Lightning Audio LS05-03 Installation And Application Manual

Fig. 1
Fig. 2
S
PECIFICATIONS
Rating:
VDC:
Tolerance:
Dimensions: .5 farad : 3" x 6.5" (76.2mm x
165.1mm)
219mm)
Digital Status Caps add 1" (25mm) LSD10,
1-1/16" (27mm) LSD10DT or
1-3/4" (45mm) BD10, to height
ESR:
Terminals:
Tools:
W I
ARRANTY NFORMATION
Capacitors are nearly indestructible and will
provide years of service if installed and used in
accordance with the instructions in this manual.
If this product should prove to be defective within
a period of ninety (90) days from the date of
1
purchased, contact your dealer or Lightning Audio
Customer Service Department at 1-888-881-8186
for replacement instructions.
In the event the vent is blown or leaking as a
result of switched polarity, the capacitor is not
covered by warranty.
Stripped screws or terminals are not covered by
2
warranty. Replacements may be obtained at a
resonable cost by contacting Lightning Audio
Customer Service Department at 1-888-881-8186.
3
Gilbert, Arizona 85233 U.S.A.
4
01/03
.5 farad
(LS05-03, LSD05-03, B05-03)
1 farad
(LS0-03, LSD10-03, LSD10DT-03,
B10-03, BD10-03)
20V surge
-10% + 50%
1 farad : 3" x 8.625" (76.2mm x
<0.00198Ω @ 120Hz 25°C
1/4" 28 thread
3/16" Allen wrench
Lightning Audio
955 N. Fiesta Blvd, Suite 4
(480) 966-8278
www.lightningaudio.com
Printed in U.S.A. LAMANTF-03
.5 Farad or 1 Farad
Reinforcement
Capacitor
LS05-03 B05-03
LS10-03 B10-03
LSD10-03 BD10-03
LSD10DT-03
Installation &
Application Manual
I
NTRODUCTION
Thank you for purchasing the Lightning Audio
Reinforcement Capacitor.
The Lightning Audio Reinforcement Capacitors
allow you to help maintain continuous power to
other devices, such as amplifiers, in your audio
system.
Please read, understand and follow all instructions
before connecting the Lightning Audio
Reinforcement Capacitor. If, after reading your
manual, you still have questions regarding this
product, we recommend that you see your
Lightning Audio dealer. If you need further
assistance, you can call us direct at
1-800-881-8186.
