SINK SPECIFICATIONS
DOUBLE BOWL Undermount
VG 3321R
Model
FEATURED MODEL VG3321R
5 & 9" BOWL DEPTH
FEATURES
18 gauge, stainless steel
304 Nickel - Bearing Content
Long-lasting, easy-to-clean, satin finish
Available in right and left configurations
Sound-deadening insulation
Available in right configuration (big bowl is on the
right) or left configuration (big bowl is on the left)
Rear drain placement
198mm and 98mm radius corners on big bowl
96mm radius corners on small bowl
PACKING LIST
-
SINK
-
CUT-OUT TEMPLATE
-
MOUNTING HARDWARE
NOMINAL DIMENSIONS
MODEL #
BOWL SIZE
VG3321R
21 1/2" x 19"
7 " x 14 1/4"
31 3/4" [806mm]
7"
[177mm]
SINK DEPTH
EXTERIOR
GAUGE
DIM.
9"
31 3/4" x 21"
5"
21 1/2" [545mm]
TOP VIEW
FRONT VIEW
18
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VIGO VG3321R
Summary of Contents for VIGO VG3321R
- Page 1 SINK SPECIFICATIONS DOUBLE BOWL Undermount VG 3321R Model FEATURED MODEL VG3321R 5 & 9" BOWL DEPTH FEATURES 18 gauge, stainless steel 304 Nickel - Bearing Content Long-lasting, easy-to-clean, satin finish Available in right and left configurations Sound-deadening insulation Available in right configuration (big bowl is on the...
-
Page 2: Tools And Materials Needed
Long-Life Care Vigo Stainless Steel Sinks are easy to keep looking new, longer with minimal care. For best results, always rinse with a mild soap and wipe after each use. Rub lightly with soft cloth in the direction of the grain line on a regular basis. -
Page 3: Installation Instructions
Please carefully read complete instructions before beginning installation. Only a professional stone fabricator is qualified to perform this installation. Note: These instructions are for installation with solid surface, composite material countertops. Vigo recommends professional countertop installers and is not responsible for damage to the countertop or sink during installation. - Page 4 6. Loosely attach mounting brackets to the countertop, parallel to the cutout opening using the supplied mounting screws and nuts. Mounting screws with brass inserts are supplied with the sink, however, countertop material vary and the correct type of fasteners should be recommended by your installer or supplier. 7.
-
Page 5: Care And Maintenance
Care and Maintenance ALWAYS preventative cleaning. affect the appearance of your sink. abrasive such as Comet. up over time with a mild solution of vinegar and water followed by a thorough flushing with water. grain. NOT RECOMMENDED FOR MIRROR FINISH. NEVER develop rust spots in the stainless steel surface. - Page 6 Subject to the Warranty Service provision below, any product reported to the authorized dealer or to VIGO as being defective within the warranty period will be repaired or replaced (with a product of equal value) at the option of VIGO. This warranty extends to the original owner or end-user and is not transferable to a subsequent owner.
-
Page 7: Packing List
FAUCET SPECIFICATIONS Pull-Out Spray Kitchen Faucet Model VG02019 MODEL VG02019 FEATURES PACKING LIST DIMENSIONS MODEL # HOLE FAUCET SPRAYER DIAMETER HEIGHT REACH VG02019 1 3/8" 13 7/8" 8 1/2" 8 1/2" 1 3/8"... -
Page 8: Side View
3 3/8" 8 1/2" 2 1/4" 1 3/8" SIDE VIEW SPRAY HOSE VG02019 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... -
Page 9: Package Content
HOSE CONNECTIONS. IF LEAKS ARE DETECTED, REFER BACK TO THE INSTRUCTIONS AND ADJUST ACCORDINGLY. If you have any questions please contact the Vigo Technical Support TIGHTENING NUTS SLIGHTLY MAY STOP ANY MINOR LEAKS. Department before proceeding with installation. -
Page 10: Troubleshooting
5.A - Remove and clean aerator. 5.B - Contact Vigo Technical Support for replacement. PARTS LIST - For any parts needed but not shown, please contact Vigo Technical Support PART PART # FINISH SUPPLY DATE INDICATOR (INTERNAL USE ONLY) - Page 11 VIGO or an authorized VIGO dealer, through the lifetime of the original owner or end-user. VIGO warrants the cartridge component of the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner, contractor, or builder, from VIGO or an authorized VIGO dealer.
