Grandinroad 6433Q/K Assembly Instructions Manual

Bradford canopy bed
Hide thumbs

Advertisement

Quick Links

Download this manual
grandin
WARNING
:
Failure to follow these directions and
warnings can result in serious injury and/or product damage.
!
Assistance is required to assemble this bed.
!
Never stand on the bed, the side rails or the cross rails.
!
Never use this bed as a ladder.
!
Do not tip or move the bed frame without first removing the mattress and box springs.
!
Do not scoot the bed frame. With a helper, lift the frame and set it down in the
desired location.
If any parts become missing, damaged or worn, discontinue use until
!
they are replaced with identical parts.
!
Periodically re-tighten all bolts.
!
This item is intended for indoor use only.
176982 Bradford Canopy Bed
Assembly Instructions
road
#6433Q/K
Bradford Canopy Bed
Assembly Instructions
CONTACT
for assembly questions on
Weekdays // 8am-8pm EST
Saturday // 9:30am-6pm EST
EMAIL
service@grandinroad.com
®
1.800.491.4958

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6433Q/K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandinroad 6433Q/K

Summary of Contents for Grandinroad 6433Q/K

  • Page 1 ® 176982 Bradford Canopy Bed Assembly Instructions #6433Q/K Bradford Canopy Bed Assembly Instructions WARNING Failure to follow these directions and warnings can result in serious injury and/or product damage. Assistance is required to assemble this bed. Never stand on the bed, the side rails or the cross rails.
  • Page 2 COMPONENTS Please con rm you have the necessary parts to complete the assembly. COMPONENTS LEFT FOOTBOARD LEG CROSS RAIL (X3) RIGHT HEADBOARD LEG CENTER LEGS (x3) LEFT HEADBAORD LEG RIGHT FOOTBOARD LEG HEADBOARD CANOPY POST (x2) END CAP (x4) FOOTBOARD CANOPY POST (X2) HEADBOARD LOWER RAIL FOOTBOARD HEADBOARD UPPER RAIL...

  • Page 3: Hardware & Tools

    HARDWARE & TOOLS Please con rm you have the necessary parts to complete the assembly. TOOLS HARDWARE MEDIUM BOLTS (X8) ALLEN WRENCH LOCK WASHERS (X8) FLAT WASHERS (X8) SHORT BOLT (X52) LONG BOLT (X2) 1.800.491.4958...
  • Page 4 ASSEMBLE Headboard RIGHT HEADBOARD LEG JOIN the Right Headboard Leg (A) and Left Headboard Leg (B) to Headboard Lower Rail (D), Headboard (F), and Head- board Upper Rail (E1). NOTE: Ensure holes align. LEFT HEADBOARD LEG HEADBOARD LOWER RAIL HEADBOARD UPPER RAIL HEADBOARD ATTACH...
  • Page 5 ASSEMBLE Footboard LEFT JOIN the Left Footboard Leg (G) and FOOTBOARD LEG Right Footboard Leg (H) to Footboard (J). NOTE: Ensure holes align. RIGHT FOOTBOARD LEG FOOTBOARD SHORT BOLTS (X4) ATTACH the Left Footboard Leg (G) and Right Footboard Leg (H) to Footboard (J) by using 4x Short Bolts (Y).
  • Page 6 ASSEMBLE Cross Rails FASTEN Center Legs (O) to Cross Rails CROSS RAIL (X3) (N) x3.Tighten with an allen wrench. NOTE: DO NOT Overtighten. Tighten Evenly.` CENTER LEGS (X3) SHORT BOLTS (X6) SET ASIDE the Cross Rail assembly until it is needed. BEGIN the platform assembly.
  • Page 7 ASSEMBLE Platform PLACE the Cross Rail Assembly x3 between Right Side Rail (K) and Left Side CROSS RAIL Rail (L) while aligning holes. ASSEMBLY RIGHT SIDE RAIL CROSS RAIL ASSEMBLY LEFT SIDE RAIL ATTACH SHORT BOLTS (X12) each Center Rail Assembly x3 between Right Side Rail (K) and Left Side Rail (L) by using 12x Short Bolts (Y).
  • Page 8 ASSEMBLE Lower Bed INSERT the Platform Assembly into the Headboard Assembly and Foot- HEADBOARD board Assembly. Align holes. ASSEMBLY HEADBOARD ASSEMBLY PLATFORM ASSEMBLY FOOTBOARD ASSEMBLY PLATFORM ASSEMBLY FOOTBOARD ASSEMBLY ATTACH the Platform Assembly into the Headboard Assembly and Foot- board Assembly by using 16x Short Bolts (Y).
  • Page 9 ASSEMBLE Canopy CANOPY INSERT CROSS RAIL each Footboard Leg Posts x2 (I) into the Canopy Cross Rail (E2) as shown. FOOTBOARD CANOPY POST (X2) SHORT BOLTS (X2) FASTEN the Canopy Cross Rail (E2) the to Footboard Leg Posts x2 (I) by using 2x Short Bolts (Y).
  • Page 10 ASSEMBLE Canopy CANOPY CROSS RAIL INSERT Short Rail (D) into Headboard Canopy Posts x2 (C). HEADBOARD CANOPY POST (X2) SHORT BOLTS (X2) FASTEN the Canopy Cross Rail (E2) the to Headboard Canopy Post x2 (C) by using 2x Short Bolts (Y). ALLEN WRENCH HELP? 1.800.491.4958...
  • Page 11 ASSEMBLE Canopy INSERT LOWER CANOPY Upper Canopy Assembly into ASSEMBLY the top of Head Board, as shown. Next, insert the Lower Canopy Assembly into the top of the Foot Board, as shown. UPPER CANOPY ASSEMBLY UPPER CANOPY ASSEMBLY LOWER CANOPY ASSEMBLY ASSEMBLY ALLEN WRENCH...

  • Page 12: Bed Assembly

    ASSEMBLE Canopy CONNECT the 2x Canopy Side Rails (M) into Upper Canopy Assembly and Lower Canopy Assembly. BED ASSEMBLY FASTEN the Canopy Side Rails (M) by using 4x Short Bolts (Y). CANOPY SIDE RAILS (X2) SHORT BOLTS (X4) LONG BOLTS (X2) ALLEN WRENCH FASTEN Lower...
  • Page 13 ASSEMBLE Complete END CAP (X4) INSERT End Caps x4 (E) as shown. FASTEN each bolts using allen wrench. Do not overtighten. ASSEMBLY IS COMPLETE. HELP? 1.800.491.4958...

  • Page 14: Cleaning & Care Instructions

    All wood finishes, fabric, and leathers will fade with time. Avoid direct sunlight. Avoid extreme changes in humidity. This can cause the wood components to warp and crack. GrandinRoad: Please contact one of our Production Specialist for assembly assistance or questions at 1.800.491.4958 or email service@grandinroad.com.
