Summary of Contents for Blaupunkt RC 1.2
- Page 1 REVERSE CAMERA RC 1.2 Enjoy it. Operating and Installation Instructions...
- Page 2 Disclaimer in conjunction with this reverse camera. In no event shall Blaupunkt be liable for any Attentions direct, indirect, punitive, incidental, special consequential damages to property or life •...
- Page 3 SPECIFICATIONS Features RC1.2 CMOS Image Sensor NTSC TV System E ective Pixels 652 (H) x 492 (V) 750TVL Image Resolution 25 Frame Per Second Exposure & Gain Control 1/60~1/100000sec Electronic Shutter Auto White Balance ...
- Page 4 INSTALLATION DIAGRAM a) Rear Camera a)With Parking Line White Blue b)Remove Parking Line White Blue Video (Yellow) Display Monitor/ Car Radio Power Supply (Red) Reverse Camera Reverse Light Reverse Trigger Ground the wire through the exterior body of the vehicle and keep connection intact. b) Front Camera Video (Yellow) White...
- Page 5 INSTALLATION LOCATION Remove one side of Connect the reverse the reverse light light power cable to socket from its the camera, screwn housing then remove the housing & camera Tail the bulb from its back into position socket. with a screwdriver. Light Use a screwdriver Mount the camera...
- Page 6 FRONT / REVERSE CAMERA INSTALLATION FRONT/ REAR VIEW DISPLAY & PARKING LINE Reverse Camera Wiring (Remove Parking Line) Reverse Camera Reverse Camera Do not cut the wires when using Cut blue wire when using as reverse camera to remove parking line. as reverse camera.
- Page 7 TROUBLESHOOTING If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt authorized dealer if problem persist. Problem Solution Display monitor / car radio does not Restart the display monitor / car radio. show reverse view when reversing.
- Page 8 Blaupunkt Car Entertainment - Asia Paci c Competence Centre 1 331 24 019 32 01...
