North Light OCL-764-Concrete-BK Instruction Manual

Pendant Light
Art.no 36-6651 Model OCL-764-Concrete-BK
36-6652
36-6691
36-6693
36-6747
Please read the entire instruction manual before using
the product and then save it for future reference.
We reserve the right for any errors in text or images
and any necessary changes made to technical data.
In the event of technical problems or other queries,
please contact our Customer Services.

Safety

• All light fittings must be installed in accordance with
current safety regulations to prevent life-threatening
accidents. Installation should only be performed by those
with a good knowledge of electrical wiring. Contact
a registered competent person or qualified electrician if
you do not possess the required knowledge to perform
such an installation on your own. Follow the instructions
carefully and keep them for future reference.
• The ceiling light is only meant to be used in clean, dry
indoor environments. Do not expose the light fitting
to water, moisture or other liquids.
• Never attempt to repair or modify the ceiling light in
any way.
• Only use a dry cloth to wipe the ceiling light clean
when needed.
• The bulb can become very hot during use. Let it cool
completely before changing.

Warning symbols

For indoor use only.
Class II luminaire.

Installation

Bulb: 220–240 V AC, E27, max 46 W (sold separately).
Note: If you are at all unsure about proper installation
procedures, seek the advice of someone with
the requisite knowledge to help you perform such
an installation or consult a certified electrician.
The light fitting does not need to be earthed (class II).
Warning: Before beginning any
electrical installation always
disconnect the power to
the circuit you are working on,
either by turning off the main
circuit breaker or by removing
the fuse from the consumer
unit. Make sure that there are
no obstructing cables or pipes
behind the wall/ceiling area
where you have planned to drill.
GREAT BRITAIN • CUSTOMER SERVICE tel: 020 8247 9300
internet: www.clasohlson.co.uk e-mail: customerservice@clasohlson.co.uk
postal: 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
OCL-764-Concrete
OCL-764-Marble-BK
OCL-764-Marble-WH
OCL-764-Concrete-Pin
Installation on ceiling with a lamp
socket or a pre-mounted ceiling hook
1. Connect a lamp plug
cable to the terminal
block.
2. Plug the lamp plug into
the ceiling lamp socket.
3. Hang the light onto
the ceiling hook.
4. Push the ceiling cup flush
against the ceiling and
tighten the strain relief
screw.
5. Screw in a light bulb
(E27, max 46 W).
6. Turn the power back on.
Installation on ceiling without a lamp
socket or a pre-mounted ceiling hook
1. Screw a hook capable of supporting the weight of
the light into the ceiling.
2. Connect the electrical supply cable to the terminal
block.
3. Hang the light onto the ceiling hook.
4. Push the ceiling cup flush against the ceiling and
tighten the strain relief screw.
5. Screw in a light bulb (E27, max 46 W).
6. Turn the power back on.

Responsible disposal

This symbol indicates that this product
should not be disposed of with
general household waste. This applies
throughout the entire EU. In order to
prevent any harm to the environment or
health hazards caused by incorrect waste
disposal, the product must be handed
in for recycling so that the material
can be disposed of in a responsible
manner. When recycling your product,
take it to your local collection facility or
contact the place of purchase. They will
ensure that the product is disposed of in
an environmentally sound manner.

Specifications

Supply voltage 220–240 V, 50 Hz
Max 46 W (sold separately)
Bulb
E27
Lamp holder
2 m
Mains lead
