Tracking 3D Scanner
TrackScan Series
User Manual
V1.3.6
2022.10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TrackScan Series and is the answer not in the manual?

Questions and answers

Related Manuals for Scantech TrackScan Series

Summary of Contents for Scantech TrackScan Series

  • Page 1 Tracking 3D Scanner TrackScan Series User Manual V1.3.6 2022.10...
  • Page 2 Hangzhou SCANTECH COMPANY won’t make any representations, warranties or implied, regarding the contents of this manual. Hangzhou SCANTECH COMPANY will do the best to guarantee the accuracy and completeness of the information in the manual,but the express statement does not represent any commitment of Hangzhou SCANTECH COMPANY.

  • Page 3: Introduction

    Introduction Please read user manual before start. After reading, keep it safely for next time review. Basic Label This manual will use the following labels to describe different significance, so please red carefully and make sure understand all of labels. Fail to obey the announcement will cause dangerous situation or Danger injuries and deaths.

  • Page 4: Please Use It Correctly

    Please use it correctly To avoid malfunction of the KSCAN series and to ensure proper use, please observe the following precautions. Normal Announcement  Before starting work, please confirm the function and performance of this product, and the equipment can operate normally.

  • Page 5: Operation Announcement

    Operation Announcement  Please choose the correct power supply voltage. Otherwise malfunction will cause failure or fire. Warning  Please do not disassemble or modify the unit. Otherwise malfunction will cause failure or fire.  In order to use this product properly and safely, please try to avoid the following places, otherwise it may cause malfunction.

  • Page 6: Accident Announcement

    Accident Announcement  Turn off the power immediately when the following phenomenon occurs. If you continue to use it, it may cause equipment failure. Attention  Water or foreign matter inside the device；  The device is dropped, or the casing is damaged; ...

  • Page 7: Notes On Regulations And Standards

    Notes on Regulations and Standards Safety Announcement The laser wavelengths of the TrackScan series are as follows: Type TrackScan Series Blue wavelength 450nm Red wavelength 660nm According to the ICE60825-1, the laser grade of KSCAN series used is Class II.

  • Page 8: System Maintenance Manual

    Storage temperature: 5 to 55 degrees C Operating temperature: -10 to 40 degrees C Humidity: Relative humidity 10 to 90% (no condensation). Warning: Do not open any components using SCANTECH technology. Daily use  Always use the equipment in a clean, dry environment ...
  • Page 9 Metal and plastic parts Clean the device with a small amount of water or soap in a soft cotton cloth. Note: Do not use solvents to clean the device. Optical components By injecting dry air, remove all particles that may scratch the objective and light source Clean the objective and light source with a damp cloth, such as a frictionless optical or microfibre rag.

  • Page 10: Table Of Contents

    2. Dip the cotton swab into a diluted soap (do not use alcohol). 3. Gently wipe the target point (do not wipe the target point hard). 4. Place the microfibre towel or paper towel on the target point and gently dry the target point (do not wipe the target point hard).
  • Page 11 4.1 Calibration ......................16 4.2 Scanning laser patch (points) ................. 22 5 Cautions ........................23...

  • Page 12: Introduction To Tracking 3D Scanners

    1 Introduction to Tracking 3D Scanners The camera of the TrackScan 3D scanner can obtain the laser projected onto the scanned object, the laser deforms with the shape of the object, and as the camera is accurately calibrated in advance, it is possible to calculate the linear 3D information projected by the laser line;...

  • Page 13: Precautions Before Using

    2 Precautions before using This chapter provides a brief description of the scanner’s product configuration, product structure and device connection. 2.1 Product configuration The following is a brief introduction to relevant product names and other information. The specific configuration,please refer to the packing list. Product introductions: （1）...
  • Page 14 （3） Calibration Board：It is mainly used to calibrate the camera parameters. In order to ensure good data quality, camera calibration is performed using a quick calibration plate before the scanner is started or when temperature changes or poor scan data quality occurs.
  • Page 15 （6） Power adapter: Connects to relay box to provide external power. As shown in Figure 2-6. 2- 6 Power Adapter （7） Mark point box：Totally have 24pcs transfer mark points.As shown in Figure2-7。 2- 7 markpoint （8） Probe：The probe for TrakScan,As shown in Figure2-8。 2- 8 Probe （9）...

  • Page 16: Product Structure

    2.2 Product Structure （1） The product structure is shown in Figure 2-8. 2- 7 Product Structure ①-Back button; ②-Data cable Type B interface; ③-Data cable power interface； ④-Front Button；⑤-Data cable Type B interface; ⑥-Data cable power interface； ⑦-Data cable power interface+Type A interface； ⑧-Data cable power interface+Type A interface；...

  • Page 17: Tracker And Scanner Connection

    The function of all keys in the back button only works when the scanning Attention software is running. 2.3 Tracker and Scanner connection 1) Device connection includes connecting the tracking device power+data cable to the relay box and the scanner device power+data cable to the relay box. The power adapter is connected to the relay box and the USB cable of the relay box is connected to the computer.
  • Page 18 2- 9 Tracker Cascading Connection...

  • Page 19: Software Installation

    3 Software Installation This product requires the installation of the scanning software TViewer, the following is a description of the required operating environment and installation steps for the software. 3.1 Computer configuration requirements Scanning software for real-time processing of scanning data transmitted in real time during the scanning process, the selection of the appropriate hardware configuration can effectively improve the efficiency of the entire scanning system.

  • Page 20: Scanning Software Installation

    ①Please close all anti-virus software before software installation; Attention ②All software installations require administrator privileges. 3.2 Scanning software installation This section will scan the software TrackScanVX.XX.exe.installation package to install the computer steps to explain, here mainly to install to the Windows 10 system as an example to explain.
  • Page 21 3- 2 TrackScanVX.XX Installation Steps （3） Click "Install". As shown in Figure 3-3. 3- 3 TrackScanVX.XX Installation Steps （4） When the installation is finished,Click finish end the process.If you have installed the polyworks,it will show such tip as below,As shown in Figure 3-4.

  • Page 22: Software Uninstallation

    3- 4 TrackScanVX.XX Installation Steps （5） After clicking "Finish", a shortcut will be automatically created on the desktop. 3.3 Software Uninstallation If you want to uninstall or re-install the software, you can enter the software name in the Start menu to enter the uninstall procedure; go to "Control Panel - Uninstall a Program"...
  • Page 23 3- 6 Software Uninstallation （2） choose“repair”or“remove”，and click next。 3- 7 Software Uninstallation （3） Click remove，and click next。...
  • Page 24 3- 8 Software Uninstallation ） Afther the setup finished,it will shows as below,then click finished,the （4） SW installed successfully. 3- 9 Software Uninstallation...

  • Page 25: Software Operating Environment Settings

    3.4 Software operating environment settings After the installation, in order to ensure the use for software, you need to set the permissions for the software: run the scanning software with administrator privileges, set the scanning software to run with the graphics card. To grant administrator privileges: right-click the software icon, click "Properties", select the "Compatibility"...

  • Page 26: Manage Configurations File

    Select the graphics card to run: Right click on the desktop, select "NVIDIA Control Panel" in the menu, in the NVIDIA Control Panel, select "Manage 3D Settings" - " Program Settings" - "Preferred Graphics Processor for this Program" - select "High Performance NVIDIA Processor"...
  • Page 27 4.1 Calibration （1） Click on the tracker calibration and place the matching calibration bar into the tracking area (the bar is placed horizontally with the plane facing forward, as in picture 4-1), the arrow in the image shows the direction of the bar movement, align the grey bar with the white one until they turn green and move the bar position.
  • Page 28 （2） In step 13, the calibration bar is set vertically (refer to the calibration interface video) for calibration, as shown in Figure 4-2. 4- 2 Tracker calibration （3） In step 18 change the attitude of the calibration bar (refer to the calibration interface video, picture 4-3), point the tilt side up towards the tracker and start the calibration.
  • Page 29 （4） In step 21, change the attitude of the calibration bar (refer to the calibration interface video, picture 4-4) and start the calibration with the tilt side facing the tracker. 4- 4 Tracker calibration （4） In step 24 change the attitude of the calibration bar (refer to the calibration interface video, picture 4-5), point the tilt side up towards the tracker and start the calibration.
  • Page 30 4- 6 Tracker calibration （5） The display shows the calibration accuracy when the calibration is complete, as shown in Figure 4-7. 4- 7 Tracker calibration （6） Open the Fast Calibration Board, put the board in the direction of the arrow, place the board steadily in the tracking range and move it to the software specified position until the block turns green (Figure 4-8).
  • Page 31 4- 8 Scanner calibration （7） Click on Red Calibration or Blue Calibration in the interface to enter the scanner calibration interface, the red calibration interface is shown in Picture 4-9 and has 28 steps. When calibrating please note the video prompts for the scanner angle. 4- 9 Scanner calibration （8）...
  • Page 32 4- 10 Scanner calibration...
  • Page 33 4.2 Scanning laser patch (points) Befre scanning the laser patch (point), set parameters such as, resolution, exposure, scanning control etc. When scanning, watch the angle of the scanner (in the tracking range) and the distance between the scanner and the part, move the scanner steady and use the laser to collect the complete data.
  • Page 34 Cautions (1) Do not disconnect the power supply of the equipment during use; (2) he device must be connected with the USB3.0 port; (3) The device must be directly connected to the port on the pc and don't insert into a USB hub;...
  • Page 35 Manufacturer's Name: SCANTECH (HANGZHOU) CO., LTD Product name: AirGo Trade Mark: SCANTECH Model number: Airgo Power, Airgo Pro, Airgo ProII Operating Temperature: 0C ° to 40° C Remark:5150-5250MHz indoor use only. This device in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
  • Page 36 The host manufacturer has the responsibility that the host device should be compliance with all essential requirement of RED. This restriction will be applied in all member states. The simplified EU declaration of conformity referred to in Article 10(10) shall be provided as follows: Hereby. Advanced Technologies SRL declares that the radio equipment type Tablet PC is in compliance with Directive 2014/53/EU.
  • Page 37 To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum 20cm distance between the radiator and your body: Use only the supplied antenna. SCANTECH (HANGZHOU) CO.,LTD Building 12, No.998, Wenyi West Road, Yuhang District,Hangzhou, Zhejiang Province, China Tel: +86 571 85370380 https:// www.3d-scantech.com...
