Big Blue
Deutz
OWNER'S MANUAL
OM-4428AZ
215932
Processes
Stick (SMAW) Welding
TIG (GTAW) Welding
Air Carbon Arc (CAC-A) Cutting
and Gouging
Description
Engine Driven Welder/Generator
600 X
®
2023-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Big Blue 600 X and is the answer not in the manual?

Questions and answers

Related Manuals for Miller Big Blue 600 X

Summary of Contents for Miller Big Blue 600 X

  • Page 1 OM-4428AZ 2023-05 215932 Processes Stick (SMAW) Welding TIG (GTAW) Welding Air Carbon Arc (CAC-A) Cutting and Gouging Description Engine Driven Welder/Generator Big Blue 600 X ® Deutz OWNER’S MANUAL For product information, Owner’s Manual translations, and more, visit www.MillerWelds.com...
  • Page 2 We know you don’t have time to do it any other way. That’s why when Niels Miller first started building arc welders in 1929, he made sure his products offered long-lasting value and superior quality.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1 – SAFETY PRECAUTIONS – READ BEFORE USING..............1 Symbol Usage .
  • Page 4 TABLE OF CONTENTS SECTION 7 – OPERATING AUXILIARY EQUIPMENT................34 Export Auxiliary Power Receptacles.

  • Page 5: Section 1 - Safety Precautions - Read Before Using

    SECTION 1 – SAFETY PRECAUTIONS – READ BEFORE USING Protect yourself and others from injury—read, follow, and save these important safety precautions and operating instructions. 1-1. Symbol Usage DANGER! – Indicates a hazardous situation which, if not avoided, will result in death or serious injury. The possible hazards are shown in the adjoining symbols or explained in the text.
  • Page 6 Accidental contact of electrode to metal objects can cause sparks, ex- FLYING METAL OR DIRT can injure plosion, overheating, or fire. Check and be sure the area is safe be- eyes. fore doing any welding. � Welding, chipping, wire brushing, and grinding �...

  • Page 7: Engine Hazards

    � Install cylinders in an upright position by securing to a stationary � Turn face away from valve outlet when opening cylinder valve. Do support or cylinder rack to prevent falling or tipping. not stand in front of or behind the regulator when opening the valve.

  • Page 8: Compressed Air Hazards

    1-4. Compressed Air Hazards � Reinstall doors, panels, covers, or guards when servicing is fin- COMPRESSED AIR EQUIPMENT can ished and before starting unit. injure or kill. � If ANY air is injected into the skin or body seek medical help immediately.
  • Page 9 � Follow the guidelines in the Applications Manual for the Revised HIGH PRESSURE FLUIDS can injure NIOSH Lifting Equation (Publication No. 94-110) when manually or kill. lifting heavy parts or equipment. � Engine fuel system components can be under high OVERHEATING can damage motors.

  • Page 10: California Proposition 65 Warnings

    � If notified by the FCC about interference, stop using the equipment � Be sure all equipment in the welding area is electromagnetically at once. compatible. � Have the installation regularly checked and maintained. � To reduce possible interference, keep weld cables as short as �...

  • Page 11: Section 2 - Consignes De Sécurité - Lire Avant Utilisation

    SECTION 2 – CONSIGNES DE SÉCURITÉ - LIRE AVANT UTILISATION Pour écarter les risques de blessure pour vous-même et pour autrui — lire, appliquer et ranger en lieu sûr ces consignes relatives aux précautions de sécurité et au mode opératoire. 2-1.
  • Page 12 � Ne pas toucher aux portes-électrodes qui sont raccordés à deux bien ventilé, et en portant un respirateur à alimentation d’air. Les machines à souder en même temps, car cela entraîne la présence revêtements et tous les métaux renfermant ces éléments peuvent d’une tension de circuit-ouvert double.

  • Page 13: Dangers Existant En Relation Avec Le Moteur

    � Ne pas souder là où l’air ambiant pourrait contenir des poussières, � Les porteurs d’implants médicaux doivent consulter leur médecin gaz ou émanations inflammables (vapeur d’essence, par et le fabricant du dispositif avant de s’approcher de la zone où se exemple).

  • Page 14: Dangers Liés À L'air Comprimé

    � Ne pas placer l’appareil sur, au-dessus ou à proximité de surfaces � Ne pas toucher aux pièces chaudes, utiliser les outils recomman- inflammables. dés et porter des gants de soudage et des vêtements épais pour éviter les brûlures. � Tenir à distance les produits inflammables de l’échappement. LA VAPEUR ET LE LIQUIDE DE Les PIÈCES MOBILES peuvent REFROIDISSEMENT CHAUD peuvent...

  • Page 15: Symboles De Dangers Supplémentaires En Relation Avec L'installation, Le Fonctionnement Et La Maintenance

    L’AIR COMPRIMÉ risque de Les PIÈCES MOBILES peuvent provoquer des blessures ou même la causer des blessures. mort. � S’abstenir de toucher des parties mobiles telles � Avant d’intervenir sur le circuit d’air comprimé, que des ventilateurs, courroies et rotors. couper l’alimentation électrique, verrouiller etéti- �...
  • Page 16 � Utiliser uniquement des équipements adéquats pour un fonction- � Régler les commandes de charge de batterie sur la position d’arrêt nement avec une alimentation de 50/60 ou de 60 Hz. avant de brancher la batterie. Veiller à ce que les pinces de charge ne se touchent pas.

  • Page 17: Proposition Californienne 65 Avertissements

    � Effectuer l’installation, l’entretien et toute intervention selon les LE SOUDAGE À L’ARC risque de manuels d’utilisateurs, les normes nationales, provinciales et de provoquer des interférences. l’industrie, ainsi que les codes municipaux. � L’énergie électromagnétique risque de provoquer LE RAYONNEMENT HAUTE des interférences pour l’équipement électronique FRÉQUENCE (H.F.) risque de sensible tel que les ordinateurs et l’équipement...
  • Page 18 les porteurs d’implants médicaux doivent être prises: par exemple, 5. Connecter la pince sur la pièce aussi près que possible de la des restrictions d’accès pour les passants ou une évaluation indivi- soudure. duelle des risques pour les soudeurs. Tous les soudeurs doivent ap- 6.

  • Page 19: Section 3 - Definitions

    Safe Safe8 Safe8 � Complete Parts List is available at www.MillerWelds.com Never use generator inside a home or garage, even if doors Never use generator inside a home or garage, even if doors a SECTION 3 – DEFINITIONS Never use generator inside a home or garage, even if doors a dows are open.

  • Page 20: Miscellaneous Symbols And Definitions

    Connect green or green/yellow grounding conductor to ground Connect green or green/yellow grounding conductor to ground terminal. terminal. Hot Parts can burn. Do not touch hot parts bare-handed. Allow cooling period before handling parts or equip- Connect input conductors (L1, L2 And L3) to line terminals. Connect input conductors (L1, L2 And L3) to line terminals.
  • Page 21 � Complete Parts List is available at www.MillerWelds.com Engine Start (En- Spark Arrestor Welding (General) gine RPM) Air Filter Shielded Metal Arc Engine Stop Welding (SMAW) Gas Tungsten Arc Air Flow Welding (GTAW) / Engine Oil Tungsten Inert Gas (TIG) Welding Check Air Cleaner Starting Aid Fuel...

  • Page 22: Section 4 - Specifications

    Information About Default Weld Parameters And Settings NOTICE – Each welding application is unique. Although certain Miller Electric products are designed to determine and default to certain typical welding parameters and settings based upon specific and relatively limited application variables input by the end user, such default settings are for reference purposes only;...

  • Page 23: Dimensions Weights And Operating Angles

    � Complete Parts List is available at www.MillerWelds.com 4-5. Dimensions Weights And Operating Angles Dimensions Height 50 in. (1270 mm) (to top of muffler) Width 28.5 in. (724 mm) Do not exceed tilt angles or engine (mtg. brackets turned in) could be damaged or unit could tip.

  • Page 24: Environmental Specifications

    � Complete Parts List is available at www.MillerWelds.com 4-6. Environmental Specifications A. IP Rating IP Rating IP23S This equipment is designed for outdoor use. It may be stored, but is not intended to be used for welding outside during precipitation unless sheltered.

  • Page 25: Duty Cycle And Overheating

    � Complete Parts List is available at www.MillerWelds.com 4-7. Duty Cycle And Overheating Duty Cycle is percentage of 10 minutes that 100% Duty Cycle At 500 Amperes unit can weld rated load without overheating. � This unit is rated for welding at 500 am- peres continuously.

  • Page 26: Fuel Consumption

    � Complete Parts List is available at www.MillerWelds.com 4-9. Fuel Consumption The curve shows typical fuel use under weld or power loads. 1800 RPM IDLE 100 150 200 250 300 350 400 450 500 DC WELD AMPERES AT 100% DUTY CYCLE 193 093 4-10.

  • Page 27: Section 5 - Installation

    � Complete Parts List is available at www.MillerWelds.com SECTION 5 – INSTALLATION 5-1. Installing Welder/Generator Movement And Airflow Clearance 18 in. 18 in. (460 mm) (460 mm) 18 in. 18 in. (460 mm) 18 in. 18 in. (460 mm) (460 mm) (460 mm) 18 in.

  • Page 28: Grounding Generator To Truck Or Trailer Frame

    � Complete Parts List is available at www.MillerWelds.com 5-2. Grounding Generator to Truck or Trailer Frame 1-1. Grounding Generator To Truck Or Trailer Frame GND/PE Bed liners, shipping skids, and 3 Metal Vehicle Frame Always ground generator frame to some running gear insulate the vehicle frame to prevent electric welding generator from the vehicle shock and static electricity hazards.

  • Page 29: Installing Exhaust Pipe

    � Complete Parts List is available at www.MillerWelds.com 5-4. Installing Exhaust Pipe Stop engine and let cool. SECTION 2 INSTALLATION � Point exhaust pipe in desired direction but always away from front panel and direction of travel. 1/2 in. philips head wrench crescent wrench 5-5.

  • Page 30: Engine Prestart Checks

    2 Full � Use Starting Aid switch (see Section 6- � Diesel engines in Miller equipment are Add fresh diesel fuel before starting to pre- � Keep battery in good condition. Store meant to operate optimally at moder- vent air from entering the fuel system (see battery in warm area.

  • Page 31: Weld Output Terminals

    � Complete Parts List is available at www.MillerWelds.com 5-7. Weld Output Terminals Turn off power before connecting to weld output terminals. Do not use worn, damaged, under- sized, or repaired cables. 1 Positive (+) Weld Output Terminal 2 Negative (−) Weld Output Terminal Stick and TIG Welding For Stick and TIG welding Direct Current Electrode Positive (DCEP), connect elec-...

  • Page 32: Selecting Cable Sizes

    � Complete Parts List is available at www.MillerWelds.com 5-9. Selecting Cable Sizes* NOTICE – The Total Cable Length in Weld Circuit (see table below) is the combined length of both weld cables. For example, if the power source is 100 ft (30 m) from the workpiece, the total cable length in the weld circuit is 200 ft (2 cables x 100 ft). Use the 200 ft (60 m) column to determine cable size.

  • Page 33: Section 6 - Operating The Welder/Generator

    � Complete Parts List is available at www.MillerWelds.com SECTION 6 – OPERATING THE WELDER/GENERATOR 6-1. Front Panel Controls (See Section 6-2) 238 627-B / 803 602 OM-4428 Page 29...

  • Page 34: Description Of Front Panel Controls (See Section 6-1)

    5 Engine Temperature Gauge 2 Engine Control Switch R1 to maximum when the arc breaks. NOTICE – Diesel engines in MILLER equip- Normal temperature is 212 − 239° F (100 − Also in the Stick position, the arc drive (dig) ment are meant to operate optimally at mod- 115°...

  • Page 35: Remote Amperage Control (Optional)

    � Complete Parts List is available at www.MillerWelds.com 6-3. Remote Amperage Control (Optional) Example: Combination Remote Amperage Control (Stick) Max (240 A DC) Min (84 A DC) Ref. 154 862-A / Ref. 236 973 / 803 602 Combination Remote Amperage Control Step 4.

  • Page 36: Weld Control/Arc Condition Information Label

    � Complete Parts List is available at www.MillerWelds.com 6-4. Weld Control/Arc Condition Information Label � Set weld controls as shown to achieve softer or stiffer arc conditions for differ- ent applications. 212 944-B OM-4428 Page 32...

  • Page 37: Fuel/Hour Gauge Descriptions

    � Complete Parts List is available at www.MillerWelds.com 6-5. Fuel/Hour Gauge Descriptions OM-4428 Page 33...

  • Page 38: Section 7 - Operating Auxiliary Equipment

    � Complete Parts List is available at www.MillerWelds.com SECTION 7 – OPERATING AUXILIARY EQUIPMENT 7-1. Export Auxiliary Power Receptacles 805259-A Test GFCI monthly. See Section 7-2 Use GFCI protection when operating � At least once a month, press test but- for GFCI information and for reset- auxiliary equipment.

  • Page 39: Gfci Receptacle Information, Resetting, And Testing

    � Complete Parts List is available at www.MillerWelds.com 7-2. GFCI Receptacle Information, Resetting, And Testing Use GFCI protection when operating If a ground fault is detected, the GFCI Reset Resetting GFCI Receptacles auxiliary equipment. If unit does not button pops out, and the circuit opens to dis- If a GFCI fault occurs, stop engine and dis- have GFCI receptacles, use GFCI- connect power to the faulty equipment.

  • Page 40: Section 8 - Deutz D2011L04I Maintenance

    � Complete Parts List is available at www.MillerWelds.com SECTION 8 – DEUTZ D2011L04I MAINTENANCE 8-1. Maintenance Label (Deutz D2011L04i-Powered Units) OM-4428 Page 36...

  • Page 41: Routine Maintenance (Deutz D2011L04I-Powered Units)

    Hours ouble: Dirty fuel filters. Symptom: Fuel flow to the engine is When servicing a Miller gasoline-powered welder/generator, always perform the following basic stricted. Engine will not run or run well if it is starved for fuel. engine checks before contacting the engine manufacturer.

  • Page 42: Operating Optional Oil Pan Heater

    � Complete Parts List is available at www.MillerWelds.com Every Every 6000 6000 Hours Hours or 5 or 5 Years Years ��Engine Timing Belt � Clean exterior, including stainless steel, frequently to prevent rust and corrosion. *To be done by factory authorized service agent. DEUTZ Service: http://www.deutzamericas.com To ensure rapid, efficient service support, you should initially contact your nearest DEUTZ service distributor or dealer.

  • Page 43: Servicing Air Cleaner (Deutz D2011L04I-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com NOTE: This standard is now used for IED/PED models with plastic air cleaner housing. 8-5. Servicing Air Cleaner (Deutz D2011L04i-Powered Units) Stop engine. NOTICE – Do not run engine without air cleaner or with dirty element. Engine dam- age caused by using a damaged element is not covered by the warranty.

  • Page 44: Inspecting/Cleaning Optional Spark Arrestor (Deutz D2011L04I-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 8-6. Inspecting/Cleaning Optional Spark Arrestor (Deutz D2011L04i-Powered Units) Stop engine and let cool. 1 Spark Arrestor Muffler 2 Cleanout Plug Remove plug and remove any dirt covering cleanout hole. Start engine and run at idle speed to blow out cleanout hole.

  • Page 45: Adjusting Engine Speed (Deutz D2011L04I-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 8-8. Adjusting Engine Speed (Deutz D2011L04i-Powered Units) Stop engine and let cool. � For operation at high altitude, engine may require adjustments. If adjustment is necessary, contact engine manufac- turer’s Factory Authorized Service Agent.

  • Page 46: Servicing Fuel And Lubrication Systems (Deutz D2011L04I-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 8-9. Servicing Fuel And Lubrication Systems (Deutz D2011L04i-Powered Units) 803 657 tools/ maintenance label for oil/filter change To replace secondary fuel filter: Stop engine and let cool. allen_wrench allen_set flathead philips head wrench crescent wrench information.

  • Page 47: Overload Protection (Deutz D2011L04I-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 8-10. Overload Protection (Deutz D2011L04i-Powered Units) Stop Engine. � When a supplementary protector, cir- cuit breaker or fuse opens, it usually in- dicates a more serious problem exists. Contact Factory Authorized Service Agent.

  • Page 48: Section 9 - Deutz F3L912 Maintenance

    � Complete Parts List is available at www.MillerWelds.com SECTION 9 – DEUTZ F3L912 MAINTENANCE 9-1. Maintenance Label (Deutz F3L912-Powered Units) OM-4428 Page 44...

  • Page 49: Routine Maintenance (Deutz F3L912-Powered Units)

    Technical Manual. event damage to the EFI fuel pump and injectors. See Section __. � Weld Terminals Complete Parts List available at www.MillerWelds.com When servicing a Miller gasoline-powered welder/generator, always perform the following basic FUEL Every Refer to Complete Parts List is available at www.MillerWelds.com...

  • Page 50: Checking Generator Brushes

    � Complete Parts List is available at www.MillerWelds.com Every 3000 Hours � Injectors* � Clean exterior, including stainless steel, frequently to prevent rust and corrosion. *To be done by factory authorized service agent. DEUTZ Service: http://www.deutzamericas.com To ensure rapid, efficient service support, you should initially contact your nearest DEUTZ service distributor or dealer. They are staffed with highly qualified parts, service and engine specialists to handle your different needs.

  • Page 51: Servicing Air Cleaner (Deutz F3L912-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com NOTE: This standard is now used for IED/PED models with plastic air cleaner housing. 9-4. Servicing Air Cleaner (Deutz F3L912-Powered Units) Stop engine. NOTICE – Do not run engine without air cleaner or with dirty element. Engine dam- age caused by using a damaged element is not covered by the warranty.

  • Page 52: Inspecting/Cleaning Optional Spark Arrestor (Deutz F3L912-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 9-5. Inspecting/Cleaning Optional Spark Arrestor (Deutz F3L912-Powered Units) Stop engine and let cool. 1 Spark Arrestor Muffler 2 Cleanout Plug Remove plug and remove any dirt covering cleanout hole. Start engine and run at idle speed to blow out cleanout hole.

  • Page 53: Adjusting Engine Speed (Deutz F3L912-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 9-7. Adjusting Engine Speed (Deutz F3L912-Powered Units) Stop engine and let cool. � For operation at high altitude, engine may require adjustments. If adjustment is necessary, contact engine manufac- turer’s Factory Authorized Service Agent.

  • Page 54: Servicing Fuel And Lubrication Systems (Deutz F3L912-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 9-8. Servicing Fuel And Lubrication Systems (Deutz F3L912-Powered Units) 803 658 tools/ maintenance label for oil/filter change To replace secondary fuel filter: Stop engine and let cool. allen_wrench allen_set flathead philips head wrench crescent wrench information.

  • Page 55: Overload Protection (Deutz F3L912-Powered Units)

    � Complete Parts List is available at www.MillerWelds.com 9-9. Overload Protection (Deutz F3L912-Powered Units) Stop Engine. � When a supplementary protector, cir- cuit breaker or fuse opens, it usually in- dicates a more serious problem exists. Contact Factory Authorized Service Agent.

  • Page 56: Section 10 - Troubleshooting

    � Complete Parts List is available at www.MillerWelds.com SECTION 10 – TROUBLESHOOTING 10-1. Troubleshooting A. Welding Trouble Remedy No weld output; generator power out- Check position of Ampere Range switch. put okay at AC receptacles. Check position of optional Polarity switch. Place Amperage Adjust switch in Panel position, or place switch in Remote position and connect re- mote control to Remote Amperage Adjust receptacle RC13 (see Sections 5-10 and 6-1).
  • Page 57 � Complete Parts List is available at www.MillerWelds.com Trouble Remedy Reset supplementary protector CB12. Have Factory Authorized Service Agent check diode D1. Have Factory Authorized Service Agent check brushes and slip rings, and field excitation circuit. High output at generator power AC Check engine speed, and adjust if necessary.

  • Page 58: Section 11 - Parts List

    SECTION 11 – PARTS LIST A. Recommended Spare Parts Reccomended Spare Parts Item Part No. Description Quan- Dia. Mkgs. tity F1, F2 085874 Fuse, Mintr Cer Slo-blo 10. Amp 250 Volt 190823 Brush, Contact Elect .250 X.500 X 1.250 Grd Ay ♦192939 Filter, Air Element Safety 246988...
  • Page 59 Notes...

  • Page 60: Section 12 - Electrical Diagrams

    SECTION 12 – ELECTRICAL DIAGRAMS Figure 12-1. Circuit Diagram For CC Welder/Generator (Deutz D2011L04i-Powered Units) OM-4428 Page 56...
  • Page 61 OM-4428 Page 57...
  • Page 62 Figure 12-2. Circuit Diagram For CC Welder/Generator (Deutz F3L912-Powered Units) OM-4428 Page 58...
  • Page 63 OM-4428 Page 59...

  • Page 64: Section 13 - Run-In Procedure

    SECTION 13 – RUN-IN PROCEDURE NOTICE – Diesel engines in Miller equipment are meant to operate optimally at moderate to rated load. Using light or no load for extended peri- ods of time may cause wetstacking or other engine damage. Do not idle engine longer than necessary.

  • Page 65: 13-2. Run-In Procedure Using Load Bank Or Resistance Grid

    13-2. Run-In Procedure Using Load Bank Or Resistance Grid Stop engine. Connect load bank or resistor grid to gener- For Resistance Grid ator Side A weld output terminals using Do not touch hot exhaust pipe, en- Set grid switches and then adjust gener- proper size weld cables with correct connec- gine parts, or load bank/grid.

  • Page 66: Section 14 - Generator Power Guidelines

    SECTION 14 – GENERATOR POWER GUIDELINES � The views in this section are intended to be representative of all engine-driven welder/generators. Your unit may differ from those shown. 14-1. Selecting Equipment 1 Generator Power Receptacles – Neutral Bonded To Frame 2 3-Prong Plug From Case Grounded Equipment 3 2-Prong Plug From Double Insulated...
  • Page 67 14-3. Grounding When Supplying Building Systems 1 Equipment Grounding Terminal 2 Grounding Cable GND/PE Use #8 AWG or larger insulated copper wire. 3 Ground Device � Use ground device as stated in electri- cal codes. Ground generator to system earth ground if supplying power to a premises (shop,...
  • Page 68 14-5. Approximate Power Requirements For Industrial Motors Industrial Motors Rating Starting Watts Running Watts Split Phase 1/8 HP 1/6 HP 1225 1/4 HP 1600 1/3 HP 2100 1/2 HP 3175 Capacitor Start-Induction Run 1/3 HP 2020 1/2 HP 3075 3/4 HP 4500 1400 1 HP...
  • Page 69 14-7. Approximate Power Requirements For Contractor Equipment Contractor Equipment Rating Starting Watts Running Watts Hand Drill 1/4 in. 3/8 in. 1/2 in. Circular Saw 6-1/2 in. 7-1/4 in. 8-1/4 in. 1400 1400 Table Saw 9 in. 4500 1500 10 in. 6300 1800 Band Saw...

  • Page 70: Power Required To Start Motor

    14-8. Power Required To Start Motor 1 Motor Start Code 2 Running Amperage 3 Motor HP 4 Motor Voltage AC MOTOR VOLTS AMPS Step 1: Find code and use table to find kVA/ CODE HP. If code is not listed, multiply running am- PHASE perage by six to find starting amperage.
  • Page 71 14-10. Typical Connections To Standby Power 1. Utility Electrical 2. Transfer Switch 3. Fused Disconnect 4. Welder/Generator Service Switch (If Required) Output 5. Essential Loads Have only qualified persons perform 1 Utility Electrical Service 4 Welder/Generator Output these connections according to all 2 Transfer Switch (Double-Throw) Generator output voltage and wiring must applicable...

  • Page 72: Selecting Extension Cord (Use Shortest Cord Possible)

    14-11. Selecting Extension Cord (Use Shortest Cord Possible) A. Cord Lengths For 120 Volt Loads Use GFCI protection when operating auxiliary equipment. If unit does not have GFCI receptacles, use GFCI-protected extension cord. Do not use GFCI receptacles to power life support equipment. Maximum Allowable Cord Length In ft (m) for Conductor Size In AWG (mm Current (Amperes)
  • Page 73 Notes...
  • Page 74 Notes...
  • Page 75 Effective January 1, 2023 (Equipment with a serial number preface of ND or newer) This limited warranty supersedes all previous Miller warranties and is exclusive with no other guarantees or war- ranties expressed or implied. � CoolBelt, PAPR Blower, and PAPR Face...

  • Page 76: Owner's Record

    Appleton, WI 54914 USA tact your distributor and/or equipment manu- facturer’s Transportation Department. International Headquarters–USA USA Phone: 920-735-4505 USA & Canada FAX: 920-735-4134 International FAX: 920-735-4125 For International Locations Visit www.MillerWelds.com ORIGINAL INSTRUCTIONS – PRINTED IN USA © Miller Electric Mfg. LLC 2023-05...
