Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come
loose inside the carton during shipment.
Parts key
No
Code
Qty
1605-63
1 pc
1
1605-64
2 pcs
2
1605-64P11
12 pcs
3
MADE IN VIET NAM
INC.
Description
Footboard
Side rails
Slats
1
ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL #1605-63+64+65
JACKSON LODGE
TWIN PANEL BED
Hardware kit #1605-64P01
No
Description
Bolt Side Rails
A
Lock washer
B
Flat washer
C
Allen Key
D
Screw
E
2
Qty
M8 x 20
4 pcs
M8
4 pcs
M8 x 16
4 pcs
K4
1 pc
M4 x 30
24 pcs
C
B
A
D
2
