Napa Sectional - Middle
183096
32"H x 27"W x 32"D
ASSEMBLY INSTRUCTIONS
Napa Sectional - Middle
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Product Specialist: 800-491-4958
Online:
www.grandinroad.com
MADE IN VIETNAM
Page 1 of (7)
Advertisement
Related Manuals for Grandinroad Napa Sectional - Middle
Summary of Contents for Grandinroad Napa Sectional - Middle
- Page 1 Product Specialist: 800-491-4958 GR Product Name: Napa Sectional - Middle Online: www.grandinroad.com GR Product Number: 183096 Assembled Dimensions: 32”H x 27”W x 32”D ASSEMBLY INSTRUCTIONS Napa Sectional - Middle Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete.
- Page 2 Remove all parts, hardware and protective packaging from carton and carefully arrange on a clean, level, padded surface. Ltr. Qty. Components Ltr. Qty. Components SEAT and BACK SIDE BACK CUSHION SEAT CUSHION Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 2 of (7)
- Page 3 Back and Seat (A) to the Side (B)x1 with Long Bolts w/ Washers (E)x4 first by hand, then tightening with the provided Allen Wrench, as shown below. Back and Seat Side(x1) Long Bolt w/ washers (x4) Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 3 of (7)
- Page 4 Seat Assembly to the Side (B)x1 with Long Bolts w/ Washers (E)x4 first by hand, then tightening with the provided Allen Wrench, as shown below. Seat Assembly Long Bolt w/ washers (x4) Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 4 of (7)
- Page 5 THREAD Then, the velcro straps of the SEAT CUSHION (D) through the back of the PRESS Seat Frame and straps together to secure to frame, like shown. Seat Assembly Seat Cushion Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 5 of (7)
-
Page 6: Step 9: Cleaning And Care Instructions
All wood finishes, fabric, and leathers will fade with time. Avoid direct sunlight. Avoid extreme changes in humidity. This can cause the wood components to warp and crack. Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 6 of (7) - Page 7 Please contact one of our Product Specialists for assembly assistance or questions at 1-800-491-4958 or email ps@grandinroad.com. Specialists are available weekdays 8:00am to 8:00pm EST or Saturday 9:30 am to 6:00pm. Page 7 of (7)
