- Page 1 SERVICE MANUAL GLASSWASHER SINGLE SKIN XS-S Doc. SM_GW_XS-S Edition 01 - 03.2021...
- Page 2 Document made by Product Care - Technical Training & Service - Vallenoncello PN/Italy All the images and information of this document are property of ©Electrolux Professional Spa. This document and all of its contents cannot be copied or used, in part or entirely without the written authorization of Electrolux Professional Spa.
- Page 3 SERVICE MANUAL REVISIONS UPDATE EDITION DESCRIPTION DATE First publication of this manual March 2021 FOREWARD The service manual (here in after Manual) provides the engineer with information necessary for correct and safe use of the machine (or “appliance“, “machine” or “unit”). The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to improper operating procedures.
- Page 4 SERVICE MANUAL MODELS COVERED BY THE SERVICE MANUAL MODEL DESCRIPTION TYPE VOLTAGE GW (XS), SINGLE SKIN, 30B/H ELECT. 230V/1N/50Hz EXSR GW (XS), SINGLE SKIN, ROUND BASKET, 30B/H ELECT. 230V/1N/50Hz EXSP GW (XS), SINGLE SKIN, DRAIN PUMP, 30B/H ELECT. 230V/1N/50Hz EXSG GW (XS), SINGLE SKIN, DRAIN P., DET.
-
Page 5: Table Of Contents
SERVICE MANUAL 1 GENERAL INFORMATION MANUAL PURPOSE SAFETY PRECAUTIONS 1.2.1 Personal protection equipment DATAPLATE 1.3.1 Machine and manufacturer's identification data 1.3.2 Additional indications 1.3.3 How to interpret the factory description 1.3.4 How to interpret the serial number 1.3.5 Responsibility 1.3.6 Copyright 1.3.7 Recipients of the manual... -
Page 6: General Information
SERVICE MANUAL GENERAL INFORMATION 1.1 MANUAL PURPOSE The purpose of this manual is to provide useful information for all after-sales operations. In the manual there are some symbols of caution and danger: IMPORTANT! Note of particular importance WARNING! Risk of damage to the machine or the product. DANGER! Danger for the health and safety of operators. -
Page 7: 1.2.1 Personal Protection Equipment
SERVICE MANUAL DANGER! Interventions, tampering or not expressly authorized changes that do not • comply with the instructions in this manual may cause damage, injury or death and will void the warranty. DANGER! When working on the equipment maintain good ventilation in the room. •... -
Page 8: Dataplate
2.7 kW Boiler 2.5 kW IPX23 Electrolux Professional spa - Viale Treviso, 15 - 33170 Pordenone (Italy) Fig. 1 Data plate position (machine right) The main dataplate information can be viewed accessing the Service menu. Please refer to chapter §4.4.15.1 Dataplate. -
Page 9: How To Interpret The Serial Number
SERVICE MANUAL 1.3.4 HOW TO INTERPRET THE SERIAL NUMBER 1.3.5 RESPONSIBILITY The Serial Number on the data plate uniquely identifies: The Manufacturer declines any liability for damage and - The year of construction of the appliance; malfunctioning caused by: - The week of construction of the appliance; •... -
Page 10: General Reference To Applicable Product Certifications
SERVICE MANUAL 1.4.2 MAIN TECHNICAL DATA (E-Z-V-N)XS, S .. Model (E-Z)XS, S ..G6 (E-Z-N)XS, S ..DU, GU R, P, G, GC Voltage: 230/1N 230/1N 230/1N Frequency Maximum power input 2.89 2.89 2.89 Boiler heating power 2.70 2.70 2.70 Tank heating element 2.40 2.40 2.40... -
Page 11: Installation And Commissioning
Water quality affects the dosage of detergent and rinse aid. It is trongly raccomended Electrolux Professional C11 or C13 Detergent aid. It is trongly raccomended Electrolux Professional C12 or C14 Rinse aid. - Page 12 Drops of water on the glass indicate an insufficient dosage while streaks indicate an excessive dosage which can either be caused by the density or the quantity. It is trongly raccomended Electrolux Professional C12 or C14 3. Make sure washing rinsing, Rinse aid.
-
Page 13: Use Of Appliance
SERVICE MANUAL USE OF APPLIANCE OPERATING INSTRUCTIONS Please refer to the User Manual of the appliance available on website https://www.electroluxprofessional.com https://webgate.electroluxprofessional.com In case of any doubt, refer to your local country Customer Care. PREVENTIVE ROUTINES/MAINTENANCE FOR THE OPERATOR Please refer to the User Manual of the appliance available on website https://www.electroluxprofessional.com https://webgate.electroluxprofessional.com In case of any doubt, refer to your local country Customer Care. -
Page 14: Control Panel
SERVICE MANUAL CONTROL PANEL Doc. 59566Q200... - Page 15 SERVICE MANUAL ON/OFF button (A) Press this button to activate the appliance. Press it again to deactivate. ON indicator (B) when the appliance is on, the B indicator is lit up. Water temperature indicator (C) When the water in the tank and boiler reach the operating temperature, the C indicator is lit up. START button (D) This button starts washing cycle.
-
Page 16: Troubleshooting
4) Soaking the Wash/Rinse arms new one. It’s strongly suggested 2) Dishwasher is running in a solution of water and descale Electrolux Professional C11 or with-out detergent-aid; product, C13 Detergent aid, 3) Tank filter of machine It is strongly suggested Electrolux 3) Position the tank filter properly;... - Page 17 SERVICE MANUAL Type of General Anomaly Possible cause Instruction to User Service Action Anomaly description 1) Only use not-foaming products for professional dishwashers. It 1) Foam in wash tank; is strongly suggested Electro- lux 2) Check the correct Professional C11 or C13 Detergent chemical products pipes in aid and C12 or C14 Rinse aid;...
- Page 18 SERVICE MANUAL Type of General Anomaly Possible cause Instruction to User Service Action Anomaly description 1) Remove and clean the drain Glasswasher 1) Drain pump clogged; Drain pump out Loss of pump; cannot be 2) Drain pump faulty; Please call Service Center of order performance 2) Replace the drain pump;...
-
Page 19: Service The Appliance
SERVICE MANUAL SERVICE THE APPLIANCE LIST OF NEEDED TOOLS List of needed tools Please, refer to the Electrolux Professional Universal Spare Parts Catalogue. 6.1.1 ORDINARY TOOLS The following tools take part of the Kit of assorted tools [usp #0S1288] contained in the Tool trolley case [usp #0S1980]: •... -
Page 20: Components Layout
SERVICE MANUAL 6.2.1 COMPONENTS LAYOUT Control Panel Door With Hinges Filling Valve Tank Heating Element Boiler Heating Element Door Switch Pressure Switch Pcb Board Thermostats Detergent dispenser Rinse aid dispenser Washing pump Drain pump NOTE To access the components, remove the panelsas shown in the steps on Doc. -
Page 21: Panels
SERVICE MANUAL 6.2.2 PANELS Phases for the replacement of the panels. DANGER! Before any operation on the machine read Chapter 1 "Safety Precautions." To reinstall a part, follow the instructions in reverse order to those described below. Doc. -
Page 22: Door With Hinges
SERVICE MANUAL 6.2.3 DOOR WITH HINGES 1. Open the door 2. Remove the screws (4 pcs) from the basket guides 3. Pull the door by slipping it Doc. 59566Q200... -
Page 23: Control Panel
SERVICE MANUAL 6.2.4 CONTROL PANEL A3 Remove the screws (2 pcs) under the joint A4 Pull the upper panel by slipping it 1. Reverse the upper panel and put it over the door 2. Remove the interruptors/components Doc. -
Page 24: Door Switch
SERVICE MANUAL 6.2.5 DOOR SWITCH A3 Remove the screws (2 pcs) under the joint A4 Pull the upper panel by slipping it 1. Reverse the upper panel and put it over the door 2. Remove the nuts (2 pcs) over the door microswitch, then disconnect the microswitch wiring ... -
Page 25: Pressure Switch
SERVICE MANUAL 6.2.6 PRESSURE SWITCH A3 Remove the screws (2 pcs) under the joint A4 Pull the upper panel by slipping it 1. Reverse the upper panel and put it over the door 2. Remove the pressure switch pipe, remove the screw that fixes the pressure switch to the support ... -
Page 26: Pcb
SERVICE MANUAL 6.2.7 A3 Remove the screws (2 pcs) under the joint A4 Pull the upper panel by slipping it 1. Reverse the upper panel and put it over the door 2. Remove the screws (4 pcs) to divide the PCB from the support ... -
Page 27: Tank Heating Element
SERVICE MANUAL 6.2.8 TANK HEATING ELEMENT A1 Remove the screws (2 pcs) of the under door panel 1. Remove the nut from the tank heating element, then disconnect the tank heating element wiring 2. Gently bend the faston (2 pcs) of the tank heating element 3. -
Page 28: Inlet Water Filling Valve
SERVICE MANUAL 6.2.9 INLET WATER FILLING VALVE A1 Remove the screws (2 pcs) of the under door panel 1. Close the water inlet faucet 2. Disconnect the water inlet hose, valve exit hose, wiring connections and remove the water inlet valve Doc. -
Page 29: Boiler Heating Element
SERVICE MANUAL 6.2.10 BOILER HEATING ELEMENT A1 Remove the screws (2 pcs) of the under door panel 1. Remove the screws (2 pcs) of the thermostats support 2. Disconnect the boiler hose.The water is hot, pay attention! 3. When the boiler is empty, remove the nuts (3 pcs) 4. -
Page 30: Wash Pump
SERVICE MANUAL 6.2.11 WASH PUMP A1 Remove the screws (2 pcs) of the under door panel 1. Remove the inlet water valve group (don't disconnect the hoses) 2. Remove the screws (2 pcs) of the thermostats support 3. Remove the clamps (2 pcs) of pump aspiration-supply hoses, then disconnect the hoses 4. -
Page 31: Drain Pump
SERVICE MANUAL 6.2.12 DRAIN PUMP A1 Remove the screws (2 pcs) of the under door panel A6 Remove the back panel A2 Take out the dishwasher 1. Remove the screws (2 pcs) of the thermostats support A3 Remove the screws (2 pcs) under the joint 2. -
Page 32: Rinse Aid Pump
SERVICE MANUAL 6.2.13 RINSE AID PUMP A1 Remove the screws (2 pcs) of the under door panel 1. Unscrew the fixing nut 2. Remove the screws (2 pcs) of the thermostats support 3. Disconnect the rinse aid pump's pipes Doc. 59566Q200... -
Page 33: Detergent Pump
SERVICE MANUAL 6.2.14 DETERGENT PUMP A1 Remove the screws (2 pcs) of the under door panel 1. Remove the screws (2 pcs) of the thermostats support 2. Remove the detergent pump 3. Disconnect the detergent's pipes and wiring Doc. 59566Q200... -
Page 34: Peristaltic Hose Of Detergent Pump
SERVICE MANUAL 6.2.15 PERISTALTIC HOSE OF DETERGENT PUMP 1. Remove the screws (2 pcs) and the cover 2. Remove the inner pipe starting from the left side and turn clockwise the roller holder 3. Turn clockwise the roller holder 4. Remove the roller holder 5. -
Page 35: Thermostats
SERVICE MANUAL 6.2.16 THERMOSTATS A1 Remove the screws (2 pcs) of the under door panel 1. Remove the screws (2 pcs) of the thermostats support 2. Remove the screws (4 pcs) to take out the thermostats and disconnect the wirings 3. -
Page 36: Thermostop
SERVICE MANUAL 6.2.17 THERMOSTOP A1 Remove the screws (2 pcs) of the under door panel 1. Remove the screws (2 pcs) of the thermostats support 2. Move the connector on the terminal at the state you want to achieve (the thermostop is always disabled "OFF"). When the thermostop is activated "ON"... -
Page 37: Related Documents
SERVICE MANUAL RELATED DOCUMENTS ELECTRICAL WIRING DIAGRAM Please refer to Electrical Wiring Diagram available on web site https://www.electroluxprofessional.com https://webgate.electroluxprofessional.com HYDRAULIC CIRCUITS Pressure boiler without drain pump Pressure boiler with drain pump Doc. 59566Q200... - Page 38 Electrolux Professional SpA Viale Treviso, 15 33170 Pordenone, ITALY Fax (+39) 0434 380 201 https://www.electroluxprofessional.com https://webgate.electroluxprofessional.com...
