DPH-100 IP Phone
User's Guide
First Edition (August 2001)
651DPH100015
Printed in Taiwan

Advertisement

loading
Need help?

Need help?

Do you have a question about the DPH-100S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for D-Link DPH-100S

Summary of Contents for D-Link DPH-100S

  • Page 1 DPH-100 IP Phone User’s Guide First Edition (August 2001) 651DPH100015 Printed in Taiwan...
  • Page 2 This Warranty applies on the condition that the product Registration Card is filled out and returned to a D-Link office within ninety (90) days of purchase. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card.
  • Page 3 The product's Registration Card, provided at the back of this manual, must be sent to a D-Link office. To obtain an RMA number for warranty service as to a hardware product, or to obtain warranty service as to a software product, contact the D-Link office nearest...
  • Page 4 RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD. LIMITATION OF LIABILITY IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D-LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.
  • Page 5 Table of Contents INTRODUCTION ....................................1 ......................................1 EATURES ....................................... 2 NPACKING ................................2 PERATION EQUIREMENTS ............................3 XTERNAL ARTS AND HEIR UNCTIONS PHONE INSTALLATION AND INDICATOR FUNCTIONS ...................... 6 ................................6 NSTALLATION ROCEDURES CONFIGURATION ................................... 7 .......................... 7 ONFIGURING THE HONE SING A ROWSER...
  • Page 7 DPH-100 IP Phone Introduction This manual describes the D-Link DPH-100 IP (Internet Protocol) telephone and explains how to configure and operate it. The DPH-100 is a fully featured IP telephone that allows both business and residential customers to benefit from IP telephony services. It reduces costs by providing access to local and long-distance voice and data services over a single network connection.
  • Page 8 DPH-100 IP Phone ♦ DTMF tone generation ♦ Remote software upgrade support ♦ Visual status indicators ♦ Communication interface: LAN jack: RJ-45 for Ethernet (MDI-II) PC jack: RJ-45 for Ethernet (MDI-X) ♦ Communications protocols: TCP/IP, UDP ♦ Voice compression: complies with G.711 µ-law, G.711 A-law, G.723 and G.729 ♦...
  • Page 9 DPH-100 IP Phone External Parts and Their Functions Figure 1 The Parts of the Phone HOOK Switches the phone on/off hook. SWITCH Presents on-line messages LCD Screen configuration settings. HOLD ON when the HOLD function is in effect. INDICATOR FUNCTION Selects configuration menus.
  • Page 10 DPH-100 IP Phone REDIAL Dials the last number you called. Shifts the state to editing the name and number of the Speed Dial and Address MEMO Book, or stores the configuration in non- volatile memory. Turns sound pickup off and on. MUTE Transfers the call or clears the input FLASH...
  • Page 11 DPH-100 IP Phone Figure 3 Connectors POWER Power adapter receptacle. 10/100BASE-TX LAN to ITSP Internet ETHERNET connection. 10/100BASE-TX connection to PC. ETHERNET...
  • Page 12 DPH-100 IP Phone Phone Installation and Indicator Functions Installation Procedures The following are steps to install and power on your DPH-100 IP phone. 1) Plug the RJ-45 Ethernet cable into the LAN jack. 2) Plug the power adapter into the appropriate wall outlet. 3) Plug the power adapter plug into the power jack (DC 12V/1A).
  • Page 13 DPH-100 IP Phone Configuration Configuring the Phone Using a Web Browser Setting Up the Connection In order to use a Web browser to configure the DPH-100 IP phone, you must make sure the phone has a valid Ethernet connection to a PC or LAN via its Ethernet port. We recommend using a recent version of any widely used browser.
  • Page 14 DPH-100 IP Phone This is the main page of the phone's embedded Web-based configuration utility. This page shows you a welcome message and information about the phone for your reference. There are three choices for you on this page: Download, Configuration and Reset.
  • Page 15 DPH-100 IP Phone SIP Configuration Page On this page you can set network, SIP, CODEC , Security,SNMP and clock configuration according to your requirements. After completing configuration, you must choose the Save button to store the settings in the phone's non-volatile memory, then reset the phone to activate the new configuration.
  • Page 16 DPH-100 IP Phone Network Configuration Page This is the IP phone network configuration web page. On this page, you can set the network parameters according your network environment. These include DHCP option fixed-IP address/subnet/gateway settings. After adjusting the settings, you must click the Save button to save your new configuration.
  • Page 17 DPH-100 IP Phone Security Configuration Page This is the IP phone's security password configuration page. You can set a password to protect your IP phone's configuration from unwanted tampering by other users. After changing the setting, you must click the Save button to save your new configuration. The default password setting is an "empty string," that is, nothing.
  • Page 18 DPH-100 IP Phone SIP Configuration Page This is the SIP configuration page. You can set the Server IP address, dial plan, phone number, and phone name. After completing configuration, you must click the Save button to save your new configuration. •...
  • Page 19 DPH-100 IP Phone CODEC Configuration Page This is the codec (compression/decompression) configuration page. You can select the voice codecs G.711 µ-law, G.711 A-law, G.723 and G.729 on this page. After configuration, click the Save button.
  • Page 20 DPH-100 IP Phone Clock Configuration Page This is the clock configuration page. You can specify an NTP (Network Time Protocol) server, select the time zone of your region, and enable or disable adjustment for Daylight Savings Time to ensure that the phone displays the correct local time.
  • Page 21 DPH-100 IP Phone SNMP Configuration • Trap Configuration: Enter the Trap server IP address and the community name of the trap manager. • SNMP Community Configuration: Enter the community string for access right. • SNMP System Configuration: Enter the system description and interface description.
  • Page 22 DPH-100 IP Phone Download Page This page is used to upgrade the phone's SIP application software image. When you click this page's single button, you will be taken to the TFTP download page, and the phone will be restarted in download mode (see below for details).
  • Page 23 DPH-100 IP Phone This is the TFTP download page. Both of the input boxes on this page must be filled in for the TFTP download function to work. • TFTP Server: This is the IP address of the TFTP server where the application software image (also known as the "runtime file") is located.
  • Page 24 DPH-100 IP Phone Reset Page This is the IP phone reset system web page. You can reset the IP phone device through the web browser by clicking the “Reset” button. Configuring the Phone using the Keypad and LCD After power is applied, the LCD panel will display the time on the first line and the phone's name on the second line.
  • Page 25 DPH-100 IP Phone Subnet Mask <Enter a.b.c.d> Gateway IP <Enter a.b.c.d> DNS Server IP <Enter a.b.c.d> DNS Host <Enter string> DNS Domain <Enter string> Security Configuration New Password <Enter number> <1~8 digits> Confirm Password <Enter number> <1~8 digits> SIP Configuration Server IP <Enter a.b.c.d >...
  • Page 26 DPH-100 IP Phone After change settings, press ”MEMO” to store the changes in the phone's non-volatile memory, or the changes will disappear after a power reset. Note: The key buttons behave as shown below only when the configuration menu is active (To activate the keypad configuration menu, press button <FUNCTION>.) 1.
  • Page 27 DPH-100 IP Phone Additional Features REDIAL 1. The IP phone remembers the last phone number dialed. 2. To dial the same number again, off-hook the handset or press Speakerphone button, listen for a dial tone, and then press the REDIAL button. MEMO 1.
  • Page 28 DPH-100 IP Phone Editing Speed Dial Addresses On Hook Select Index Key[1~10] Edit Name MEMO [1~10] Edit Number [1~10] MEMO Edit Speed Dial Address Book...
  • Page 29 DPH-100 IP Phone MUTE 1. Disables the voice packet transmission to the phone's network interface. 2. To enable/disable MUTE, press the MUTE button during a call. FLASH 1. Flash to transfer the call 2. To transfer the call, simply press the FLASH button. HOLD 1.
  • Page 30 DPH-100 IP Phone Specifications Call Control Protocol Compliance: MGCP, H.323 ,SIP Internet Protocol Compliance: TCP/IP, UDP, ARP, TFTP, ICMP, Telnet, HTTP Available Audio Compression Schemes G.711 µ-law, G.711 A-law, G.723, G.729 Signal Format: DTMF Echo Cancellation: G.165 DTMF tone detection/generation IEEE 802.3 10BASE-T Ethernet compliant IEEE 802.3u 100BASE-TX Ethernet compliant LEDs...
  • Page 31 DPH-100 IP Phone FCC Class B VCCI Class B BSMI Class B CE Class B C-Tick Class B...
  • Page 32 TEL: 39-02-2900-0676 FAX: 39-02-2900-1723 URL: www.dlink.it E-MAIL: info@dlink.it JAPAN D-LINK TOKYO 10F, 8-8-15 Nishi-Gotanda, Shinagawa-ku, Tokyo 141 Japan TEL: 81-3-5434-9678 FAX: 81-3-5434-9868 URL: www.d-link.co.jp E-MAIL: kida@d-link.co.jp SINGAPORE D-LINK INTERNATIONAL/D-LINK SINGAPORE 1 International Business Park, #03-12 The Synergy, Singapore 609917 TEL : 65-774-6233 FAX: 65-774-6322 E-MAIL: info@dlink.com.sg URL: www.dlink-intl.com...
  • Page 33 8. What category best describes your company? Aerospace Engineering Education Finance Hospital Legal Insurance/Real Estate Manufacturing Retail/Chainstore/Wholesale Government Transportation/Utilities/Communication Systemhouse/company Other_____________ 9. Would you recommend your D-Link product to a friend? No (why?) ______________________ I don know yet 10. Your comments on this product:____________________________________________________________...
