- Page 1 Solar Robotic Pool Skimmer HVIN: Peng Plus User Manual (Note: Please read this manual carefully before use to avoid danger or damage to the product due to improper operation)
- Page 2 FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 catalogue 1. Safety statement 2. Product description 2.1 Part name 2.2 Product parameter 3. Instructions for use 3.1 Operation guide 3.2 APP connection 3.3 Product maintenance 4. Common Faults 5. Replaceable modules...
- Page 4 Safety statement Please read the following safety instructions and follow all usual safety precautions before using this product Please read this manual carefully and keep this manual Any operation inconsistent with this instruction manual may cause damage to the product Host and accessories related safety precautions warn 01.
- Page 5 Safety statement How to remove the battery Remove the six screws on the bottom cover and remove the bottom cover. Remove 52 screws from the left and right shell assembly and the front shell assembly, then remove 8 screws from the motor assembly on both sides, and finally remove 12 screws from the battery assembly and remove the battery assembly.
- Page 6 Product composition 2.1Part name 1.Flip open button 2.Solar panels 3.Trash basket detection port 4.Power switch 5.Rear LED light 6.Guide wheel 1.Fliptop 2.Trash basket 3.Guide wheel 4.impeller 5.Front LED light...
- Page 7 Product composition 1.TYPE-C- charging port seal cover 2.Ultrasonic obstacle avoidance sensor 3.Anti-kara rod 4.Propeller motor...
- Page 8 Product composition 2.2Product parameters Structure Dimensions of the main unit 663*453*193mm Net weight of the main unit Electronic Charging port input Rated power Rated voltage 7.2V Battery rated capacity 4800mAh Typical battery capacity 5100mAh Type C charging time 5.5h Accessory Trash basket capacity 4.5L Basket size...
- Page 9 Instructions for use 3.1Operational Guidelines Press the flip open button before use to check that the trash basket is in place. Tie rod catch There is a boundary anti-kara rod around the bottom of the machine, if the water surface of the pool is close to the level of the pool shore, you need to press tie rod catch and pull out the tie rod.
- Page 10 Instructions for use Turn on the power switch of the machine, the machine will turn on the green indicator light, and the machine will start to work forward automatically within 3 to 5 seconds. Automatically avoid turning when encountering obstacles ahead. In the outdoor scene, when the power is less than 20%, the machine automatically finds the area with strong sunlight intensity, suspends the previous work for charging, and the machine will automatically continue to work when the power is charged to 30%.
- Page 11 Instructions for use LED indicator 01. When the APP remote control machine turns, the green light flashes quickly. 02. When the machine automatically cleans the pool, the green light flashes slowly. 03. Breathing flashes red when garbage basket is full. 04.
- Page 12 Instructions for use 3.2APP connection APP settings Scan QR code of Figure 1 ，then download and install "LIBOS HOME" APP or Search for LIBOS HOME on the App Store or Android App platforms. Then, download and install it. Figure1 Open the "LIBOS HOME" App and log in. There are two ways to log in: by verification code or by password. Sign in Figure2 After logging in, click "+"...
- Page 13 Instructions for use Follow the page prompts to turn on your device and keep it within range and turn on your phone's Bluetooth. After confirming the completion of the above steps and the status of the device, click Next. Wait for the device to be bound. Figure5 Figure6 After successful binding, you can control the device.
- Page 14 Instructions for use 3.3Product maintenance Press the flip open button to remove the trash basket. Clean out the trash in the trash basket, clean it with water, and put it back into the machine.
- Page 15 Instructions for use In order to ensure the efficiency of solar charging, it is necessary to regularly clean up dust, fallen leaves and other debris. The solar panel can be rinsed with water and wiped clean. For ultrasonic sensors, dust should be cleaned regularly. If there is dirt and water stains, it will affect the distance measurement of the machine, causing the machine to keep rotating.
- Page 16 Common Faults Faults Description Faults Possible Reasons Solution The power switch at the rear Turn the power switch on of the machine is not turned on Please use the adapter to fully charge or put it The machine is out of power or under the sunlight to charge (the machine the power is not enough will work automatically after charging to 30%)
- Page 17 Replaceable modules connector Flap assembly Rear shell assembly Basket assembly Right shell assembly Bottom shell assembly Front shell assembly Guide wheel assembly Anti-kara rod Left shell assembly PCBA module...
- Page 18 IC Warning This device complies with Industry Canada’s licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
