COLOUR TV RECEIVER
OWNER'S MANUAL
Please read this manual carefully
before operating the unit, and keep
it for future reference.
The Owner's Manual for the Follow Models:
21F9D, 21T9D, 21FA1, 21TA1, 21T9D(D),
21T9D(S), 21T9D(B) , 21FA11,21FA11-AM,
15F6B, HT-3768,HT-3728, 21FA1N, 21FA12,
21SF1N 21TA18-T,21FA12-AM,
21FA18-T 21NT1

Advertisement

Table of Contents
loading

  Related Manuals for Haier 21NT1

   Summary of Contents for Haier 21NT1

  • Page 1 OWNER'S MANUAL The Owner's Manual for the Follow Models: Please read this manual carefully 21F9D, 21T9D, 21FA1, 21TA1, 21T9D(D), before operating the unit, and keep 21T9D(S), 21T9D(B) , 21FA11,21FA11-AM, it for future reference. 15F6B, HT-3768,HT-3728, 21FA1N, 21FA12, 21SF1N 21TA18-T,21FA12-AM, 21FA18-T 21NT1...

  • Page 2: Table Of Contents

    CONTENTS Before Operation War nin g and C aut ion s....................... Ins tal lat ion ..........................Ant enn a con nec tio n ......................Pre par ati on fo r the r emo te co ntr ol ..................Pos iti on of k eys a nd pl ug- ins ....................Fro nt an d sid e pan el ......................

  • Page 3: Warning And Cautions

    Warning and Cautions 4. To prevent the TV set from firing 1. When you clean the TV set, please pull out the power plug from AC outlet. and electric shock, don't expose the Don't clean the cabinet and the TV set to rain or moisture. screen with benzene, petrol and other chemicals.

  • Page 4: Installation

    Installation Antenna connection Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an outdoor antenna .In different places, the suitable antenna type and position are different. twin-lead cable Antenna adapter Mixer additional purchase Antenna input 75 coaxial cable 75 standard...

  • Page 5: Position Of Keys And Plug-Ins

    Position of Keys and Plug-ins Front and side panel 21FA1/21TA1 Signal receiver VIDEO Power switch Power indicator Menu TV/AV switch L/R audio Volume down/up Channel down/up 21F9D/21T9D/21T9D(D)/21T9D(S)/21T9D(B) Signal receiver Power switch TV/AV switch Volume down/up Channel down/up Power indicator Menu 21FA11/21FA11-AM VIDEO L/R audio...
  • Page 6 Position of Keys and Plug-ins 21NT1 TV/AV switch L/R audio Menu Volume down/up VIDEO Channel down/up Power indicator Power switch Signal receiver Video C Input terminal Antenna Input socket Video Y Input terminal Video C Input terminal Video Output terminal...

  • Page 7: Using The Remote Control

    Using the Remote Control Buttons and Descriptions P.MODE S.MODE DC Standby button P.mode button No available Program Number Channel Selection Source button Call Screen display P+/P-: Channel Selection Exit button H.Lock button SOURCE System Adjust button INFO MUTE Sleep button Program Scan button No available S.mode button...

  • Page 8: Power On And Power Off

    Power On and Power Off Below are methods on how to power on/off the TV set with the switch on the TV and on the remote control. Power on/off Connect/disconnect to the power 1. Connect the power supply wire, then press power switch button, the power indicator will light, in several seconds the picture will appear on the screen.

  • Page 9: Viewing Tv Programs

    Viewing TV Programs The channels amount to 218 . Viewing TV programs How to select the TV program 1. Use the direct-digit choosing button Press the button from 0-9 to select a one digit channel. If you want to select a two-digit channel, press the Digit Select button and change it into two-digit mode, then press the number of the channel.

  • Page 10: Program Scan And Screen Display

    Viewing TV Programs (continued) Program scanning function is to let the television automatically scan all preconcerted channel program(about two seconds per channel). Program scan and screen display Program scanning function 1. If you want to scan the program s and select your favorite channel , just press the SCAN button, then the television will start scanning from the present channel with a...

  • Page 11: Favorite Program

    Viewing TV Programs (continued) Favorite program Favorite program setting Press FAVORITE button for long time to enter the menu as right figure. Press P+/- to select the favorite program and V+/- to adjust the channel. You could set 8 favorite programs.

  • Page 12: Tuning

    Tuning There are three ways of searching: automatic search, manual search and MFT (manual fine tune). You may operate it either on the TV or on the remote control. Here is mainly about the remote control. Automatic search Automatic search 1.

  • Page 13: Manual Search

    Tuning (continued) Manual search Manual search 1. Press P+/- button or the Direct-digit Choosing button to select a channel directly(take channel 1 for example). 2. Press MENU button MENU TUNING continuously, until select POS. EDIT TUNING menu. POS. SEARCH AUTO MEMORY 3.

  • Page 14: Mft

    Tuning (continued) MFT(manual fine tune) When you can't get a satisfactory picture and audio effect, you can fine tune to obtain. MENU 1. Press MENU button TUNING continuously, until select POS. EDIT TUNING menu. POS. SEARCH AUTO MEMORY 2. Press P+/- button to select POS EDIT and V + to enter.

  • Page 15: Skip

    Tuning (continued) Skip Skip After the programs are presetted, you can skip some programs to select your favorite channels only. 1. Press MENU button continuously, until select TUNING TUNING menu. POS. EDIT POS. EX. SEARCH AUTO MEMORY 2. Press P+/- button to select POS EDIT and V+ to enter.

  • Page 16: Adjusting The Picture And The Sound

    Adjusting the Picture and the Sound Multiple picture modes How to select the picture mode You may select the mode you want from the DYNAMIC five preset modes and one individual mode. P.MODE Press the P. STD button to select a mode you STANDARD like.DYNAMIC PICTURE, STANDARD MILD...

  • Page 17: Multiple Sound Modes And Setting The Sound

    Adjusting the Picture and the Sound (continued) Multiple Sound Modes and Setting the Sound How to select the sound mode S.MODE You can quickly select your most favored THEATER sound mode from the following four kinds of modes. NEWS Press the S.STD button to select the sound quality that you want.THEATER/ NEWS/STANDARD/USER can be STANDARD...

  • Page 18: C, Aut O Off A Nd Mu Te

    Adjusting the Picture and the Sound (continued) S.C.C, auto off and mute How to use the S.C.C(soft change channel) This TV set provides you with the function of S.C. C. When it is set "ON", the picture will fade in and fade out when the channel is changed.

  • Page 19: Setting The Timer

    Setting the Timer This TV set provides you with three timer functions such as timer on, timer off and sleep off. Timer off Timer off Using this function can turn the TV set automatically into standby status at the preconcerted time. 1.

  • Page 20: Sleep Timer And On Timer

    Setting the Timer (continued) Sleep timer and on timer Sleep timer Using this function, the TV set can be changed into the standby status after a period of preset time from when this function is activated. 1. The utmost time for this function is 120 minutes, and the time interval is 10 minutes.There are totally 12 kinds of off-time.

  • Page 21: Channels Appointment

    Setting the Timer (continued) The channels appointment function can help you conveniently preset program . At the preset time, the TV set will automatically change to the preconcerted channel. Channels appointment Channels appointment 1. Press MENU button continuously until select TIMER menu, press V+/- to enter.

  • Page 22: Setting The Other Function

    Setting the other Function Screen protection How to activate the function of screen protection If no signal has been received by the TV set,when the B.B function is set ON, the screen will change into the form on the right shows if the screen protection is set ON .

  • Page 23: Curtain Function,Calendar Display

    Setting the other Function (continued) Curtain function,calendar display How to use the Curtain function This TV set provides three types of Curtain function for you to select. 1. Press MENU button until select FUNCTION menu. FUNCTION MENU 2. Press P+/- button, and LANGUAGE ENGLISH move the indicator to...

  • Page 24: Cha Nne L Exc Han

    Setting the other Function (continued) The function of channel exchange will enable you to exchange any two programs and you can conveniently adjust the order of the programs due to your own need. Channel exchange Channel Exchange for example, to change between channel1 and 9 1.

  • Page 25: Setting The Lock

    Setting the Lock This TV set provides you with the LOCK function, you can choose it due to your need to protect your TV set. Changing your password Changing your password This TV set can set a four digit password, the original one is 0000, if you want to reset it, please follow the instructions below.

  • Page 26: Setting The Lock

    Setting the Lock (continued) Setting the Lock Setting the Lock There are TUNING LOCK, PRESET PROG. ,AV LOCK, CHILD LOCK and MAX.VOLUME five lock setting, you can set it due to your need. 1. Press the LOCK button, the LOCK SET UP H.LOCK PASSWORD ---- screen will show as the form...

  • Page 27: Game Control Buttons And Method Of Playing The Game

    Game This TV set provides you with the game, after entering the game, except the buttons that are appointed in the game( for example, the game button, P+/-and MODE, etc.)and the DC Stand by button, the other buttons cannot be used.

  • Page 28: Connecting Additional Equipments

    Connecting Additional Equipments Connecting additional equipments You can connect the DVD,VCR and stereo system to the AV output to enjoy a higher quality of picture and sound effect. An additional TV DVD, VCD or other units Video output VIDEO L-AUDIO-R Audio output Laser DVD with output terminal DVD, VCD or other units...

  • Page 29: Troubleshooting

    Troubleshooting *To assist in location possible faults use help guide below. BREAKDOWN PHENOMENON CHECKING SOUND PICTURE The aerial direction and connection Picture with snow Noise This is called ghosting which can be minimized with an outside aerial, and good quality cable and terminations.

  • Page 30: Specifications

    21FA11-AM 611 W x472 D x450 H 21TA18-T/21FA18-T 615 W x400 D x453 H 21FA12-AM 582 (W) X334 (D) X456 (H) (mm) 21NT1 Remote control Owner's manual Accessories Warranty card Battery(AA) Sound output power and sound system may differ from different models and countries.
  • Page 31 0090506298M...
