Process Quick Start Guide
Trailblazer and Big Blue
®
1. Registration – Be sure to register your product at www.Millerwelds.com/support/product-registration.
2. Operator's Manual – Take out the operator's manual from the bag stored inside the service door. Refer to your operator's manual
for specific installation instructions.
3. Exhaust – The exhaust pipe and mounting bracket with hardware are packaged with the owner's manual. Install these compo-
nents using a 1/2" combination wrench.
4. Wireless Interface Control Remote (for Wireless Interface Control models only) – Remove the handheld remote package stored
inside the welder and set aside. This is already paired with your new machine and ready to use.
5. Battery – The welder is shipped without the negative battery cable attached. Secure the negative battery cable to the negative
battery terminal through the side door using a 1/2" combination wrench.
• The battery on Big Blue models 500A and above is accessed by removing the battery access panel on the back side of the
welder. This will require a 1/2" combination wrench. These Big Blues also contain a battery disconnect switch which is
accessed from the side panel of the machine. This switch must be turned to the ON position prior to operation. See the owner's
manual for more information.
6. Oil – Check the oil level. The unit is shipped with oil so the addition of oil is not necessary on new welders/generators.
7. Fuel – Add fresh fuel to the welder and be sure to not overfill. See owner's manual for best fueling practices.
8. Coolant (Big Blue's Only) – Check the coolant level on overflow/recovery tank from the access panel on top of the welder. The unit
is shipped with coolant so the addition of coolant is not necessary on new welders.
9. Air Compressor Oil (Air Pak models only) – Check the air compressor oil gauge as described in the owner's manual. This unit is
shipped with air compressor oil so the addition of oil is not necessary on new welders. See owner's manual for more details on
the air compressor system.
10. Installation Location – Verify 18" of clearance on each side and the top of the unit to ensure proper airflow for cooling.
• Mount welder – Secure the welder to a rigid frame by fastening bolts through the four mounting holes on the base of the unit.
• Big Blues can also have mounting brackets welded. See the Installation section of the owner's manual for instructions.
• Electric Shock Protection – Ground the welder to the truck or trailer if applicable (ground cable not supplied). Detailed
instruction available in the owner's manual.
11. Attach welding cables/connectors to the output terminals – Be sure that the weld cables/connectors makes direct contact
with the copper bar on the output
welder/generators
®
