Prince Castle Excalibur 411-MSLFCE Operating Instructions Manual

OPERATING
INSTRUCTIONS
Series Solid State Universal
Bun Toaster
Model No. 411-MSLFCE
Model 411-MSL Series Solid State Universal Bun
Toasters include the latest enhancements to pro-
duce perfectly caramelized buns. The digital read-
out continuously displays the actual temperatures of
the platens throughout operation. Now with long-life,
reliable solid state temperature controls, the
411-MSL Series Toaster maintains a much tighter
temperature swing resulting in more consistent
color, texture and internal bun temperature. Simple
to use controls allow the operator to adjust the set
point temperature by one degree increments and
adjust the toasting cycle by one second increments.
Calibration is made easy via the calibration mode
and the time/temp readout.
Printed 1998
Prince Castle Inc.
355 East Kehoe Blvd.
Tel: (630) 462-8800
Toll Free: 1-800-PCASTLE

TABLE OF CONTENTS

Side View ...................................................................... 2
Front View ..................................................................... 3
Rear View ...................................................................... 3
Internal View ................................................................. 4
Equipment Set-up ......................................................... 5
Programming ................................................................. 6
Cleaning ........................................................................ 8
Troubleshooting ............................................................ 8
Diagnostic Troubleshooting .................................... 9-11
Wiring Diagram ........................................................... 11
