- Page 1 NEVERTOUCH SE L F-E MP TY SHARKCLEAN APP Robot Vacuum cleaner RV2800YEEU SERIES, RV2800ZEEU SERIES, AV2800ZEEU SERIES...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS PLEASE READ CAREFULLY BEFORE USE • FOR HOUSEHOLD USE ONLY WARNING To reduce the risk of fire, electric shock, injury, or property damage: CHILDREN OR ANIMALS SHOULD NOT BE LEFT UNATTENDED IN ANY ROOMS THAT THE ROBOTIC VACUUM HAS ACCESS TO DURING CLEANING. LASER WARNING THIS PRODUCT HAS A CLASS 1 LASER.
- Page 3 (lighter your finger on the power switch. fluid, petrol, kerosene, paint, paint thinners, 30. Use only the SHARK charging dock and battery mothproofing substances, or flammable dust outlined in the table below. and use only c) In an area with a space heater battery RVBAT58002 (33V).
- Page 4 WHAT'S INCLUDED 1. Anti-Odour Cartridge (1X) 2. Side Brush (2X) Side brush design may very. Some models include a spare. Note: Not included on all models 3. Robot (1X) 4. Antimicrobial Mopping Pads (3X) 5. Ramp (1X) 6. NeverTouch Base (1X) s h a r kc l e a n .
- Page 5 SET-UP YOUR SHARK ROBOT & NEVERTOUCH BASE Insert Odour Cartridge Attach a Side Brush to Bottom of Robot Note: Not included on all models 1. The side brush can be Side Brush found inside the robot box. 2. Align the hole in the...
- Page 6 GETTING TO KNOW YOUR SHARK ROBOT Indicator Lights Front Bumper DRY CLEAN Button WET CLEAN Button Base Button LIDAR Module Robot Combo Dust Bin & Water Tank Release Button Cli Sensors Front Caster Wheel Battery Door Side Brush Ultrasonic Floor...
- Page 7 GETTING TO KNOW YOUR SHARK POWERDETECT NEVERTOUCH BASE Anti-Odour Cartridge Not included with all models. Clean Water Tank Lid Base Dust Bin Post-Motor Filter Access Door Clean Water Tank Indicator Light Debris Intake Pad Dry Fan Charging Contacts SELF-EMPTY BASE BACK...
- Page 8 GETTING TO KNOW YOUR SHARK POWERDETECT NEVERTOUCH PRO BASE Anti-Odour Cartridge Not included with all models. Grey (Dirty) Water Tank Base Dust Bin Post-Motor Filter Access Door Blue (Clean) Water Tank Indicator Light Debris Intake Pad Dry Fan Charging Contacts...
- Page 9 GETTING TO KNOW YOUR SHARK POWERDETECT NEVERTOUCH PRO BASE Grey (Dirty) Water Tank Blue(Clean) Water Tank s h a r kc l e a n . e u...
- Page 10 CAN’T CONNECT TO WI-FI? NOTE: If your POWERDETECT Base has enough water in Shark Robots use 2.4 GHz networks to connect. Typical the clean water tank and has a pad plate with mop home Wi-Fi netwroks support both 2.4 GHz and 5 GHz.
- Page 11 PREPARE YOUR HOME Your robot uses an array of sensors to navigate around walls, furniture legs, and other obstacles while it cleans. To prevent the robot from entering areas you don't want it to, set up no-go zones in the app. For best results, prepare your home as indicated below, and schedule a daily cleaning to ensure all floor areas are regularly maintained.
- Page 12 ROBOT BASE SET-UP 0.6m • Place the base with its back against a wall. Select a level surface on a BARE FLOOR in a central area with a strong Wi-Fi signal. Do not place it against baseboard heaters or other heating elements. Ensure the base is not placed in area with direct sunlight.
- Page 13 ROBOT INDICATOR LIGHTS Low Battery LEFT NOTIFICATION BATTERY WI-FI RIGHT LEFT LED pulsing RED Charging LEFT NOTIFICATION BATTERY WI-FI RIGHT BATTERY LED pulsing RED for low, YELLOW for medium, GREEN for high If your robot is low on battery power, the left LED light will pulse RED.
- Page 14 CHARGING IMPORTANT: Be sure to charge the robot completely before its first clean so that it can explore, map, and clean as much of your home as possible. It may take up to 4 hours* to fully charge your robot. To TURN THE ROBOT ON: Slide the robot up the ramp on to the base or hold down DOCK icon for 5 to 7 seconds, until the indicator lights turn on.
- Page 15 ROBOT BUTTONS DRY CLEAN BUTTON If the robot is on the base, press the DRY icon on the robot for a whole-home clean. Press again to pause the cleaning session. For a 1.5m x 1.5m spot clean, press and hold the DRY icon for 5-7 seconds.
- Page 16 Search for SharkClean in the app store and download the app to your smartphone.. SETTING UP VOICE CONTROL WITH THE GOOGLE ASSISTANT OR AMAZON ALEXA Visit sharkclean.eu/app for setup instructions, which include how to enable Shark Skill for Amazon Alexa and using with Google Assistant.
- Page 17 Open the Amazon Alexa app, go to the menu and select Skills. Or go to the Alexa Skills store on the Amazon website. Search for "Shark Skill". Select the Shark Skill to open the detail page, then select the Enable Skill option.
- Page 18 Wi-Fi isolation is turned o on the router. Note: Shark® robot vacuums cannot connect to 5GHz band. There may be instances where your Shark robot loses connectivity while operating, due to a weak Wi-Fi signal, or entering a zone that blocks Wi-Fi. In such cases: •...
- Page 19 USING THE SHARK POWERDETECT 3D SENSOR AND AI LASER NAVIGATION After setup is complete, your robot will conduct an The robot's object detection technology helps it Explore Run to create an initial map of your home. navigate around obstacles taller than 11.5cm in...
- Page 20 MAINTENANCE OVERVIEW NOTE: To order replacement visit sharkclean.eu. Component Frequency Replacement Part(s) Base Maintenance BEFORE PERFORMING ANY MAINTENANCE, TURN OFF POWER TO YOUR BASE BY UNPLUGGING IT FROM ITS POWER SOURCE. 4920KU2800WDEU Base Dust Bin Every 30 or 60 days, depending 4922KU2800WDEU NOTE: Capacity varies on the model...
- Page 21 MAINTENANCE OVERVIEW Component Frequency Replacement Part(s) Robot Maintenance BEFORE PERFORMING ANY MAINTENANCE, POWER OFF YOUR ROBOT. TO DO THIS, PRESS AND HOLD THE DOCK ICON ON THE ROBOT FOR 5-7 SECONDS. REMOVE THE ROBOT WATER TANK. Mop Pad NOTE: After a wet clean mission, the NEVERTOUCH PRO base 4918K2800WDEU will automatically wash the...
- Page 22 MAINTENANCE MAINTAINING THE BASE DUST BIN Depending on the size of the base, empty the base To empty the bin, hold it over the trash, then press dust bin every 30 to 60 days or as needed. the dustbin release button to empty. The bin lid will open, releasing dust and debris.
- Page 23 MAINTENANCE CAUTION: Turn off power before performing any maintenance. To turn the base power off, simply unplug it from the electrical outlet. CLEANING THE PAD PLATE TRAY With the ramp removed, you can access the pad plate tray. To clean the pad plate tray, wipe it down with a damp microfiber cloth.
- Page 24 MAINTENANCE MANUAL ROBOT INTERACTIONS CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. NOTE: With the self-emptying robot, these actions will not be required for regular maintenance. FILLING THE ROBOT WATER TANK Though the base will automatically refill the robot water tank, you can also access and fill it manually if needed.
- Page 25 MAINTENANCE EMPTYING THE ROBOT DUST BIN CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. NOTE: With the self-emptying robot, these actions will not be required for regular maintenance. Press the Dust Bin Release Button and slide the To open the robot dust bin lid, pinch and lift up dust bin out from the robot.
- Page 26 MAINTENANCE MAINTAINING THE WATER TANK(S) 1. It is recommended to clean the base clean water 1. The NEVERTOUCH PRO base includes a grey water tank before every refill, or once every 30 days. tank that collects and store dirty water after pad wash.
- Page 27 MAINTENANCE CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. CLEANING AND REPLACING THE MOP PAD After a wet clean mission, the NEVERTOUCH PRO base will automatically wash the robot mop pad. Regardless, it is recommended to clean the mop pad in the washing machine or replace the pad every three months or as needed.
- Page 28 MAINTENANCE CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. CLEANING THE ROBOT FILTER For optimal suction power, clean the filter inside the robot's dust bin. 1.
- Page 29 MAINTENANCE MAINTENANCE CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. CLEANING THE SENSORS CLEAN SENSORS AND CHARGING CONTACTS AS NEEDED.
- Page 30 MAINTENANCE CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. BRUSHROLL 1. To access the brushroll, push up on the tabs on the 2.
- Page 31 MAINTENANCE CAUTION: Turn off power and remove the robot’s water tank before performing any maintenance. To turn the robot power off, press and hold the DOCK icon on the robot for 5-7 seconds. CLEANING THE WHEELS 1. Rotate the front wheel while lightly brushing away 2.
- Page 32 UNDERSTANDING THE ROBOT USER INTERFACE If any lights are illuminated or flashing on your robot, refer to the chart below to understand why: LED COMBINATION FUNCTIONALITY Robot is booting up. ALL LEDS (WHITE) - FLASHING Robot finishes booting up and enters standby ALL LEDS (WHITE) - SOLID mode.
- Page 33 COMMON ERROR CODES If any error lights are illuminated or flashing on your robot, refer to the error code chart below: ERROR ERROR CODE SOLUTION NUMBER BATTERY LED (RED) Side brush is stuck. Remove any debris from + WIFI LED (RED) around the side brush so it moves freely.
- Page 34 REPLACEMENT PARTS NOTE: To order replacement visit sharkclean.eu REPLACEMENT PARTS: ROBOT Robot Dust Bin Brushroll Battery Brushroll Door Side Brush NeverTouch Base NeverTouch Base NeverTouch Clean Ramp Water Tank NeverTouch Pro NeverTouch Pro NeverTouch Pro NeverTouch Pro Base Base Ramp Clean Water Tank Grey Water Tank Base Dust Bin...
- Page 35 END-USER LICENSE AGREEMENT FOR SHARKNINJA SOFTWARE IMPORTANT: PLEASE READ THE TERMS AND CONDITIONS OF THIS LICENCE AGREEMENT CAREFULLY BEFORE COMMENCING USE OF THIS PRODUCT This End-User License Agreement (“EULA”) is a legal agreement between you and SharkNinja Operating LLC’s (“SharkNinja”, “us” or “we”) for [the]/[SharkNinja’s] computer software which is preinstalled on your SharkNinja device, which you download in order to control the SharkNinja device from your phone or computer, or, in either case, is made available by way of updates (the “Software”), as well as any printed, online or electronic documents related to the Software (the “Documentation”).
- Page 36 5. THIRD-PARTY APPLICATION LIBRARIES AND EMBEDDED SOFTWARE 5.1 You acknowledge that Ayla Networks, Inc. (“Ayla”) has provided certain application libraries that have been embedded into the Software (“Ayla Application Libraries”) and enables SharkNinja devices to connect to the Ayla Cloud Service (“Ayla Embedded Software”). 5.2 You must not use the Ayla Application Libraries except as an incorporated portion of the Software, unmodified from the form provided to you.
- Page 37 If you further agree to receive communications from us, you can also receive tips and advice on how to get the best out of your Shark appliance and hear the latest news about new Shark technology and launches.
- Page 38 Contact our customer service helpline on 0800 862 0453. For service hours please visit our website under ‘Contact Us’. It’s free to call, and you’ll be put straight through to a Shark representative. You’ll also find online support at support.sharkclean.eu . The Shark representative will go through some troubleshooting with you, and if we conclude that the item has failed, we will send you a replacement part or a returns label to send the defective item back to us free of charge.
- Page 39 Spezifikationen ohne Ankündigung vor. © 2024 SharkNinja Operating LLC. SHARK er et registreret varemærke i den Europæiske Union tilhørende SharkNinja © 2024 SharkNinja Operating LLC. SHARK ist eine in der Operating LLC. Europäischen Union eingetragene Marke der SharkNinja Operating LLC.
