grandin
WARNING
:
Failure to follow these directions and
warnings can result in serious injury and/or product damage.
!
Never stand on or use this chair as a ladder.
!
Do not tip this chair when seated.
If any parts become missing, damaged or worn, discontinue use until
!
they are replaced with identical parts.
!
This item is intended for indoor use only.
road
Item #175755
®
Corinne Arm Chair
Assembly Instructions
CONTACT
for assembly questions on
Weekdays // 8am-8pm EST
Saturday // 9am-6:30pm EST
EMAIL
service@grandinroad.com
#3707A
1.800.491.4958
Advertisement
Related Manuals for Grandinroad Corinne 3707A
Summary of Contents for Grandinroad Corinne 3707A
- Page 1 Weekdays // 8am-8pm EST Do not tip this chair when seated. Saturday // 9am-6:30pm EST If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts. EMAIL This item is intended for indoor use only. service@grandinroad.com...
- Page 2 PARTS Please confirm you have the necessary parts to complete the assembly. COMPONENTS HARDWARE TOOLS Chair Seat (x1) Long Bolt with Washers (x8) ALLEN WRENCH Front Legs (x2) 1.800.491.4958 Right Back Leg (x1) Left Back Leg (x1)
- Page 3 ASSEMBLE Corinne Arm Chair FLIP With assistance, the Chair Seat (A) upside down and rest it on a table. Chair Seat (x1) Right Rear Leg (x1) Long Bolt w/ Washers (x2) FASTEN the Right Back Leg (C) in the leg slot as shown below using two Long Bolts with Washers (E) and an allen wrench.
-
Page 4: Chair Assembly
ASSEMBLE Corinne Arm Chair FASTEN the Left Back Leg (D) in the leg slot as shown below using two Long Bolts CHAIR with Washers (E) and an allen wrench. ASSEMBLY NOTE: Do Not Over-tighten Bolts. Front Leg (x1) Left Back Leg (x1) FASTEN the Front Leg (B) in the leg slot as shown below using two Long Bolts with... - Page 5 ASSEMBLE Corinne Arm Chair FASTEN the Front Leg (B) in the leg slot as shown below using two Long Bolts with CHAIR Washers (E) and an allen wrench. ASSEMBLY NOTE: Do Not Over-tighten Bolts. Front Leg (x1) Long Bolt w/ Washers (x2) FLIP With assistance,...
- Page 6 ASSEMBLE Corinne Arm Chair LEVELING CHAIR THE HOLES IN THE SEAT FRAME HAVE BEEN OVERSIZED TO ALLOW FOR EASIER ASSEMBLY. ASSEMBLY If your chair is not sitting level, adjustment may be necessary. To adjust, slightly loosen the bolts that connect the LEGS to the SEAT FRAME, until the parts can move freely.
