Calix ODC-40 Installation Guide
July 2003
Part #220-00002, Rev. 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ODC-40 and is the answer not in the manual?

Questions and answers

Related Manuals for Calix ODC-40

Summary of Contents for Calix ODC-40

  • Page 1 Calix ODC-40 Installation Guide July 2003 Part #220-00002, Rev. 14...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Before You Begin Installing the ODC-40 Product Overview and Access ............3 Introduction to the ODC-40 cabinet ........... 3 Front access ................6 Side splice access ..............7 Rear access................8 Opening and closing compartment doors ........9 Battery access ..............
  • Page 4 Maintaining the Calix Outdoor Cabinet........77 Battery Maintenance ..............77 Maintain external cable connections .........78 Maintain the cabinet surfaces ..........79 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. ODC-40 Installation Guide...
  • Page 5 Customer Service and Support ..........105 The Calix Technical Assistance Center ........105 Appendix: Specifications ............107 ODC-40 cabinet specifications..........107 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. ODC-40 Installation Guide...

  • Page 7: Before You Begin Installing The Odc-40

    Chapter Before You Begin Installing the ODC-40...

  • Page 9: Product Overview And Access

    The Calix C7 ODC-40 optical access cabinet is an environmentally controlled enclosure designed to deploy the Calix C7 in outdoor locations. The cabinet can be configured for copper, fiber, or a combination of both with flexibility for migration from copper to fiber in the field.
  • Page 10 View of the ODC-40 cabinet The following shows a closed front view of the Calix C7 ODC-40 cabinet. Features of the ODC-40 cabinet Following are some features of the Calix C7 ODC-40 cabinet. • integrated air-to-air cooling system with DC blowers •...
  • Page 11 Dynasty batteries. Calix Dynasty 125 AH batteries) recommends and supports using Dynasty 125 AH batteries.) Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 12: Front Access

    Front access The front equipment compartment contains two Calix C7 shelves, a rectifier shelf, and an optional remote testing unit. The compartment also contains the AC load center and the DC distribution box. Front view of the ODC-40 cabinet Proprietary Information: Not for use or disclosure except by written agreement with Calix.

  • Page 13: Side Splice Access

    The ground plate has 4 field-configurable knockouts (two 3/4", one 1", one 1 1/ 2"). Side view of the ODC-40 cabinet Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 14: Rear Access

    Each rear panel holds five copper protection blocks. Each block corresponds to two slots on one of the Calix C7 shelves. The panels are hinged to support easy maintenance and access to the backs of the Calix C7 shelves. Each protection block provides protection for two copper plug-in cards. Protection blocks terminate with MS2 connectors for interface in the splice compartment.

  • Page 15: Opening And Closing Compartment Doors

    If the handle does not lock in place, insert and turn the key until it clicks. Then, press the handle latch into place. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 16: Battery Access

    On the panel, remove the ground strap from the panel. Set the battery compartment panel out of your way. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 17 Insert the key into a latch and turn it clockwise until the inner keyhole notch aligns with the outer keyhole notch. Repeat for all latches on the panel. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 18: Cooling Fan Access

    An allen wrench is provided with the cabinet. Push the front edge of the roof up until the support arm locks into place. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 19 5/16" allen wrench. An allen wrench is provided with the cabinet. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 21: Installation Prerequisites

    Installation Prerequisites gives instructions to prepare for installation on a concrete pad. The concrete pad can be poured on site using a pour-in-place template. Pad recommendation and alterations Calix recommends a reinforced 5 1/2-inch thick concrete pad. Your pad may vary depending on site and environmental conditions. Modify for local conditions Local climatic conditions, site conditions, or local practices may require modifications to cable termination.

  • Page 22: Site Requirements

    The pad dimensions are 83 inches by 96 inches; 5 1/2 inches deep. These pad dimensions allow for full door clearance around the cabinet. Footprint clearance Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 23: What You Need To Bring

    Analog test set (for testing POTS lines) • DS1 test set • DS3 test set • ADSL test set • Optical power meter Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 24: What You Get With The Cabinet

    What you get with the cabinet Items in the installation kit The following items are shipped inside the battery tray of the ODC-40 as an installation kit: • Calix coffee cup with lid (quantity 1) • 2-inch cold shrink tubing (quantity 2) •...

  • Page 25: Placing The Odc-40 On A Pad

    Chapter Placing the ODC-40 on a Pad...

  • Page 27: Pad Mounting The Cabinet

    Remove the four shipping bolts at each corner of the cabinet that hold the cabinet to the pallet. Open the battery tray and remove the installation kit and related items. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 28: Prepare The Cabinet For Placement

    Attach lifting straps the to lifting details. Suspend the cabinet approximately 2 feet (61 cm) above the pad. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 29: Lower And Bolt

    Securely tighten the nuts to secure the cabinet to the pad. Close the rear battery compartment panel. See the battery access procedure. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 30: Seal The Cabinet

    Cover any unused cable entry ports with the blank plates provided. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 31: Installing Power, Subscriber Cables, And Equipment

    Chapter Installing Power, Subscriber Cables, and Equipment...

  • Page 33: Cable Requirements

    For fiber cabling, if you are using fiber, use single-mode fiber only. • For fiber cabling, use a fiber splice value of no greater than.5 dB loss. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 35: Connecting Power And Ground

    Do not turn on the main power to the cabinet until the power installation is complete. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 36: Ground The Cabinet And Test The Ground

    Secure the terminal lug of the ground cable to the ground bar stud. Tighten the strain relief fitting to secure the ground cable. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 37 Attach the second lead from the Ohm meter to the ground bar. Verify that the Ohm meter reads 1 Ohm or less. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 38: Install And Test The Ac Power

    Requirements for AC power input. The Calix outdoor cabinet requires a 240-220 VAC power feed with 60 Amp service. DANGER! High voltage may be present. Do not turn on the main power to the cabinet until the installation is complete.
  • Page 39 Note: ODC-10 and ODC-20 pegboards have 3 screws per side. Remove the wall plate located above the AC entry tray. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 40 AC cables in the AC entry tray c. pull the cables through to the AC Load Center. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 41 Run the black hot lead to the L1 side of the breaker. Run the red hot lead to the L2 side of the breaker. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 42 In the front equipment compartment, re-attach the AC load center front panel. In the side splice compartment, re-attach the AC cover plate over the AC entry tray. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 43: Install And Test Rectifier Modules

    Install and test rectifier modules Description of the rectifier shelf The Calix rectifier shelf contains an alarm control unit on the left and space for four rectifier modules in the center. Each rectifier module has its own power switch and alarm and status indicators.
  • Page 44 ON for module positions 1, 2, and 3, and set to OFF for position 4. Set the rectifier module AC switch to ON. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 45 -54.5 +/-.5 VDC At the AC Load center, set all the breakers to OFF. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 46: Install And Test The Batteries

    On the battery temperature compensation sensor, remove the protective cover to expose the lug. Remove the protective caps from the battery terminal lugs. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 47 Dynasty recommends 110 in.-lbs. or 12.4 n-m. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 48 -46 and -54 VDC Set the battery breaker switch above each drawer to ON. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 49 52 VDC At the AC load center, set the Main breaker to OFF to check that the batteries supply power to the cabinet. The fan trays in the Calix C7 should continue to run.

  • Page 50: Install And Test The Fan Tray

    Install and test the fan tray Installing a fan tray into a Calix C7 shelf in the front compartment of the cabinet provides cooling for the Calix C7 shelf. The front panel of the fan tray also shows the results of a power test at start-up, and provides status displays and interfaces for testing.
  • Page 51 (Note: In the locked position, the handle should be flush with the bottom lip of the shelf.) Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 53: Installing Outside Plant Cables

    For best results with a high copper count configuration, route the cable to the right. Note Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 54 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 55 Use the appropriate tool to squeeze the two connectors together for a tight fit. Repeat steps 2 through 4 for all binders in the outside plant cable. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 56 The sample image shows 320 modules installed in 2 copper protection panels. Your configuration may differ. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 57 The figure shows the labels for slot 1 and where you would apply them to the copper protection block. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 58: Install The Fiber Holders

    72 fiber connections. Jumper options From the front of a Calix C7 optical plug-in card, you can run a fiber jumper to a fiber distribution cassette. You can also run a jumper between the fiber splice tray and the fiber distribution cassette.
  • Page 59 Fiber jumper and pigtail options • From the front of a Calix C7 optical plug-in card, you can run a fiber jumper to a fiber distribution cassette. • From the front of a Calix C7 optical plug-in card, you can run a fiber pigtail to a fiber splice tray.
  • Page 60 Slide the fiber trays into the holder. Secure the fiber trays to the holder with the supplied velcro strap. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 61: Install The Fiber

    Pigtails are splice to the fiber with the splices placed in the fiber splice trays. The above configuration is a sample placement suggestion. Your configuration may differ. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 62 Insert the fiber distribution cassette into the holder. Procedure to terminate the fiber cables Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 63 If desired, run fiber pigtails from the fiber distribution cassette(s) to the corresponding fiber splice tray. Use velcro around the splice tray ends to simplify cable management. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 64 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 65: Install Other Fiber And Cable Management Accessories

    Install other fiber and cable management accessories Calix ships each cabinet with brackets that you can use to mount equipment or accessories in the splice compartment. Description of the accessory brackets The accessory brackets are 6" high and 5-5/8" deep.

  • Page 67: Installing Plug-In Cards

    Push the card ejector up into the locked position. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 68 AMP installation view Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 69: Install The Calix Rap

    Lock the card ejectors at the top and bottom of the card. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 70: Install The Metallic Plug-In Cards

    On the card, push the card ejector up into the locked position. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 71: Install The Optical Plug-In Cards

    However, it can destroy the retina of the eye. Optical plug-in card installation view Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 72 (Note: the Calix optical card ports are located on the face of each card and are numbered from the top of the card down -1, 2, 3, etc. - with the RX connector in the front and the TX connector immediately behind it.)

  • Page 73: System And Network Configuration

    Introduction Calix iMS features The Calix integrated Management Software (iMS) is a graphical user interface that you use to configure and monitor all of the Calix C7 nodes on a network. With the Calix iMS, you can: • view a diagram of your network topology •...

  • Page 74: Configure Your Computer To Connect To The Calix C7

    Calix C7 iMS Guide. Calix factory settings for the front Ethernet port The Calix C7 ships with the front Ethernet port on the AMP (E1) active and set to the following configuration: IP: 192.168.1.1...
  • Page 75 Use a straight-through Ethernet cable to connect the Ethernet port on your computer to the Ethernet port on the front of the AMP in the Calix C7 shelf. Proprietary Information: Not for use or disclosure except by written agreement with Calix.

  • Page 76: Start The Calix Integrated Management System

    Start the Calix integrated Management System You start the iMS by entering the IP address of the Calix C7 shelf into your browser. One-time install of the Java Runtime Environment The first time you start the Calix iMS, you may be prompted to: •...
  • Page 77 Start up view of your network The first time you log in to a new Calix C7 network, you will see the following: • An empty Work Area with no network topology. • One entry in the Navigation Tree named Unassigned Shelves.

  • Page 78: Define Nodes In The Network

    In the Alarm Setting list, click either Node to display alarms only for this node, or Network to display all alarms. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 79 Click Next to save all node definitions and the Admin Master designation, and to exit the Network Wizard. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 81: Maintaining And Troubleshooting The Odc-40

    Chapter Maintaining and Troubleshooting the ODC-40...

  • Page 83: Maintaining The Calix Outdoor Cabinet

    Cabinet Battery Maintenance At a minimum follow the battery manufacturers recommended maintenance. Additionally Calix recommends that all batteries be removed from the cabinet, tested and maintained at least once a year. Perform the following task: • Visually inspect each battery for physical damage, leakage, or bulging. Replace any battery displaying any defect before the batteries are placed back in service.

  • Page 84: Maintain External Cable Connections

    Check all conduits to ensure that any material used to seal between the cable and the conduit is still present and providing a complete seal. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 85: Maintain The Cabinet Surfaces

    Visually inspect the inside of the cabinet for signs of visible damage to the metal or paint. • Repair damage to the paint using touch-up paint available from Calix after cleaning the surface and removing rust. • Note any damage to the metal work. If the damaged metal work interferes with the operation of the Calix C7 cabinet or electronics contact Calix support for assistance with a resolution.

  • Page 87: Environmental Alarms

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 08-15-00 A 001 REPT EVT ENV "N2-1:POWER,CL,9-10,8-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 88: Battery Circuit Breaker Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 09-20-00 A 001 REPT EVT ENV "N2-1:BATTCB,CL,9-10,8-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 89: Auxiliary Fuse Fail Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 10-45-00 A 001 REPT EVT ENV "N2-1:FUSE,CL,9-10,10-45-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 90: Cabinet Over Temperature Alarm

    You will see this message once the alarm has been cleared from the system: TID-000 01-09-10 11-55-00 A 001 REPT EVT ENV "N2-1:HITEMP,CL,9-10,11-55-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 91 If the equipment is producing more heat than what is budgeted for equipment in the cabinet, proceed to the next step. Access the Calix C7 equipment with a computer and verify the heat setting for the shelf or shelves in the cabinet.

  • Page 92: Door Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 17-15-00 A 001 REPT EVT ENV "N2-1:OPENDR,CL,9-10,17-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 93: Gmt Fuse Fail Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 12-15-00 A 001 REPT EVT ENV "N2-1:FUSE,CL,9-10,12-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 94: Low Battery Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 13-15-00 A 001 REPT EVT ENV "N2-1:BATTERY,CL,9-10,13-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 95: Low Voltage Disconnect Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 14-15-00 A 001 REPT EVT ENV "N2-1:LVD,CL,9-10,14-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 96: Rectifier Major Alarm

    The rectifier major (RECT) alarm indicates that the outdoor cabinet Major rectifier shelf has a major alarm. The Calix rectifier will report a major alarm for high voltage shut down, AC fail, Fuse Alarm, and low voltage disconnect. Alarm output...

  • Page 97: Rectifier Minor Alarm

    You will see this message once the alarm has been cleared from the system. TID-000 01-09-10 16-15-00 A 001 REPT EVT ENV "N2-1:RECT,CL,9-10,16-15-00;" Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 99: Troubleshooting And Replacing Outdoor Cabinet Hardware

    Verify cooling fan operation as part of regular cabinet maintenance. An over temperature condition will occur as the result of a failed cooling fan. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.
  • Page 100 Replace and tighten all cartridge screws around the perimeter. Close the cabinet roof. See the roof closure procedure. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...

  • Page 101: Replace A Rectifier Module

    OFF for positions 3 and 4. Set the rectifier module AC switch to ON. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 102 -54.5 +/-.5 VDC At the AC Load center, set all the breakers to OFF. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 103: Replace The Batteries

    Tighten the bolt to a terminal torque as specified by the battery manufacturer. Dynasty recommends 110 in.-lbs. or 12.4 n-m. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 104 -46 and -54 VDC Set the battery breaker switch above each drawer to ON. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 105: Replace The Circuit Breakers

    Replace the cover to the AC load center. Set the main AC breaker, and the breaker that you just replaced, to ON. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved.

  • Page 106: Replace The Fuses

    Replace the fuses Fuses for the Calix C7 shelves and other equipment in the cabinet are located on the DC Distribution panel. Fuse ratings in the DC Distribution panel Fuse Type Fuse Rating Calix C7 shelves 20 Amp Heat exchanger fans and other equipment...

  • Page 107: Replace The Battery Heater

    Repeat steps 2 through 4 if you are installing battery heaters in a cabinet with multiple battery drawers. Reload and reconnect batteries. See the battery installation procedure. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 108 View of the battery heater The battery heater is highlighted in the image below. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 109 Chapter Reference...

  • Page 111: Customer Service And Support

    TAC. Normal business hours are 7:00 am to 7:00 pm PST, Monday through Friday. After hours and on holidays: Contact the Calix TAC by phone and receive an immediate response from a Service Engineer for Severity 1 and 2 issues.

  • Page 113: Appendix: Specifications

    Over temperature Rectifier Major Rectifier Minor AC Fail AUX/GMT Fuse Fail Battery Breaker Fail Low voltage Disconnect Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
  • Page 114 Preferred batteries: Dynasty 125 AH battery Up to 2 strings per cabinet The ODC-40 base is designed to accommodate Fiamm, Hawker, Lifeline, Lucent and Saft. Ancillary Equipment 2 RU available for 3rd party active equipment in 19" equipment rack Color Warm gray Proprietary Information: Not for use or disclosure except by written agreement with Calix.
  • Page 115 Telcordia, GR-63-CORE, Network Equipment-Building System (NEBS) Requirements, Issue 1, October 1995. Telcordia, GR-487, Generic Requirements for Electronic Equipment Cabinets, Issue 2, March Proprietary Information: Not for use or disclosure except by written agreement with Calix. © 2001-2003 Calix. All Rights Reserved. Calix ODC-40 Installation Guide...
