- Page 1 WARRANTY CARD OPERATING INSTRUCTIONS HGG3100E HGG3100X...
- Page 3 Home Thank you for your trust and congratulations on making the right choice. The power plant you have purchased has a modern petrol engine and an aesthetic, robust design. The power unit has been designed and manufactured in accordance with the safety regulations of the European Union.
-
Page 4: Table Of Contents
Table of Contents 1. Safety instructions ..................3 2. Design elements of the power plant ............4 3. Before commissioning ................5 4. Commissioning of the power plant ............8 5. Switching off the aggregate ..............9 6. Correct operation of the power plant............9 7. Service and inspections................11 8. -
Page 5: Safety Instructions
1. Safety instructions Before starting work or carrying out any inspections, it is essential to read the operating instructions and the equipment purchased. The use of the power generator must comply with the instructions in this manual and the OHS and other local regulations applicable to the use of the equipment. This is a condition for any comments, claims and warranty claims. -
Page 6: Design Elements Of The Power Plant
During the operation of the power plant, the OHS regulations and other local regulations applicable to the operation of such equipment must be observed. Fuel level indicator Air filter AC socket 23GW16A Manual starter AC circuit fuse Oil drain screw Motor hours counter Oil filler plug Earthing... -
Page 7: Before Commissioning
Carburetor Fuel filler plug Spark plug Production label Silencer with cover 3. Before commissioning 3.1. Check that the power pack is standing on a level surface (horizontal). 3.2. Check the oil level in the engine: 1) Unscrew the oil filler plug with dipstick. 2) Wipe the dipstick. - Page 8 Correct oil level Oil level indicator with dipstick Recommended engine : SAE15W40 Oil pan capacity: 0.6L 3.3. Check the fuel level in the tank Check the fuel level in the tank using the gauge located on the tank at the filler neck.
- Page 9 Recommended fuel: unleaded petrol Pb95 (E5) Fuel tank capacity: 9 L 3.4 Check the air filter Check the condition of the air filter before each use of the power pack. Carry out maintenance according to the information on the label on the power unit. If , replace the filter with a new one.
-
Page 10: Commissioning Of The Power Plant
5. Plug the unit into an AC outlet, then switch the AC circuit breaker to the I 'ON' position. 4.2. Commissioning of the HGG3100E 1. Disconnect all load devices from the AC outlets and switch the AC circuit breaker to the O 'OFF' position. -
Page 11: Switching Off The Aggregate
5. Shutting down aggregate 1) Switch the AC circuit breaker to the O 'OFF' position. 2) Unplug appliances from the AC outlet 3) Switch the switch lever to the right from the 'OPERATION' position to 'STOP'. 6. Proper operation of power plant To keep the power pack in good condition and to prolong its reliable operation, please observe the following instructions: 6.1. - Page 12 6.3. Direct Current - Applications 1) The DC socket (if the device is equipped with one) is used exclusively for charging the rechargeable batteries. 2. To charge the batteries, turn the AC power switch to OFF. An ON/OFF switch may be retrofitted on the control panel near the 12V DC output. 3) When charging lead-acid batteries, remember to keep the "+"...
-
Page 13: Service And Inspections
7. Service and inspections Regular inspections and replacement of consumable components are very important to keep the power plant in good condition. The power pack must be switched off while the replacement and inspection is being carried out. The use of non-original spare parts may cause damage to the power pack. Installation of non-genuine parts will void the warranty. -
Page 14: Air Filter
7.1. Changing the engine oil Be sure to warm up the power unit for about 5 minutes before starting the oil change (the oil in the engine must be warm so that it flows completely out of the engine). 1) Unscrew the oil dipstick. 2) Unscrew the oil drain screw and drain the worn oil into the container. - Page 15 1) Unscrew the drain plug located under the fuel tap. Fuel tap Drainage container 2) Clean the reservoir, strainer and O-ring. Fuel filter (strainer) O-ring Drainage container 3) After cleaning, everything, leave the fuel tap in the ON position and check for any leaks.
-
Page 16: Fuel
Recommended spark plug: Seals candles Equivalents: 8. Fuel Use only clean, unleaded petrol and prevent dirt and water from entering the fuel tank. Measures: - gasoline is flammable and explosive, - only refuel when the engine is switched off in a well-ventilated area. - no smoking near petrol tanks, avoid situations where sparks can be generated - Do not fill the tank above the maximum level (no petrol in the tank neck),... -
Page 17: Transport And Storage, Long-Term Storage
If the engine stops and cannot be restarted, check the engine oil level. Never disconnect the oil level sensor. This can lead to engine damage (seizing). 10. Transport and storage, long-term storage Store the power unit in a covered warehouse that protects it from direct exposure to atmospheric influences. -
Page 18: Possible Problems And Solutions
The warranty does not cover any damage caused by improper storage or transportation of the equipment and repair of damage will be paid for by the owner of the equipment. If the equipment has been used, allow it to cool before transporting or storing. Otherwise, storage or transportation may lead to burns, fire and even explosion. - Page 19 11.3. Uneven engine operation. Cause Solution High voltage wire fault. Replace the spark plug cable, including the spark plug connector, with a new one. Carbonized spark plug. Clean the spark plug. Clogged fuel line. Clean the fuel lines. 11.4. The engine is too high. Cause Solution Engine fins sealed.
-
Page 20: Technical Parameters
12. Technical parameters Model HGG3100X HGG3100E Frequency 50 Hz Voltage 230 V Rated power / Starting power 3.0kVA/kW / 3.3kVA/kW Rated current Effect cosφ= 1.0 single-cylinder, four-stroke, air- Engine cooled Revolutions 3000 rpm Volume of the oil sump 0,6 L... -
Page 21: Electrical Diagram
13. Electrical diagram 13.1. Model HGG3100X... - Page 22 13.2. Model HGG3100E...
-
Page 23: Ec Declaration Of Conformity
Notified person number: 0197 Device type Power Plant Model/Type: HGG3100X HGG3100E Measured sound power level: 93.8± 0.5 dB/A Guaranteed sound power level: 96 dB/A Hahn & Sohn GmbH, Auf der Schanze 20 93413 Cham, declares under its own responsibility that the equipment to which this declaration relates complies with the requirements set out in the Collection of Laws: •... -
Page 24: Warranty Sheet
WARRANTY SHEET The equipment is subject to warranty if purchased from Hahn & Sohn GmbH or an authorized regional representative of Hahn & Sohn GmbH. The warranty is for 1 year or 200 motor hours from the time of purchase, whichever comes first. The warranty covers only manufacturing and material defects. - Page 25 The absence of documented activities as described above deprives the buyer of warranty rights. Documentation of the above inspections, including a record of the types of oils, filters, and service stamp, must be made each time in the "Warranty Repairs and After Warranty Service" section of the Warrantor's Operator's Manual or the Machine Manufacturer's Operator's Manual.
- Page 26 INSPECTIONS, ADJUSTMENTS AND CHECKS Number of Date and signature of working Description of inspection, adjustment or repair, scope of service hours activities technician...
- Page 27 INSPECTIONS, ADJUSTMENTS AND CHECKS Date and Description of inspection, adjustment or repair, scope of Number of signature of working activities service hours technician...
- Page 28 Central distributor and warranty provider Hahn & Sohn GmbH Auf der Schanze 20 93413 Cham Tel: +490 9944 890 9 896 www.hahn-power.de Hahn a syn s.r.o. Lelkova 186/4, 747 21 Kravaře www.hahn-power.cz...
