North Light OCL-0979W PBK4 Manual

Solar Wall Light
Please read the entire instruction manual before using the pro-
duct and then save it for future reference. We reserve the right
for any errors in text or images and any necessary changes
made to technical data. If you have any questions concerning
technical problems please contact our Customer Services.
Safety
• Handle the product with care, making sure not to damage
the surface of the solar cell and ensuring that it is not cove-
red with dust or affected by other contaminants.
• The product must not be changed or modified in any way.
• Do not let children play with the product.
This product is not intended for use as a general
light source.
Care and maintenance
• Clean the light using a slightly moist cloth.
• Use only mild cleaning agents, never solvents or corrosive
chemicals.
• Be careful not to damage the solar cell.
• If the product is not used for a long time, the battery may
become so discharged that the LED light does not come
on. In this case the product must be left in bright sunlight
for 10–20 hours to charge. The battery will charge regard-
less of whether the power switch is set to ON or OFF but
quicker if set to OFF.
Responsible disposal
This symbol indicates that the product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards caused
by incorrect waste disposal, the product must be
handed in for recycling so that the material can be
disposed of in a responsible manner. When recycling your
product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Art.no 36-9082
Model OCL-0979W PBK4
Installation
1
3
1. Remove the solar lamp from the housing.
2. Mark where the hole is to be drilled.
Make sure that there are no water pipes or electrical
cables hidden in the wall where you intend to drill or screw.
3. Fasten the housing to the wall using appropriate screws
and wall plugs.
4. Press in the push-button switch on
the back of the solar lamp and place
the solar lamp into the housing. The solar-
powered light will charge during the day
and come on at night.
36-9082-1 36-9082-2
OCL-0979W PRT2 OCL-0979W PGY2
Battery replacement
The rechargeable battery can be replaced as follows:
1. Set the power switch to OFF.
2. Unscrew the retaining screw and
remove the battery compartment
cover.
3. Change the battery making sure
2
that the new battery is inserted with
the correct polarity.
4. Screw the battery cover back in
place again.
5. Set the power switch to ON.
Specifications
Luminous flux
Colour temp.
Battery
Charging time
Operating time
Dimensions
4
ENGLISH
100 lumens
3000 K
1 × 18650, 3.7 V, 2600 mAh, Li-ion
Approx. 8 hours (in continuous sunlight)
Approx. 8 hours (fully charged)
11 × 12 × 11 cm (W × D × H)
