Summary of Contents for Blaupunkt RC 2.0
- Page 1 REVERSE CAMERA RC 1.0 RC 2.0 RC 3.0 Enjoy it. Operating and Installation Instructions...
- Page 2 Disclaimer in conjunction with this reverse camera. In no event shall Blaupunkt be liable for any Attentions direct, indirect, punitive, incidental, special consequential damages to property or life •...
-
Page 3: Specifications
SPECIFICATIONS Features RC1.0 RC2.0 RC3.0 CMOS Image Sensor NTSC/PAL TV System Effective Pixels 720 (H) x 480 (V) 720 (H) x 480 (V) 1280 (H) x 720 (V) 750TVL Image Resolution 25/30 Frame Per Second ... -
Page 4: Installation Diagram
INSTALLATION DIAGRAM Black Wire (Ground) Display Monitor/ Car Radio Reverse Camera Reverse Light Ground the wire through the exterior body of the vehicle and keep connection intact. Display Monitor/Car Radio Reverse Camera Attention • Remove protective film from camera lens before use. •... - Page 5 FRONT / REAR CAMERA INSTALLATION FRONT/ REAR VIEW DISPLAY & PARKING LINE Applicable for RC 1.0, RC 2.0 White Camera Monitor Video Blue GND Rear Power Reverse Camera Front Camera Do not cut this wire when using Cut this wire when using as front as reverse camera.
-
Page 6: Installation Location
INSTALLATION LOCATION Remove one side of Connect the reverse the reverse light light power cable to socket from its the camera, screwn housing then remove the housing & camera Tail the bulb from its back into position socket. with a screwdriver. Light Use a screwdriver Mount the camera... -
Page 7: Troubleshooting
TROUBLESHOOTING If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt authorized dealer if problem persist. Problem Solution Display monitor / car radio does not Restart the display monitor / car radio. show reverse view when reversing. - Page 8 RC 1.0 1 331 19 003 32 02 RC 2.0 1 331 19 004 32 02 RC 3.0 Designed and engineered by Blaupunkt Competence Centre 1 331 19 005 32 02...
