North Light SAL22877 Manual

Floor lamp
Please read the entire instruction manual before use and
then save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
Warning:
• The mains lead should be checked regularly. Never use
the product if the mains lead or plug is damaged.
• If the mains lead has been damaged, it must only be
replaced by the manufacturer, authorised service facility or
qualified tradesman. This is to prevent the risk of electric
shock or fire.
Class II luminaire.
This product is intended for indoor use only.
Responsible disposal
This symbol indicates that this product should
not be disposed of with general household
waste. This applies throughout the entire EU. In
order to prevent any harm to the environment
or health hazards caused by incorrect waste
disposal, the product must be handed in for
recycling so that the material can be disposed
of in a responsible manner. When recycling the product,
take it to your local collection facility or contact the place of
purchase. They will ensure that the product is disposed of in
an environmentally sound manner.
Specifications
Rated voltage 220–240 V AC, 50 Hz
Light source 1 x E27 max 10 W (sold separately)
Size Ø 42 cm, höjd 92,8 cm
Mains lead 1,8 m
Art.no 36-9869 Model SAL22877
Product description
1. Foot switch
2. Lamp base
3. Base fabric
4. Lamp holder
5. Small lamp holder ring
6. Shade ring
7. Large lamp holder ring
8. Shade ring
9. Lamp shade fabric
10. Lamp shade ring
11. Lid
Assembly
1. Place the lamp base (2) on the floor and attach the base
fabric hooks to the upper ring of the lamp base (a).
Make sure that the hook and loop strip is even.
2. Pick up the lampholder from the bottom of the lamp base
and attach the small lamp holder ring (5). Secure with a
shade ring (6).
3. Attach the base fabric hooks (b) to the small lamp holder
ring (5).
4. Attach the large lamp holder ring (7) to the lampholder and
secure with a shade ring (8).
5. Attach the hooks on the lamp shade fabric (c) to the large
lamp holder ring (7). Make sure that the hook and loop
strip is even.
6. Attach the lamp shade ring (10) to the hooks on the lamp
shade fabric (e). Note! Make sure that the rings for holding
the lid in place are facing upwards.
7. Install the light bulb, 1 x E27 max 10 W (sold separately),
into the socket of the lamp holder.
8. Attach the lid by matching up the pins with the rings in
the lamp shade ring (e).
9. Plug the mains lead into a wall socket and use the foot
switch (1) to turn the light on or off.
e
d
c
4
b
a
1
ENGLISH
11
10
9
8
7
6
5
3
2
