- Page 1 Translated from original operating instructions manual PELLENC POWER TOOLS BATTERY 56_145276-G Operating instructions 04/2024 READ THE USER OPERATING GUIDE CAREFULLY BEFORE USE...
-
Page 3: Table Of Contents
2. SECURITY ..........................6 2.1. SAFETY MEASURES ASSOCIATED WITH THE USE OF THE TOOL ......... 2.2. SAFETY MEASURES ASSOCIATED WITH BATTERY USE ............2.3. SAFETY MEASURES WHEN USING THE "PELLENC" CHARGER ..........2.4. SAFETY SIGNS ..........................3. DESCRIPTION AND TECHNICAL FEATURES ..............10 3.1. - Page 4 PELLENC POWER TOOLS BATTERY 750 56_145276-G 8.1. BATTERY STORAGE CONDITIONS ..................... 8.2. CONDITIONS OF TRANSPORT OF THE BATTERY ..............9. ACCESSORIES AND CONSUMABLES ................28 9.1. OPTIONAL ACCESSORIES ......................10. WARRANTIES ........................29 10.1. GENERAL WARRANTIES ......................10.1.1. STATUTORY WARRANTY ......................
-
Page 5: Introduction
56_145276-G 1. INTRODUCTION Dear Customer, Thank you for purchasing your Pellenc power tools battery 750. Properly used and maintained, this equipment will give you years of satisfaction. Warning In accordance with product liability laws, we are not responsible for damage caused by our product if the product includes an accessory that is not from the manufacturer or is not approved by the manufacturer. -
Page 6: Security
• Battery alone: product that is classified as class 9, UN3480. 14. Use of a battery other than that provided by Pellenc SA is dangerous (risk of serious injury). If a different battery is used, Pellenc SA cannot be held responsible for any consequences. -
Page 7: Safety Measures When Using The "Pellenc" Charger
In the event of contact with eyes, seek professional medical help. The liquid leaking from the batteries can cause irritations or burns. 19. Pellenc power tools must only be used with the battery units designed for the purpose. Use of other battery units can present a risk of injury and fire. -
Page 8: Safety Signs
PELLENC POWER TOOLS BATTERY 750 56_145276-G 2.4. SAFETY SIGNS California State Proposition 65: Caution This product contains or emits a chemical recognized by the State of California to cause cancer, birth defects or other reproductive harms. IP54 protection rating: Protection... - Page 9 PELLENC POWER TOOLS BATTERY 750 56_145276-G Tool compliant with Moroccan Marking symbol for identifying standards. the chemical characteristic of the battery during recycling. The RBRC™ sticker (found on the packaging) indicates that PELLENC voluntarily participates in an industry program for the...
-
Page 10: Description And Technical Features
PELLENC POWER TOOLS BATTERY 750 56_145276-G 3. DESCRIPTION AND TECHNICAL FEATURES 3.1. DESCRIPTION Battery HMI (Human-Machine Interface) Tool power connector GUI navigation buttons Button for locking/unlocking the battery on its 10. Consumption statistics menu support 11. Maintenance menu Charge connector cap 12. -
Page 11: Technical Characteristics - Battery
PELLENC POWER TOOLS BATTERY 750 56_145276-G 3.2. TECHNICAL CHARACTERISTICS - BATTERY Nominal\battery voltage 43.2 V Type of battery 12 times 5 elements included in 1 pack Battery capacity 17.25 Ah Nominal power 745 Wh Battery life Depending on the tool Weight of the battery 4.5 kg... -
Page 12: Start-Up
PELLENC POWER TOOLS BATTERY 750 56_145276-G 4. START-UP 4.1. SWITCHING THE BATTERY ON AND OFF • Press one of the 2 On/Off battery buttons. 4.2. CHARGING THE BATTERY Important The battery must be fully charged (100 %) before being using for the first time in the new season. - Page 13 PELLENC POWER TOOLS BATTERY 750 56_145276-G Connect the charger power connector (20) to the electrical power outlet. Warning Before connecting the charger to the mains, make sure that your mains supply corresponds to the instructions on the charger (see 3.2.
-
Page 14: Hmi Display
PELLENC POWER TOOLS BATTERY 750 56_145276-G Charging is complete when the message 100% appears on the display. The charger LED lights up green and is static. All segments remain steady on the charge indicator as long as the charger is plugged in. -
Page 15: Quick-Fit Battery Attachment
PELLENC POWER TOOLS BATTERY 750 56_145276-G 4.4. QUICK-FIT BATTERY ATTACHMENT Note The procedure is the same regardless of the tool used. Only the media differs in the illustrations. 4.4.1. FITTING THE BATTERY Present the battery, see 4.5. Battery orientation, page 16. -
Page 16: Battery Orientation
PELLENC POWER TOOLS BATTERY 750 56_145276-G On the light harness, unlock the anti-unclip mechanism closest to the batter release button (2). Remove the battery. 4.5. BATTERY ORIENTATION The HMI display automatically orients itself based on the position of the battery. The push-button is also accessible... -
Page 17: Night-Time Signalization Mode
PELLENC POWER TOOLS BATTERY 750 56_145276-G 4.6. NIGHT-TIME SIGNALIZATION MODE The HMI display switches to night mode by simultaneously pressing the "-" and "+" buttons for 1 second. Note To deactivate the night signaling mode, simultaneously press and hold the - and + buttons for 1 second. -
Page 18: Using The Tool
PELLENC POWER TOOLS BATTERY 750 56_145276-G 5. USING THE TOOL 5.1. CHOICE OF MENU Reference number illustration Menu type Operating time menu, refer to 5.3. Useful life, page 20. Maintenance menu, refer to 5.4. Maintenance, page 21. Statistics menu, refer to 5.6. Statistics, page 23. -
Page 19: Selection Of The Tool Number
PELLENC POWER TOOLS BATTERY 750 56_145276-G 5.2. SELECTION OF THE TOOL NUMBER It is possible to see the data corresponding to each tool connected to the battery in each of the "tool" menus. For this, once you are in the menu (shown as ), select the number (from 1 to 30) corresponding to the type of tool you want to have information about using the (+) button. -
Page 20: Useful Life
PELLENC POWER TOOLS BATTERY 750 56_145276-G 5.3. USEFUL LIFE Reference number illustration Duration of use menu Partial useful life of the battery with the possibility of a reset (RTZ) Total useful life of the battery Time in use since last revision... -
Page 21: Maintenance
PELLENC POWER TOOLS BATTERY 750 56_145276-G 5.4. MAINTENANCE Reference number illustration Maintenance menu Battery software version. Total voltage of the battery Min. cell voltage Max. cell voltage Software version of the last tool used 5.5. DIAGNOSIS The "DIAG" menu provides various technical information on the battery, including the nature of the faults... - Page 22 PELLENC POWER TOOLS BATTERY 750 56_145276-G Table of correspondences Fault No. Specific tool Explanation of the messages displayed Voltage of the weakest cell in mVolts Voltage of the strongest cell in mVolts Start of charging with cell below 2.5 Volts...
-
Page 23: Statistics
PELLENC POWER TOOLS BATTERY 750 56_145276-G Fault No. Specific tool Explanation of the messages displayed Accelerometer C21 (Y) Excessive temperature on motor MOS semiconductors 12 - C21 General fault on motor control Power consumption from start-up (Ah) Number of hours switched on since commissioning Number of hours switched on since last overhaul 5.6. -
Page 24: Maintenance
Daily maintenance of the machine is meant for daily use, before and after each working day. Important Have the battery serviced at least once a year by a PELLENC authorised distributor. Always store the charged and clean battery in a dry place. -
Page 25: Cleaning The Charger
PELLENC POWER TOOLS BATTERY 750 56_145276-G 6.3. CLEANING THE CHARGER Ensure that the charger is unplugged and disconnected from the battery. Clean the charger housing with a soft damp cloth. Important Cleaning shall be carried out with water only and without detergent, chlorine or sterilising solutions with an alkaline reaction. -
Page 26: Troubleshooting
PELLENC POWER TOOLS BATTERY 750 56_145276-G Degraded mode messages Cell voltage too low fixed Charge Charge interrupted: Battery temperature too low Charge interrupted: Battery temperature too high Fault messages Beep every 2 minutes for 24 hours Voltage too low after 3 hours of non-use. Recharge the battery immediately. -
Page 27: Storage And Transport
PELLENC POWER TOOLS BATTERY 750 56_145276-G 8. STORAGE AND TRANSPORT 8.1. BATTERY STORAGE CONDITIONS • Store the “battery” unit and charger away from heat, dust and humidity, after turning off the battery using one of the on/off buttons. Never store the battery in an ambient temperature of more than +45 °C. -
Page 28: Accessories And Consumables
PELLENC POWER TOOLS BATTERY 750 56_145276-G 9. ACCESSORIES AND CONSUMABLES 9.1. OPTIONAL ACCESSORIES Name Reference CB5022HV charger 57256 CB5033HV charger 57283 Comfort harness 57183 Lightweight harness 57257 Quick connector adapter 57238 Extension kit 152778... -
Page 29: Warranties
10.1.2.1. CONTENTS 10.1.2.1.1. GENERAL INFORMATION In addition to legal warranties, client users benefit from the commercial warranty on PELLENC products covering the exchange and replacement of parts recognised as being out of order, due to machining defects, assembly defects or material defects, whatever the cause. -
Page 30: Paid After-Sales Service
PELLENC products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products. - Page 31 Paid after-sales service also covers PELLENC original spare parts, excluding labour and outside the legal and commercial warranty period. In case of replacement of original PELLENC spare parts in the context of after-sales service, said latter are covered by a warranty of one year as from the installation date.
-
Page 32: Statements Of Compliance
MANUFACTURER / PERSON AUTHORISED TO COMPILE PELLENC THE TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) GENERIC DENOMINATION BATTERY FUNCTION Intended to power PELLENC portable power tools COMMERCIAL NAME ULTRA LITHIUM BATTERY TYPE Li-ion battery MODEL SERIAL NO. 56Y00001 - 56Y49999... -
Page 33: Statement Of Compliance: 750 Battery
PELLENC POWER TOOLS BATTERY 750 56_145276-G 11.2. STATEMENT OF COMPLIANCE: 750 BATTERY PELLENC ﻣﺻﻧﻊ او ﻣﺳﺗورد اﻟﺟﮭﺎز (Fabriquant ou importateur d'appareil) Quartier Notre-Dame - 84120 Pertuis (France) (Adresse) اﻟﻌﻧوان ﺑطﺎرﯾﺔ ﻟﯾﺛﯾوم أﯾون (Type d'appareil) ﻧوع اﻟﺟﮭﺎز (Pellenc power tools battery) - Page 34 PELLENC POWER TOOLS BATTERY 750 56_145276-G (Signé par) PELLENC اﻟﺗوﻗﯾﻊ ﻣن طرف وﺑﺎﺳم (Lieu, date) Pertuis, ﺗﺎرﯾﺦ وﻣﻛﺎن اﻻﺻدار (Nom) Simon BARBEAU اﻻﺳم اﻟﺗوﻗﯾﻊ (Signature)
