P070GUI002 – User manual e-Celsius Medical system EN.6
®
e-Celsius
Medical System
User Manual
MEASUREMENT SYSTEM CONTINUOUS RELIABLE AND
PRECISE TEMPERATURE, AND RECORDING
GASTROINTESTINAL BY TELEMETRY
Before use, please read
entirely theses instructions
Monitor e-Viewer®
BodyCAP
3, rue du Docteur Laënnec
14200 Hérouville Saint Clair
+33 (0)2.61.53.08.14
FRANCE
http://www.bodycap-medical.com
Email :
Support@bodycap-medical.com
