- Page 1 WARRANTY CARD OPERATING INSTRUCTIONS HDE9000SA HDE9000SA3 HDE9000EA3...
-
Page 2: Home
INSTRUCTIONS FOR USE OF THE POWER PACK: Home Thank you for purchasing a Hahn & Sohn brand power generator and congratulations on making the right choice! The power unit has been designed and manufactured in accordance with the safety requirements of the European Union. Use it according to the instructions in the operating manual and the safety regulations in force in the workplace. -
Page 3: Table Of Contents
Table of Contents Home ....................1 Table of Contents ................2 1. Safety instructions ..................3 2. Construction and dimensions of the aggregate ........5 3. Before commissioning................6 4. Commissioning of the unit ..............8 5. Operation of the aggregate..............9 6. Switching off the aggregate ...............11 7. -
Page 4: Safety Instructions
1. Safety instructions 1. Read this manual carefully before putting the unit into operation and keep it for future reference or contact your dealer. 2. Familiarise yourself with the design of the unit before putting it into operation. 3. It is forbidden to allow children to operate the unit. Never allow persons without proper training or persons under the influence of alcohol or other intoxicants to operate the equipment. - Page 5 17. Place the aggregate on a flat surface. 18. Do not allow too much fuel in the tank - there must be no fuel in the tank neck. 19. The engine is very hot during work and remains hot for some time after the work is finished.
-
Page 6: Construction And Dimensions Of The Aggregate
2. Construction of the aggregate 6 - Electrical sockets 1 - Electrical switch starting 7 - Grounding clamp 2 - Low oil level light 8 - DC12V/8,3A 3 - Air heater 9 - Fuel gauge 4 - Display switch 10 - Filler neck stopper 5 - Differential switch 11 - Damper panel cover... -
Page 7: Before Commissioning
3. Before commissioning To ensure the safety and longevity of the unit, it is important to spend sufficient time checking the overall condition of the unit. Ensure that any fault, even minor, has been rectified before commissioning. In the event of a problem that is not described in these instructions, contact Hahn &... - Page 8 Grounding of the aggregate 1. Insert a 2 cm copper wire into the ground near the aggregate. 2. Plug the free end of the wire into the panel (to the ground terminal) The unit must be earthed, otherwise there is a risk of electric shock.
-
Page 9: Putting The Unit Into Operation
Installing the battery The unit must be equipped with a battery, which is not included in the manufacturer's delivery. The unit must be equipped with a 12V battery with dimensions 196.85x133.35x184.15 mm with a minimum CCA of 300. The accumulator may be smaller and have a higher CCA. The battery compartment is located behind the metal plate under the electrical panel. -
Page 10: Operation Of The Aggregate
Sucking The intake is used to deliver an enriched fuel mixture during engine start-up. The intake can be opened and closed manually. Pull the rod in the "CLOSED" direction to add mixture for cold start. 5. The work of the aggregate Connect only undamaged devices. - Page 11 The rated power of the device should be indicated in the instructions, if not, calculate this information as the product of current and voltage. Power [W]= Voltage [V] x Current [A] Connecting the device: 1. Wait for a while before connecting electrical to the unit. 2.
-
Page 12: Switching Off The Aggregate
Batteries generate explosive hydrogen during charging. Batteries contain acid that can cause corrosion. Do not use fire near the battery during and shortly after charging. Always wear goggles and gloves when charging the battery. In case of skin contact with acid, wash the area thoroughly with water. In case of eye contact with acid, flush eyes and seek immediate medical attention. -
Page 13: Regular Inspections And Checks
7. Regular inspections and maintenance Proper maintenance is essential for safe and trouble-free operation of the equipment. Never carry out maintenance while the equipment is working or immediately after it has stopped. Wait for the equipment to cool down. Keep sources of fire and combustibles away from the equipment. - Page 14 7.3 Checking the oil level It is important to check the oil level in the crankcase before each use. To check the oil level: 1. Make that the aggregate is switched off and is standing on a level surface. 2. Unscrew the stopper/plug. 3.
- Page 15 7.5 Replacing the air filter Routine air filter checks are essential for the proper functioning of the carburetor. Check that the filter is not excessively clogged. The filter may require more frequent cleaning when operating in dusty environments. To clean the fuel filter: 1.
-
Page 16: Transport And Storage
7.7 Replacing carbons 1. Remove the damper cover (Fig. 8). 2. Remove the double silencer (Fig. 9). 3. Remove the rear panel (Fig. 10). 4. Find and replace the carbon (Fig. 11,12,13). Fig. 8. Fig. 9. Fig. 10. Fig. 12. Fig. -
Page 17: Troubleshooting
9. Troubleshooting Important: If problems persist, contact your dealer. Symptoms Cause Solving the problem Engine won't The engine switch is in the Switch the switch to the start "OFF". "he". There's no fuel. Refuel. Low oil level. Top up or change the oil. The unit is standing on an Place the aggregate on a uneven surface. -
Page 18: Technical Data
10. Technical data Model HDE9000SA HDE9000SA3 HDE9000EA3 HDE9000EA Type of jacket Printed from Open Number of phases ~1 (cosφ ~1 (cosφ 1.0) ~3 (cosφ 0.8) (power factor 1.0) cosφ) Rated frequency 50 Hz 6.0 kVA/6.0 Rated power 7.5k VA/6.0 kW 6.0 kVA/6.0 kW... -
Page 19: Ec Declaration Of Conformity
EC declaration of conformity Updated on: Declaration of conformity number: 01/10/2021 01/105453/2021 He issued a declaration of conformity: Hahn & Sohn GmbH Address of the issuer of the declaration of conformity: Auf der Schanze 20 93413 Cham Notified person: Notified person's address: Notified person's number: Power plant HDE9000... -
Page 20: Warranty Sheet
WARRANTY SHEET The equipment is subject to warranty if purchased from Hahn & Sohn GmbH or an Authorized Hahn & Sohn Regional Representative. The warranty is for 12 months or 500 motor hours from the time of purchase of the equipment. - Page 21 Performing any repairs during the warranty period outside of an authorized service will void the warranty. NO SILICONE OR OTHER ADDITIVES IN FUELS AND OILS! In the case of an accepted claim, the warranty is extended by the repair period. Claims without presentation of this warranty certificate including proof of purchase will not be accepted.
- Page 22 INSPECTIONS, ADJUSTMENTS AND CHECKS DESCRIPTION OF INSPECTION AND ADJUSTMENT| NUMBER OF DATE | SIGNATURE WORKS. OF THE SERVICE REPAIRS| SCOPE OF ACTIVITIES HOURS TECHNICIAN...
- Page 23 INSPECTIONS, ADJUSTMENTS AND CHECKS DESCRIPTION OF INSPECTION AND ADJUSTMENT| NUMBER OF DATE | SIGNATURE WORKS. OF THE SERVICE REPAIRS| SCOPE OF ACTIVITIES HOURS TECHNICIAN...
- Page 24 Central distributor and warranty provider Hahn & Sohn GmbH Auf der Schanze 20 93413 Cham Tel: +490 9944 890 9 896 www.hahn-power.de Hahn a syn s.r.o. Lelkova 186/4, 747 21 Kravaře www.hahn-power.cz...
