OH08-1

Part 1 Introduction ........................................................................ 1

1. Introduction .............................................................................................2

Part 2 Control Systems ................................................................. 3

1. Remote Controller (Wired Type) .............................................................5

2. Remote Controller (Wireless Type).......................................................10

3. Simplified Remote Controller ..............................................................182

4. Remote Controller for Hotel Use .........................................................186

5. Adaptor for Wiring ...............................................................................191

6. Wiring Adaptor for Electrical Appendices (1) (2) .................................200

7. Installation box for adaptor PCB .........................................................214

8. Interface Adaptor for SkyAir Series.....................................................225

9. External Control Adaptor for Outdoor Unit ..........................................228

10.Remote Sensor (For Indoor Temperature)..........................................236

11.DIII-NET Expander Adaptor ................................................................238

12.Central Remote Controller ..................................................................242

13.Electrical Box with Earth Terminal ......................................................273

14.Unified ON/OFF Controller..................................................................275

15.Wired Remote Controller with Weekly Schedule Timer ......................282

16.Set Back Time Clock...........................................................................289

17.Noise Filter (For Electromagnetic Interface Use only) ........................301

18.Schedule Timer ...................................................................................304

19.Residential Central Remote Controller................................................313

20.Unification Adaptor for Computerized Control.....................................325

21.Wiring Adaptor for Other Air-Conditioner ............................................329

22.Interface for use in BACnet

23.Interface for use in LONWORKS

24.Optional DIII Board..............................................................................344

25.Optional Di Board................................................................................347

26.Optional DIII Ai Unit.............................................................................350

27.intelligent Manager..............................................................................353

28.intelligent Touch Controller .................................................................360

29.Parallel Interface .................................................................................376

Part 3 Indoor Units .................................................................... 393

Table of Contents

- Ceiling Mounted Cassette Type (Double Flow) - ..............................395

- Ceiling Mounted Cassette Type (Round Flow) - ...............................404

- 600×600 Ceiling Mounted Cassette Type (Multi Flow) - ...................439

- Ceiling Mounted Cassette Corner Type -..........................................451

- Slim Ceiling Mounted Duct Type - ....................................................480

®

...............................................................331

®

......................................................337

i
