Vantron SMART PDM Assembly & User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Smart PDM assembly_User_Manual_Rev1.2
Version:
1.2
Date:
2023/12/12
For any question, please contact Chengdu Vantron Technology, Ltd.
Copyright © Vantron Technology, Ltd. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMART PDM and is the answer not in the manual?

Questions and answers

Related Manuals for Vantron SMART PDM

Summary of Contents for Vantron SMART PDM

  • Page 1 Smart PDM assembly_User_Manual_Rev1.2 Version: Date: 2023/12/12 For any question, please contact Chengdu Vantron Technology, Ltd. Copyright © Vantron Technology, Ltd. All rights reserved.

  • Page 2: Change History

    Change History This document describes SMART PDM ASSEMBLY (MODEL:10-8231) briefly and is intended for all readers. This table describes the version and release date. Version Date Description Author 2023/9/4 First release 2023/9/12 Add FCC compliance statement 2023/12/12 Change the description of SMA connector...

  • Page 3: Limitation Of Liability/Non-Warranty

    Limitation of Liability/Non-warranty For direct or indirect damage to this device or other devices of Vantron caused by failure of conforming to this manual or the safety instructions on device label, Vantron assumes neither warranty nor legal liability even if the device is still under warranty.

  • Page 4: Cleaning Instructions

     Clean with a damp cloth.  Do not try cleaning exposed electronic components unless with a dust collector.  Support for special fault: Power off and contact technical support personnel of Vantron in case of the following faults: • The device is damaged.

  • Page 5: Table Of Contents

    Table of Contents 1 Introduction .......................... 1 1.1 Introduction to Vantron ....................... 1 2 Overview ..........................2 2.1 Introduction ......................... 2 2.2 Features ............................2 2.3 Order Information........................ 4 3 Product Description ......................5 3.1 Product Appearance ......................5 3.2 Device Interface ........................6 3.3 Cabling Instruction .......................

  • Page 6: Introduction

    Smart PDM assembly User Manual 1 Introduction 1.1 Introduction to Vantron Vantron offers ARM-and ATOM-based Single Boards Computer (SBC) platforms including Cirrus Logic EP9315, Rock Chip RK3128, RK3368, RK3288, RK3399, RK3566, RK3568, NXP i.MX6, i.MX8, LS1023/1043,TI OMAP35xx CortexA8series and Intel SkyLake and ApolloLake processor boards.

  • Page 7: Overview

    Smart PDM assembly User Manual 2 Overview 2.1 Introduction SMART PDM ASSEMBLY (MODEL:10-8231) is a multimedia processor based on Rockchip RK3566 with Andriod11. The device is a terminal controller designed for shower room, supporting communication interface including CAN, Ethernet, WIFI&BT, RTC, and other features.
  • Page 8 Smart PDM assembly User Manual 1*USB2.0 OTG (Type-A) for debug and program software; 1*USB3.0 HOST Type-A. 1*RJ45 - Signal port 10/100/1000Mbps Ethernet connector with indicator LEDs. Support 1xCAN Interface. 1xM12 connector and 2xM8 connector. WIFI 802.11a/b/g/n/ac, Bluetooth 5.0, with AP6256.

  • Page 9: Customer Information

    Smart PDM assembly User Manual 2.3 Customer Information Order Information (Example) MODEL: Smart PDM assembly 10-8231 Note: Please contact Vantron for more details. 2.4 Order Information Order Information (Example) MODEL: ARM IPC,V2,RK3566,4GB/32GB/HDMI/WIFI,Android11,0~60℃,RoHS IPC-RK66-TMS-GEN2 Note: Please contact Vantron for more details.

  • Page 10: Product Description

    Smart PDM assembly User Manual 3 Product Description 3.1 Product Appearance Figure 3-1-1 Overall Unit...

  • Page 11: Device Interface

    Smart PDM assembly User Manual 3.2 Device Interface ① 10/100/1000Mbps ethernet, RJ45 port with LED. ② HDMI 2.0 video output, HDMI TYPE-A port. ③ L/R Audio output, 3.5mm port. ④ USB 3.0, USB TYPE-A port. ⑤ USB 2.0 OTG, USB TYPE-A port.

  • Page 12: Hardware Operation Note

    Smart PDM assembly User Manual 4 Hardware Operation Note This chapter introduces how to use and install the device. 4.1 Operating Environment When assembling, debugging and operating the device, please ensure that there are not any hazards and that the environment meets the following requirements: ...

  • Page 13: Hardware Description

    Smart PDM assembly User Manual 5 Hardware Description 5.1 Power Input The device is configured with an AC/DC power adapter which supplies DC 24V power. 1×3×3.81mm phoenix terminal is the power input connector. Theoretically, the max. power consumption of the overall unit is 24W, including the 24V/1A output and the 2x5V/0.33A.

  • Page 14: Power Output & Can Interface

    Smart PDM assembly User Manual 5.2 Power Output & CAN Interface The device supports 3 CAN interfaces, which includes two M8 with 5V@0.33A power output and one M12 with 24V@1A power output. the mechanical PIN will make sure paring correctly.

  • Page 15: Audio

    Smart PDM assembly User Manual 5.4 HDMI The device has a HDMI 2.0 type-A output. Figure 5-4-1 HDMI Interface 5.5 Audio The device has a 3.5mm audio connector, providing Line OUT audio. Figure 5-5-1 Audio Interface 5.6 USB3.0 HOST The device supports USB3.0 HOST with 1* type-A connector.

  • Page 16: Wifi&Bt

    Smart PDM assembly User Manual Figure 5-7-1 OTG Interface 5.8 WIFI&BT The device supports WIFI 802.11a/b/g/n/ac, Bluetooth 5.0 for wireless Internet, hotspot and file transfer. Besides, the device is configured with 2.4G&5GHz dual-frequency rod antenna which is connected to the device through SMA connector.

  • Page 17: Button

    Smart PDM assembly User Manual 5.10 Button The device has 1 button used for RESET. the RESET button is shown as follows: Figure 5-10-1 Reset button...

  • Page 18: Software Note

    Smart PDM assembly User Manual 6 Software Note The software loading system is pre-installed in SMART PDM ASSEMBLY (MODEL:10-8231). Please refer to the software manual for more software information.

  • Page 19: Tips

    In the aim of avoiding accidents as far as possible, it is not allowed to replace the system or change components unless with permission and certification. Please contact the technical department of Vantron or local branches for help. Pay attention to caution signs Caution signs in this manual remind of possible danger.
  • Page 20 Smart PDM assembly User Manual information, errors in contents, citations, examples, and source programs. Vantron reserves the right to make necessary changes to this manual without prior notice. No part of this manual may be reprinted or publicly released.

  • Page 21: Fcc Compliance Statement

    Smart PDM assembly User Manual FCC compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 22: Appendix A: How To Contact Us

    Inc. Address: 48434 Milmont Ave., Fremont, CA 94538-7324 Tel: 925-621-8758 Email: sales@vantrontech.com China Office: Chengdu Vantron Technology Co., Ltd. Address: 4th-6th Floor, 1st Building, No.9, 3rd Wu Ke East Street, Wu Hou District, Chengdu 610045, China Tel: 86-28-8512-3930/3931, 8515-7572/6320 Email:...
