Summary of Contents for Sky Country Escalar
- Page 2 This is information about the design of the Escalar, advice how to use it best and how to care for it to ensure it has a long life. The manual also includes technical specifications and line plans. We hope that the Escalar will give you a lot of wonderful flying hours.
-
Page 3: Technical Data
We recommend to take off and to land with closed trimmers. You can find risers drawing at the end of this manual. Escalar does not have accel- erator. Trimmer webbing is removable - you may change it if it’s damaged. -
Page 4: Pre-Flight Check
Turn control In order to make Escalar turn with a minimum sink and radius while pull- ing the internal brake you should pull very slightly the external one too. Use weightshift to decrease the spiral radius. If the thermal flow is nar- row and strong, increase the tilt and the rotation speed by releasing the external brake. -
Page 5: Flying In Turbulence
The sink rate could be more than 15 m/sec. To get out of the spiral dive you must release the inner brake. Mind that Escalar may take one more turn after releasing the brake. -
Page 6: Asymmetric Collapse
That is why you should be careful not to pull the brake too hard to avoid stall. Frontal collapse Escalar comes out of symmetrical front collapse by itself. You can pull the brakes about a 30 cm to speed the re-inflation. -
Page 7: Full Stall
In flight damage Estimate the damage. If a brake has untied - no problem as Escalar can be steered well by weight shift and pulling the back risers. Even if the damage allows for a sustainable controlled flight, you should land as soon as possible. - Page 8 - Do not expose your glider to the sun any longer than necessary - Keep it away from water and other liquids - Do not let the front edge hit the ground - If wet dry Escalar in shade. If soaked in salty water, rinse the glider thoroughly in non-salty water...
- Page 9 - If you detect a damaged line, inform the dealer or manufacturer about the line number according to the line plan - Keep your Escalar in a rucksack in a dry well-ventilated place under neutral temperature and humidity conditions - If you do not use the glider, then once a month you should unpack it, ventilate it well, and then pack it back in the rucksack.
- Page 11 Compliance of the test samples’ suspension lines, control lines and ris- ers with the dimensions given in the user’s manual has been checked by the testing laboratory after the test flights. Tolerance for the lines lengths is +-10mm from the specified values.
- Page 12 Glider overview 1 - top surface 2 - bottom surface 3 - air intake 4 - lines 5 - risers...
- Page 13 Risers Risers for Escalar 38, 41, 44. Length is 440 mm.
- Page 16 In accordance with standards: EN926-1:2015, EN926-2:2013+A1:2021 PG_2503.2025 and NfL 2-565-20 07.01.2025 Date of issue (DMY): Sky Country Manufacturer: Escalar 41 Model: 001-09-S-2023-B-L-B Serial number: Configuration during flight tests Paraglider Accessories Maximum weight in flight [kg] Range of speed system [cm]...
- Page 17 Escalar Serial number Production date Test pilot Dealer Date Wing check and repairs information USER’S MANUAL version 1.2 issued January 2025...
