- Page 1 S2.200 S2.250 S2.300 S2.500...
- Page 2 Thank you for purchasing the Lighting Audio Strike Amplifier. Our customers have come to expect that Lightning Audio pushes the edge in audio. Now we will push the edge in the amplifier and woofer business with high value and high performance models.
-
Page 3: Specifications
SpecificAtions 2-ChAnnel Amplifiers StriKe S2.200 Strike S2.250 • Power RAting:60w x 2 @ 4ohms • Power RAting: 75w x 2 @ 4ohms 100w x 2 @ 2ohms (less than 1% THD) 115w x 2 @ 2ohms (less than 1% THD) - Page 4 FANModule provides constant cooling over the entire transients faster than the vehicle’s electrical system. The PC board and output devices improving sound quality by POWERCell enables the Lightning Audio amplifiers to reducing distortions caused by thermal gradients. withstand the rigors of driving 2 ohm loads.
-
Page 5: Design Features
Design FeAtures Strike S2.200 Strike S2.250 - 3 -... - Page 6 Design FeAtures Strike S2.300 Strike S2.500 - 4 -...
- Page 7 Design FeAtures A. High Level (Speaker) Inputs : The high level inputs use a detachable connector terminated with 20 AWG leads. These inputs should be used if the source unit has only speaker line (high level) outputs and not RCA outputs. B.
-
Page 8: Installation Considerations
Adequate Length—Black Grounding Wire This section focuses on some of the vehicle considerations for installing your new Lightning Audio amplifier. Checking your battery and present sound system, as well as pre-planning your system layout and best wiring routes will save installation time. -
Page 9: Mounting Location
Engine Compartment Mounting Lightning Audio amplifiers should never be mounted in the engine compartment. Not only will this void your warranty but could create an embarrassing situation caused by the ridicule from your friends. - 7 -... -
Page 10: Battery And Charging
Stock electrical systems which are in good condition should be able to handle the extra load of any Lightning Audio amplifier without problems, although battery and alternator life can be reduced slightly. To maximize the performance of your Lightning Audio amplifier, we suggest the use of a heavy duty battery and an energy storage capacitor. -
Page 11: Using Passive Crossovers
CAUTION: The Lightning Audio amplifiers are not recommended for impedance loads below 2Ω stereo and 4Ω bridged (mono) loads. -
Page 12: Installation
InstAllation • For safety, disconnect the negative lead from the car battery prior to beginning the installation Trunk Mounting Mounting the amplifier vertically on a surface will provide the best cooling for the amplifier. Passenger Compartment Mounting Mounting the amplifier in the passenger compartment will work as long as you provide a sufficient amount of air for the amplifier to cool itself. - Page 13 InstAllAtion Stereo/Mono OperAtion – 2Ω min. 2Ω min. – – 4Ω min. • RCA inputs are connected to both left and right channels. • Gain for left and right channels are set equally to balance the subwoofer. • Impedance for each channel should be 2Ω minimum. •...
-
Page 14: System Diagrams
System DiAgrAms 2 - WAy System BAND MUTE PUSH COMPACT DISC PLAYER WITH DIGITAL TUNER CD CHANGER CONTROL LOCAL LOUD DISP AS/PS MODE LOUD TRACK SCAN DISC SEEK TUNE MENU Crossover Crossover Tweeter Tweeter Midrange Midrange - 12 -... - Page 15 3 - WAy System System DiAgrAms Using Single Voice Coil Woofers BAND MUTE PUSH COMPACT DISC PLAYER WITH DIGITAL TUNER CD CHANGER CONTROL LOCAL LOUD DISP AS/PS MODE LOUD TRACK SCAN DISC SEEK TUNE MENU Crossover Crossover Tweeter Tweeter Midrange Midrange –...
- Page 16 3 - Way System System DiAgrAms Using duAl Voice Coil Woofers BAND MUTE PUSH COMPACT DISC PLAYER WITH DIGITAL TUNER CD CHANGER CONTROL LOCAL LOUD DISP AS/PS MODE LOUD TRACK SCAN DISC SEEK TUNE MENU Front Rear Crossover Crossover Tweeter Tweeter Midrange Midrange...
- Page 17 - 15 -...
- Page 18 FuncionAmiento InstAllAtion Estereo/Mono Páginas de Referencia para la Instalación Amplificadore de Lightning Audio a 2 canale – Español – 2Ω min. 2Ω min. – – 4Ω min. • Las entradas RCA se conectan a ambos canales izquierdo y derecho • Las ganancias izquierda y derecha han de ajustarse igual para ambos canales •...
- Page 19 NSTALACÍON • Por seguridad, desconecte el terminal negativo de la bateria antes de comenzar la instalacíon. Montaje en el Malatero del vehícule Monte el amplificador verticalmente con las orientadas de arriba hacia abajo. De esta manera conseguirá la mejor ventilación. Montaje en el Compartimento de Pasajeros El montaje en el compartimento de pasajeros sera eficiente en funcion de la ventilación que tenga el amplificador.
- Page 20 InstAllAtion Opération stéréo/mono (tri mode) Schéma d’Installation Amplificateur de Lightning Audio 2 canaux– – 2Ω min. 2Ω min. – – 4Ω min. • Les entrées RCA sont connectées aux canaux gauche et droit • Les Gains des canaux gauche et droit sont réglés de la même manière pour équilibrer le subwoofer •...
-
Page 21: Solutions Aux Problèmes
NSTALLATION • Pour votre sécurité, deéconnectez la borne négative de la batterie du véhicule avant de com- mencer le montage. Montage dans l’habitacle L’installation d’un amplificateur est envisageable dans l’habitacle dès que la convection naturelle est suffisante. Il est possible de fixer l’amplificateur soud un siège si la hauteur de celui-ci permet au minimum d’avoir trois centimètres au- dessus du dissipateur thermique. - Page 22 InstAllAtion Stereo/Mono Operation Installations Beiblatt 2-Kanal Lightning Audio Amplifier – Deutsch – 2Ω min. 2Ω min. – – 4Ω min. • Chinch Eingänge des rechten- und linken-Kanales anschlieben • Gain -Kontrolle gleich stellen um das Signal des Subwoofer anzugleichen • Die Impedanz für jeden Kanal sollte minimum 2 Ohm betragen.
-
Page 23: Einbau
INBAU • Zur Sicherheit klemmen Sie den Negativ-Pol der Batterie während des gesamten Einbaues ab. Im Fahrzeugkofferraum Der vertikale Einbau der Endstufen, gibt dem Verstärker die beste Kühlung. Auf der Beifahrerseite Sollte der Verstärker auf der Beifahrerseite montiert werden, so ist es sehr wichtig für eine ausreichende Kühlung zu sorgen. - Page 24 InstAllAtion Stereo/Mono Operation Istruzioni di Installation Amplificatore di Lightning Audio a 2 canali – Italiano – 2Ω min. 2Ω min. – – 4Ω min. • Ingressi RCA collegati sia al canale destro sia al sinistro • Gain (controllo di sensibilitá) regolati in modo identico per bilanciare il subwoofer •...
-
Page 25: Installazione
NSTALLAZIONE • Per sicurezza, scollegare il polo netativo della batteria dell’auto prima di iniziare l’installazione. Nel Bagagliaio Montando l’amplificatore su una superficie in verticale con le alette direzionate dall’alto verso il basso si garantirá un miglior raffreddamento dell’amplificatore. Nel’abitacolo Montare l’amplificatore nell’abitacolo si avrá un funzionamento regolare se si garantisce un flusso d’aria sufficiente. Per l’installazione sotto un sedile, é... - Page 26 Warranty Policies and Technical Suppor SPAÑOL RANÇAIS Veuillez contacter votre distributeur Por favor contacte al Distribuidor Lightning Audio agréé pour toute infor- Autorizado Lightning Audio en su locali- mation concernant les modalités de dad para información sobre Políticas de garantie et le support technique.
-
Page 27: Limited Warranty Information
This warranty covers only the original purchaser of Lightning Audio product purchased from an Authorized Lightning Audio Dealer in the United States. In order to receive service, the purchaser must provide Lightning Audio with a copy of the receipt stating the customer name, dealer name, product purchased and date of purchase. - Page 28 MADE IN CHINA Lightning Audio 955 N. Fiesta Blvd, Suite 4 Gilbert, Arizona 85233 U.S.A. In U.S.A., (480) 966-8278 08/00 M.J.T...
