Pentair RAINBOW 320 Manual

Features:
• No special venting required.
• Completely enclosed-no escaping gases.
• Positive external no-clog control valve.
• When used with timer, feeder is designed to
automatically lower the water level so tablets are not
soaking during off period of pump. This allows more
efficient use of tablets.
YOUR LIFEGARD
BUT IT CAN ALSO BE DANGEROUS TO YOU AND YOUR EQUIPMENT. PLEASE FOLLOW INSTRUCTIONS EXACTLY AND
HEED ALL CAUTIONS. YOUR SAFETY AND THE PROTECTION OF YOUR EQUIPMENT IS OUR FIRST CONCERN.
It is important to read all information BEFORE proceeding with the installation. The
information will guide you in installing your feeder properly and to avoid problems due to
improper installation.
IF YOUR POOL OR SPA HAS COPPER PLUMBING . . . STOP!!
Never install the feeder into copper plumbing as pipe damage will occur. (See Equipment
Safety CAUTION sheet enclosed). NOTE: If heaters are used, a Fireman's Switch or
equivalent must be installed to prevent possible damage and improper operation of Check
Valve and other equipment subject to heat damage.
INSTALLATION INSTRUCTIONS MODEL #320
Note: Make sure all pumps and timer switches are in the OFF position.
WHERE TO INSTALL YOUR FEEDER
The #320 feeder is designed for permanent installation in the return line of your new pool or
spa and must always be installed after the heater, pool cleaner, valves, etc. If your pool does
not have a heater, then it must be installed after the filter or any other piece of equipment.
DAMAGE TO THE HEATER AND OTHER EQUIPMENT COULD RESULT IF HIGHLY
CHLORINATED WATER FLOWS THROUGH IT.
If your pool is equipped with a solar system it may be necessary to install a HI FLOW KIT.
This kit can be installed if your feeder is not getting adequate flow and/or pressure through
the system. Refer to information on sheet enclosed. Your feeder may be installed in
existing PVC plumbing but will require a union and/or other fittings. The feeder comes
complete for installation with 2" or 1½" PVC plumbing. Choose a site in the return line
where feeder can be installed in a vertical position. Always install as far from any metal
equipment as practical since fumes, etc. can corrode them. If optional corrosion resistant
check valve is required refer to installation instructions before next step.
BASIC PLUMBING INSTALLATION INSTRUCTIONS
2" OR 1½" PVC PIPE: If feeder is being installed on a pool, spa or pool/spa combination,
correct plumbing procedures must be followed to insure proper flow through feeder. If pool or
spa is plumbed with 2" PVC pipe, be certain the pump, filter and heater all have 2" inlet and
outlet fittings. If any part of the equipment has less than 2" fittings or pipe, then a minimum
of 6" x 1½" reducer bushings must be installed directly into the inlet side of the feeder using
the 2" x 1½" reducer bushings supplied. This will build pressure directly into the feeder
insuring proper operation. Continue with 2" PVC pipe on the outlet side of the feeder.
POOL/SPA COMBINATION: If plumbing and equipment is a full 2" and the feeder is being
installed on the pool return line after the diverter valve, with a portion of the water diverted to
the spa, install a minimum section of 6" x 1½" PVC pipe directly into the inlet side of the
feeder using the 2" x 1½" reducer bushing supplied. Continue with 2" PVC pipe on the outlet
side of the feeder. This will compensate for that portion of water being diverted to the spa.
90° ELBOWS: Plumbing a 90° elbow directly into the inlet side of the feeder may cause
turbulence inside the elbow. This will prevent water from being scooped into the feeder. A
minimum of a 6" length of PVC pipe should be installed between the 90° elbow and the
inlet side of the feeder.
2" PVC: Simply glue feeder to the return line using PVC SOLVENT CEMENT. Be sure
arrows on feeder point in the direction of water flow returning to the pool or spa.
1½" PVC: Remove (2) 2" x 1½" slip reducer bushings packed inside the feeder and glue into
2" slip tee on bottom of feeder. Complete installation by gluing into 1½" return line making sure
the arrows on feeder point in the direction of water flow returning to the pool or spa. Use only
PVC SOLVENT CEMENT. Follow directions on solvent cement label. Allow to dry. Installation
in now complete.
OPERATING INSTRUCTIONS
Before start up of feeder, your pool should be properly conditioned and the residual should
be 1.0 to 1.5 ppm. The water in a newly-filled pool should be properly conditioned to insure
maximum effectiveness of the feeder. Consult your local dealer for water conditioning
information for your area.
1. Remove cap of feeder and fill with proper size tablets.
For Pools: 1" or 3" dia. tablets For Spas: 1" dia. tablets in optional Spa Chamber.
2. Making sure O-ring is clean, lubricated with Lifegard Silicone and is an in place,
replace cap. Hand tighten only.
3. Turn on pump and timer switches for a minimum of 6 to 8 hours.
4. Adjust control valve according to your pool/spa size. Use a test kit to determine the
READ CAREFULLY
This feeder is designed to use only CLEAN Trichlor-s-trizinetrione OR CLEAN Bromine tables - slow dissolving type. Never use dirty tablets. UNDER NO CIRCUMSTANCES MIX
Trichlor or Bromine with Calcium Hypochlorite, with other forms of concentrated chlorine or with other chemicals. Keep inside of feeder clean of dirt and debris at all times.
FIRE AND/OR EXPLOSION MAY RESULT.
NEVER use oils or grease to lubricate o-ring. Oil in contact with Trichlor OR Bromine may result in FIRE. Lubricate o-ring with Lifegard Silicone o-ring Lubricant ONLY, available at
your dealers. If shock treatments or Algaecides containing chemicals other than sanitizers tablets in feeder must be used, turn off Feeder OR remove tablets until the shock or Algae
treatment is complete and all granules have dissolved. Failure to do so may result in granules mixing in feeder causing FIRE AND/OR EXPLOSION. The shock or algae treatment
dissolved in water is safe with tablets. If you are not the original owner of this feeder, not sure which chemicals was used, or if dirt and/or debris inside feeder, be SAFE and flush
thoroughly with fresh water. CAUTION SHOULD BE USED WHEN REMOVING CAP. DO NOT INHALE FUMES.
CALCIUM HYPOCHLORITE IS NOT TO BE USED IN ANY FORM. Use of chemicals other than listed by manufacturer may be hazardous.
© 2015 Pentair Water Pool and Spa, Inc. All rights reserved. Sanford, NC Moorpark, CA Chino, CA www. pentairpool.com
RAINBOW
™
MODEL #320 -
® FEEDER IS THE MOST EFFICIENT AND TROUBLE-FREE AUTOMATIC FEEDER YOU CAN BUY,
D A N G ER
C H L O R N I E B /
(* Using Bromine tablets with this device is not NSF certified)
• No equipment damage.
Feeds sanitizer directly to pool or spa.
• All parts replaceable.
• To prevent over chlorination during use, completely
completely close the control valve and the built
in check valve will prevent chemical from being
fed into pool or spa.
chemical residual. It is recommended that the chemical residual be checked daily for the
first 5 days. Remember . . . hot days, higher water temperature or increased pool/spa
activity will cause your pool/spa to use more sanitizer. When possible, increase the feed
rate a day or two in advance. Because the chlorine demand in your pool/spa varies and is
dependent on many factors (sunlight, bather load, water temperature, etc) your valve
setting may have to be changed from time to time to adjust to these conditions. For
example, the winter setting may be #2 while the summer setting is #3. Check the chlorine
residual daily to find the ideal setting. Note: Higher numbers dispense more chemical.
Small gradual changes are imperative for control.
HOW TO RECHARGE FEEDER
1. Turn control valve to the closed position. SHUT OFF PUMP.
2. Wait one minute. This will allow water and fumes to drain from feeder.
3. Leave control valve closed and turn on pump. The check valve will prevent water from
entering the feeder.
4. Remove cap and fill with proper size tablets or sticks. (See Operating Instructions #1)
5. Making sure O-ring is clean, lubricated with Lifegard silicone and is in place, replace
cap. Hand tighten only.
6. Open control valve to original setting. Inspect inlet line below control valve each time
feeder is recharged. Replace lines yearly if necessary.
SPECIAL FEATURES AND INSTRUCTIONS
If while using 3" diameter tablets the #320 feeder does not provide enough chlorine
residual, switch to 1" tablets. The smaller tablet will erode faster producing more chlorine
residual. If this does not correct the situation, the #320 has been fitted with an optional
opening at the top of the feeder (which is plugged). To accommodate attachment of the valve
and tubing assembly for top entry of water into the feeder, an additional length of tubing has
been included. The following procedure should only be used if the suggested change has not
solved the situation. Top entry in normal situations can cause over chlorination.
1. Turn off pump and timer switches.
2. Remove tubing by unscrewing compression nut at each end of tubing.
3. Remove plug at top of feeder directly above control valve.
4. Remove control valve. If nipple stays in valve, carefully remove by using pliers at the
center of nipple. There is no need to remove the 90° tube fittings.
5. Wrapplug with 2 or 3 wraps of threaded tape in opposite direction of tightening. Screw into
opening where control valve was attached. Hand tighten plus 2 or 3 turns. Do not overtighten.
6. Wrap threads of nipple with threaded tape.Thread nipple into top opening. Finger tighten
only. Thread valve onto nipple. After nipple starts to turn from tightening valve, 2 to 3 more
turns is enough. The nipple or valve can be broken by overtightening.
7. Slide compression nut over long section of tube. Slide tube over tapered part of 90°
tube fitting and tighten. Hand tighten only. Repeat for other end of tubing.
8. Set control valve to #1. Turn on pump and timers. Check residual daily to determine
proper setting. Small gradual changes are imperative for control.
BELOW WATER LEVEL INSTALLATION
Feeder should be installed above water level whenever practical. If installed below water
level, a drain valve must be installed to prevent spillage and dangerous splash back of high
chlorinated water during recharging. Drill and tap a ¼" MPT hole at the same level the
control valve is located. Make sure there is no water or tablets inside the feeder before
drilling. Install optional drain valve, Part R172060, or suitable chemical resistant drain valve.
BELOW WATER LEVEL RECHARGING INSTRUCTIONS
1. Shut off pump and timer switches.
2. Shut off control valve.
3. Place a clean container under drain and open drain valve.
4. Exercise extreme caution when opening or servicing feeder. Do not inhale fumes.
Wear protective gear. Remove cap. Water will now drain from feeder. Empty container back
into pool or spa.
5. Close drain valve. fill with proper size tablets or sticks.
6. Making sure O-ring is clean, lubricated with Lifegard Silicone and in in place, replace cap.
7. Turn on pump and timer switches.
8. Reset control valve to original setting. Inspect inlet and outlet line each time feeder
is recharged. Replace lines yearly if necessary.
• •
R O M N I E * FEEDER
P/N R24290.F 2/15
•
