BUILT-IN WINE COLUMNS
45cm (18") Wine Column Panel Installed
Dimensions
WC455BLX2T (left hinge)
WC455BRX2T (right hinge)
Handle choices
Professional Series: PROHKCOL
Master series: MASHKCOL
Heritage Series: HERHKCOL
SIDE VIEW
22 1/4"
565
80 3/4"
2050
+
1"(25)
5"
127
2 3/4"
70
19 7/8"
505
SIDE VIEW
22 1/4"
565
80 3/4"
2050
+
1"(25)
5"
127
2 3/4"
70
19 7/8"
505
* Maximum Overall Handle Dimension
For detailed handle dimensions see page 71
FRONT VIEW
77 3/4"
83 1/2"
1974
2120
+
1"(25)
5 3/4"
+ 1"(25)
146
FRONT VIEW
77 3/4"
83 1/2"
1974
2120
+
1"(25)
5 3/4"
+ 1"(25)
146
TOP VIEW
2 1/2"
17 15/16"
*
63
40 3/4"
1034
17 5/8"
447
DOOR
WIDTH
TOP VIEW
17 15/16"
24 3/8"
620
100°
17 5/8"
447
DOOR
WIDTH
Dimensions in parentheses are millimeters unless otherwise
specified.
456
24 3/8"
620
100°
2 1/2"
*
456
63
40 3/4"
1034
bertazzoni.com
52
