INSTALLATION AND SERVICE MANUAL
FS-18, HIGH VOLUME FREE STANDING
FOUNTAIN DRINK DISPENSER
Part Number 85-10018-125, 115 Volts, 60 Hz
SPECIFICATIONS
DIMENSIONS
Width
Depth
Height
To Countertop
To Top of Shroud (Front) 67 inches (170.2 cm)
To Top of Shroud (Rear) 61.625 inches (156.5 cm)
WEIGHT
Shipping
Empty
Operating
ELECTRICAL
Operating Voltage
Hertz
Amps
This manual supersedes 28-0541, dated 01/13/03.
• NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 •
• LATIN AMERICA – 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 •
"Lancer" is the registered trademark of Lancer • Copyright — 2004 by Lancer, all rights reserved
Please refer to the Lancer web site (www.lancercorp.com) for
information relating to Lancer Installation and Service Manuals,
Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
FOR THE
FLAVORSELECT
36 inches (91.4 cm)
36 inches (91.4 cm)
36 inches (91.4 cm)
570 pounds (259 kg)
545 pounds (248 kg)
895 pounds (407 kg)
115
60
20
6655 LANCER BLVD. • SAN ANTONIO, TEXAS 78219 USA • (210) 310-7000
FAX SALES
FAX ENGINEERING: • 210-310-7096
https://manual-hub.com/
DATE:
06/02/04
P.N.
28–0541/01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for lancer 85-10018-125
Summary of Contents for lancer 85-10018-125
- Page 1 • NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 • • LATIN AMERICA – 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 • FAX ENGINEERING: • 210-310-7096 DATE: 06/02/04 P.N. 28–0541/01 "Lancer" is the registered trademark of Lancer • Copyright — 2004 by Lancer, all rights reserved https://manual-hub.com/...
-
Page 2: Table Of Contents
All control is handled by the on board microprocessor controller. The FS-18 is designed to seamlessly interface with the Lancer Ice Link system to provide for a minimum of labor and maintenance by store personnel. -
Page 3: Installation
This is to provide for maximum flexibility and performance from all circuits and products. 2. Depending on the specific use volume at the installation, the use of either one or two Lancer Turbo Carbonators is recommended. Locations serving larger drink sizes and/or higher drink volume will require a second Turbo Carbonator. -
Page 4: Electric Power Supply
CLEANING AND SANITIZING INSTRUCTIONS A. GENERAL INFORMATION 1. Lancer equipment (new or reconditioned) is shipped from the factory cleaned and sanitized in accordance with NSF guidelines. This equipment must be cleaned and sanitized after installation is complete, and the operator of the equipment must provide continuous maintenance as required by this manual and/or state and local health department guidelines to ensure proper operation and sanitation requirements are maintained. -
Page 5: Periodic Maintenance, Checklist And Cleaning Guide
Small brush. d. Extra nozzle. e. Sanitary gloves. PERIODIC MAINTENANCE, CHECKLIST AND CLEANING GUIDE A. CLEANING AND SANITIZING THE LANCER FS-18 1. CLEANING PROCEDURE NOTE: This procedure should be accomplished on a daily basis, or more often (if required). -
Page 6: Cleaning And Sanitizing Beverage Components - Figal Systems
Fill Unit with ice and replace Top Cover. NOTE Lancer does not recommend the use of shaved, flake, nugget, or pellet ice in the dispenser. Dispenser will only operate properly with cube ice. m. Reconnect Dispenser to power source and check for proper functioning. -
Page 7: Cleaning And Sanitizing Beverage Components - Bag-In-Box Systems
WARNING TO AVOID POSSIBLE PERSONAL INJURY OR PROPERTY DAMAGE, DO NOT ATTEMPT TO REMOVE SYRUP TANK COVER UNTIL CO PRESSURE HAS BEEN RELEASED FROM TANK. J. Disconnect CO supply hose from the tank. K. Following the instructions as described in 2.1 above, mix appropriate amount of sanitizing solution. -
Page 8: How To Operate The Lancer Fs-18
Lancer representative, or consult the FS-18 Training Manual. 1. The Lancer FS-18 is equipped with a serial communication port to facilitate set up and maintenance. 2. Access to the internal functions is available through the use of a Palm Pilot Hand Held computer along with software available from Lancer. -
Page 9: Troubleshooting Guide
C. ADJUSTMENTS AND RECOMMENDED SETTINGS 1. ICE MENU a. AUGER SPEED MENU The FS-18 features variable speed ice delivery. The speed is pre-set by selecting a setting from 1 (slowest) to 10 (fastest) on the drop down menu. The other speed adjustment (STIR) is for the auger stir speed and it also requires a setting of 1 through 10. -
Page 10: Illustrations, Parts Listings, And Wiring Diagrams
5. ILLUSTRATIONS, PARTS LISTINGS, AND WIRING DIAGRAMS VALVE AND NOZZLE ASSEMBLY, FS-18 NOTE: PLUMBING SHOWN MAY NOT BE REPRESENTATIVE OF PLUMBING ACTUALLY INSTALLED Item Part No. Description Item Part No. Description 08-0105 Tubing, B44-4X, 1/4 (ID) x 0.063 19-0262 Valve Assy, LFCV, 0.2, Syrup (Wall) Injection, White 54-0289... -
Page 11: Bin Assembly, Fs-18 (For Units Manufactured Before January 2004)
BIN ASSEMBLY, FS-18 (FOR UNITS MANUFACTURED BEFORE JANUARY 2004) Item Part No. Description 10-0442 Shaft, Agitator, Upper 02-0406 Seal, Shaft, Motor, MB18 10-0532 Pin, 5/16” 03-0368 Clip 82-1568 Wheel 05-1833 Shroud, Wheel, Rear 05-1962 Cap, Bearing 05-1960 Bearing 10-0445 Pin, Bearing, Shaft 10 05-1961 Housing, Bearing 11 81-0475... -
Page 12: Bin Assembly, Fs-18 (For Units Manufactured In January 2004 Or Later)
BIN ASSEMBLY, FS-18 (FOR UNITS MANUFACTURED IN JANUARY 2004 OR LATER) Item Part No. Description 82-3463 Agitator Assy 02-0556 Seal, Shaft, Motor 10-0718 Pin, 3/8” 03-0368 Clip 05-2277 Bushing, Locator Wheel 05-2253 Shroud, Distributor, Ice 05-2270 Wheel, Ice, Dispenser 81-0475 Wheel Caster, with Brake 10-0445 Pin, Bearing, Shaft... -
Page 13: Nozzle Assembly, Fs-18
NOZZLE ASSEMBLY, FS-18 Item Part No. Description 54-0289 Nozzle Assy, Multi-Flavor 02-0231 O-Ring, Nozzle Outer 02-0214 O-Ring 05-1612 Fitting, Multi-Flavor Nozzle 02-0005 O-Ring 01-0012 Adapter, 1/4 Barb x Dole https://manual-hub.com/... -
Page 14: Tower Assembly, Fs-18
TOWER ASSEMBLY, FS-18 TYPICAL - 5 PLACES (TYPICAL, 9 PLACES) (TYPICAL, 30 PLACES) (TYPICAL, 78 PLACES) (TYPICAL, 48 PLACES) 14 15 16 17 Item Part No. Description Item Part No. Description 82-2878 Foam Assy, Tube Pack 12 48-1784 Tube Assy, #2 Injection 54-0289 Nozzle Assy, Multiflavor 13 48-1785... -
Page 15: Solenoid Assembly, Ice Door, Fs-18
SOLENOID ASSEMBLY, ICE DOOR, FS-18 Item Part No. Description 04-1089 Screw, 10 - 32 x 1.000 04-0320 Screw, 8 - 32 x 0.187 30-9263 Bracket, Mount, Solenoid 12-0195 Solenoid, D-90, 32VDC 23-1029 Plunger Assy 03-0110 Spring, Solenoid 04-0328 Washer, Flat, Neoprene 04-0327 Washer, Flat, 0.060T x 0.195 ID x 0.439 OD... -
Page 16: Shroud Assembly, Exterior View, Pn 82-3359, Fs-18
SHROUD ASSEMBLY, EXTERIOR VIEW, PN 82-3359, FS-18 NOTE: CONTACT LANCER CUSTOMER SERVICE FOR MOST CURRENT GRAPHICS, BRAND, AND FLAVOR LABELS Item Part No. Description 12-0476 Switch, Membrane, 3R, ADA 12-0501 Switch, 3 Products, ADA 12-0477 Switch, Membrane, 3L, ADA SHROUD ASSEMBLY, INTERIOR VIEW, PN 82-3351, FS-18 Item Part No. -
Page 17: Access Panels, Fs-18 (For Units Manufactured Before January 2004)
ACCESS PANELS, FS-18 (FOR UNITS MANUFACTURED BEFORE JANUARY 2004) NOTE: VALVES AND NOZZLES NOT SHOWN FOR CLARITY Item Part No. Description 30-8036 Panel, Tower, Right 05-1918 Shield, Ice, Right 05-1857 Shield, Ice, Left 05-2013 Stop, Ice Level 51-5765 Panel, Splash Assy 30-8037 Panel, Tower, Left 30-8038... -
Page 18: Access Panels, Fs-18 (For Units Manufactured In January 2004 Or Later)
5.10 ACCESS PANELS, FS-18 (FOR UNITS MANUFACTURED IN JANUARY 2004 OR LATER) NOTE: VALVES AND NOZZLES NOT SHOWN FOR CLARITY Item Part No. Description 30-9050 Panel, Tower, Right 05-1918 Shield, Ice, Right 05-1857 Shield, Ice, Left 05-2013 Stop, Ice Level 51-5765 Panel, Splash Assy 30-9051... -
Page 19: Motor Assemblies, Fs-18
5.11 MOTOR ASSEMBLIES, FS-18 Item Part No. Description 82-3486 Motor Assy, Agitator 82-3367 Power Supply Assy, 115V 82-3044 Drip Tray Assy, Foamed 23-1191 Cup Rest 27-0073 Tube, Auger 05-1834 Adapter, Ice Chute 51-5698/01 Frame, Tower 82-2990 Auger Assy 82-2975/01 Motor Assy, Auger R 10 04-1428 Nut, 1/4 - 20, Knurled, Thumb... -
Page 20: Pcb Assembly, Pn 2729/01, Fs-18
5.12 PCB ASSEMBLY, PN 52-2729/01, FS-18 ICE LEVEL SENSORS (NOTE: THESE ITEMS NOT AVAILABLE ON SOME MODELS) MULTI-DROP BUSS - SLAVE PORT (1) P201 PALM PILOT INTERFACE CONNECTION 7ItemPart No. Description 52-2729/02 PCB Assy, FS-18 52-2386 Wire Assy, Power Relay 52-2383 Ribbon Wire Assy, to J324 Left, Interconnect Board Inside... -
Page 21: Injection Manifolds, Fs-18( Manufactured In May 2004 Or Later)
5.13 INJECTION MANIFOLDS, FS-18 (MANUFACTURED IN MAY 2004 OR LATER) INJECTION MANIFOLDS (MANUFACTURED IN MAY 2004 OR LATER) (NOTE: View added in Revision 01) https://manual-hub.com/... -
Page 22: Front Of Unit
5.14 PLUMBING DIAGRAM - INLETS AND VALVE LOCATIONS (FOR UNITS MANUFACTURED (FOR UNITS MANUFACTURED IN JANUARY 2004 OR LATER) IN DECEMBER 2003 OR EARLIER) RIGHT SIDE OF UNIT INJECTION FLAVORS INJECTION FLAVORS BACK SIDE OF UNIT RIGHT SIDE OF UNIT WATER 5 WATER 3 WATER 2... -
Page 23: Plumbing - Front Panel To Inlet Map
5.15 FS-18 PLUMBING - FRONT PANEL TO INLET MAP https://manual-hub.com/... -
Page 24: Wiring Diagram, Fs-18
5.16 WIRING DIAGRAM, FS-18 INTERCONNECT BOARD INTERCONNECT BOARD AUGER MOTOR DOOR SOLENOID 115VAC IN TO VALVE MODULES POWER SUPPLY ASSEMBLY AGITATOR MOTOR GRND TRANSFORMER RANCO ELECTRONIC AGITATOR TEMPERATURE RELAY CONTROL TO ICE MAKER W R W (CURTAIN SWITCH) 115V BREAKER LIGHT PLUGS INTO R AGITATOR MOTOR RELAY...
