HP ProCurve
Switch cl Modules
Installation Guide
www.hp.com/go/hpprocurve

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProCurve 3400cl-24G and is the answer not in the manual?

Questions and answers

Summary of Contents for HP ProCurve 3400cl-24G

  • Page 1 HP ProCurve Switch cl Modules Installation Guide www.hp.com/go/hpprocurve...
  • Page 3 HP ProCurve Switch cl Modules Installation Guide...
  • Page 4 Packard. performance, or use of this material. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be Publication Number construed as constituting an additional warranty.
  • Page 5 Lasers ........... . . 1-19 HP ProCurve 10GbE X2-SC LR optic (J8437A) ....1-20...
  • Page 6 EMC Regulatory Statements ........1-22 U.S.A.
  • Page 7 Transceiver (J8437A) and the CX4 Transceiver (J8440A). * Supported transceivers: The following HP ProCurve transceivers are supported by the Media Flex cl Module (as of this printing): • 10 Gigabit-X2-SC LR Optic transceiver (J8437A) • 10 Gigabit-X2-CX4 copper transceiver (J8440A) These modules require switch software version M.08.54 or greater to be installed in the switch.
  • Page 8 Extractor Handles and Fault LEDs Link and Activity LEDs Retaining screw (one pair per port) Copper Port connections HP ProCurve Switch Media Flex cl Module Extractor Handles Module Power and Fault LEDs Link and Activity LEDs Retaining screw Port covers...
  • Page 9 Features The HP ProCurve Switch cl Modules have the following features: Connectivity to both copper and fiber when using a Media Flex cl module. LEDs that provide information for each port on the link status, network activity. LEDs that provide information on Module power and Module fault conditions.
  • Page 10 — This page is intentionally unused. —...
  • Page 11 Installing the Modules Installing the Modules You can install any of the modules into any of the HP ProCurve cl Switches that have a compatible module slot. As of this printing, those are the HP ProCurve Switch 3400cl Series: 3400cl-24G (J4905A) 3400cl-48G (J4906A) “...
  • Page 12 The HP ProCurve Switch cl Modules have “low-force”, high-performance connectors. High insertion forces are not necessary to install the modules, and should not be used.
  • Page 13 Installing the Modules Remove the cover plate. Retaining screws Insert module into the guides and slide it in until the extractors come in contact with the chassis. For best results, push simultaneously near both screws. Extractors Push the extractor handles closed and tighten the retaining screws.
  • Page 14 Installing or Removing the transceivers If you installed a copper module (J8434A) you can now connect the cables. If you installed a media flex module, you can now install the transceivers. Use only HP ProCurve transceivers. See page 1 for supported transceivers.
  • Page 15 Installing the Modules Verifying the Module is Installed Correctly Power on the switch and observe the Module Status and Fault LEDs on the front of the switch to verify the module is installed properly. Module Status LED Fault LED When the module is installed properly and the switch is powered on, the module undergoes a self test that takes a few seconds.
  • Page 16 Installing the Modules Connecting the Network Cables Supported Cable Types Table 1. Fiber-Optic Cables Port Type Cable Specifications Connector Supported Length Type 9/125 µm (core/cladding) diameter, 1480 nm, low 10GbE-LR single-mode cable: 10 kilometers metal content, single mode fiber-optic cables, complying with the ITU-T G.652 and ISO/IEC 793- 2 Type B1 standards.
  • Page 17 Installing the Modules Connecting Cables Connecting the Fiber cable Remove the dust covers from the cable connectors on the transceiver port and store for possible future use. Aligning the notches on the cable connectors with the slots of the transceiver ports, press the cable connector into the transceiver port until it snaps into place.
  • Page 18 Installing the Modules Verifying the Network Connections Are Working Check the port LEDs for the newly-installed module to ensure the port(s) connected in the preceding step are operating correctly. Each port on the switch module has Link and Activity LEDs near it as shown in the next illustration.
  • Page 19 Removing a Module Removing a Module N o t e Installing or removing a module with the switch powered on causes a switch reset to occur. Only install or remove a module during scheduled downtime. Follow these procedures to remove a module: Remove any network cables from the ports on the module.
  • Page 20 (if both power supplies are being used, you will have to disconnect both power cords) issuing the reboot system command from the switch console CLI, or selecting the Reset or Reboot option from the switch console menu, web browser interface, or HP ProCurve Manager for Hubs & Switches...
  • Page 21 Troubleshooting Troubleshooting One of the primary tools for troubleshooting the switch modules are the LEDs on the front of the switch and on the modules. Refer to “LED Behavior” on page 9 for a description of the normal LED behavior. Also, refer to the switch Installation and Getting Started Guide for more detailed troubleshooting information for the switch.
  • Page 22 • Verify the port has not been disabled through a switch configuration change. You can use the console interface, or, if you have configured an IP address on the switch, use the web browser interface, or HP ProCurve Manager for Hubs & Switches network management software to determine the state of the port and re-enable the port if necessary.
  • Page 23 24 hours a day, seven days a week through the use of a number of automated electronic services. See the Customer Support/Warranty booklet that came with your switch for information on how to use these services to get technical support. The HP networking products World Wide Web site, http://www.hp.com/go/hpprocurve also provides up-to-date support information.
  • Page 24 Specifications Specifications Physical MODULES Width: 114.3 mm (4.5 in) Depth: 173 mm (6.8125 in) Height: 40.8 mm (1.6 in) Weight: CX4 J8434A 308.5g (0.68 lbs) Media Flex J8435A 297.6g (0.65 lbs) TRANSCEIVERS LR Optic J8437A Copper J8440A Width: 36 mm (1.42 in) 36 mm (1.42 in) Depth: 88.6 mm (3.48 in)
  • Page 25 Specifications Environmental MODULES Operating Non-Operating Temperature: 0°C to 55°C (32°F to 131°F) -40°C to 70°C (-40°F to 158°F) Relative humidity: 15% to 95% at 40°C (104°F) 15% to 90% at 65°C (149°F) (non-condensing) Maximum altitude: 4.6 Km (15,000 ft) 4.6 Km (15,000 ft) TRANSCEIVERS Temperature: Operating...
  • Page 26 Specifications HP ProCurve 10GbE X2-SC LR optic (J8437A) Transmitter Optical Characteristics: Parameter Minimum Typical Maximum Notes Average Optical -8.2 dBm -.5 dBm Launch Extinction Ratio 3.5dB Center Wavelength 1260nm 1355nm Optical Modulation -5.2 dBm 0.2Nm Amplitude Relative Intensity -128dB/Hz Noise...
  • Page 27 Specifications HP ProCurve 10GbE X2-CX4 Transceiver (J8440A) CX4 Transmitter Optical Characteristics: Parameter Minimum Typical Maximum Notes Differential Voltage 800mV 1200mV Common Mode -.4V 196mA 1.9V Voltage Limits Transition Time 60ps 100ohms 1340ps Deterministic Jitter .170UI Random Jitter .270UI CX4 Receiver Optical Characteristics:...
  • Page 28 EMC Regulatory Statements EMC Regulatory Statements U.S.A. FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment.
  • Page 29 EMC Regulatory Statements Korea Taiwan European Community Declaration of Conformity These products are designed for operation with the HP ProCurve switches that have cl module slots. Please see the Declarations of Conformity included in the Installation Guides for those products.
  • Page 30 — This page is intentionally unused. —...
  • Page 31 — This page is intentionally unused. —...
  • Page 32 Technical information in this document is subject to change without notice. Copyright Hewlett-Packard Development Company, 2004. All rights reserved. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. Product of Singapore October 2004 Manual Part Number 5990-6081 *5990-6081*...
