SERVICE MANUAL

Colour Television

Haier model:
21FA11-AM
Customer model:
HTAF21S

Advertisement

Table of Contents
loading

Related Manuals for Haier 21FA11-AM

Summary of Contents for Haier 21FA11-AM

  • Page 1: Service Manual

    CAUTION READ THIS MANUAL CAREFULLY TO DIAGNOSE TROUBLE CORRECTLY BEFORE OFFERING SERVICE . SERVICE MANUAL Colour Television Haier model: 21FA11-AM Customer model: HTAF21S...

  • Page 2: Table Of Contents

    CONTENTS Safety precautions……………………………………………………………..……………3 TV block dia g ram……………………………………………………………………..…….4 Replacement of memory IC………………………………………………………….……5 Service adjustment……………………………………………………………..…………...5 ICs functional description…………………………………………………………………8 Test point waveform………………………………………………………………………10 All ICs voltages……………………………..……………………………………………….10 Purity / convergence adjustment………………………………………………………11...

  • Page 3: Safety Precautions

    1. SAFETY PRECAUTIONS The design of this product contains special hardware, many Isolation Check circuits and components especially for safety purposes. For (Safety for Electrical Shock Hazard) continued protection, no changes should be made to the After re-assembling the product, always perform an isolation original design unless authorized in writing by the check on the exposed metal parts of the cabinet (antenna manufacturer.

  • Page 4: Tv Block Dia G Ram

    Block diagram TDA8378PS/N2 series with mono intercarrier sound demodulator...

  • Page 5: Replacement Of Memory Ic

    3. REPLACEMENT OF MEMORY IC 1. MEMORY IC. This TV uses memory IC. In the memory IC are memorized data for correctly operating the video and deflection circuits. 2. PROCEDURE FOR REPLACING MEMORY IC (1) Power off Switch the power off and unplug the power cord from AC outlet. (2) Replace IC Be sure to use memory IC written with the initial data values.
  • Page 6 Adjustable Items Direct access key Items Description Preset Remark “1” 5/6HSH Horizontal shift “2” 5/6VSL Vertical slop 5/6VAM Vertical amplitude 5/6SCL S-correction 5/6VSH Vertical shift 5/6VOF OSD Vertical offset HOF* OSD Horizontal offset “3” Black level offset R Black level offset G White point R White point G White point B...
  • Page 7 2. OP2 Function Description Preset Remark Bit 7 1=21dBμV 0=26dBμV Bit 6 1=Enable Bit 5 ARABIC_SET 1=Enable Bit 4 FARSI_SET 1=Enable Bit 3 CYRILLIC_SET Bit 2 EUROUP_SET 1=Enable Bit 1 AUTO_SOUND Bit 0 1=Enable 3. OP3 Function Description Preset Remark Bit 7 RUSSIA 1=Enable...

  • Page 8: Ics Functional Description

    7. OP7 Function Description Preset Remark Bit 7 FMWS 1=Enable Bit 6 HOTEL 1=Enable Bit 5 PROG_ID 1=Enable Bit 4 1=Enable Bit 3 TWIST 1=Enable Bit 2 BYELORUSSIAN 1=Enable Bit 1 UKRANIAN 1=Enable Bit 0 1=Enable 8. OP8 Function Description Preset Remark Bit 6...
  • Page 9 IREF Reference current input Vertical sawtooth capacitor TUNER AGC Tuner AGC output AUDEEM/SIFIN1 *1 Audio deemphasize or SIF input DECSDEM/SIFIN2 Decoupling sound demodulator GND2 Ground 2 for TV processor SNDPLL/SIFAGC *1 Narrow band PLL filter Automatic Volume Levelling HOUT Horizontal output FBISO Flyback input/sandcastle output AUDEXT...

  • Page 10: Test Point Waveform

    In 1 Ch 1 input Out 2 (+) Ch 2 output (+) 4. N301: Vertical output (TDA8357A) Symbol Function Symbol Function INV IN Input PUMP UP Pump up power INV IN Input V OUT Vertical output Pump up power V PRO Vertical protection V OUT Vertical output...

  • Page 11: Purity / Convergence Adjustment

    TDA8378 0.18 0.17 TDA8357 AN 7522N 2.75 0.35 24C08/PCF8598 8. PURITY / CONVERGENCE ADJUSTMENT...

  • Page 12: Purity Adjustment

    PURITY ADJUSTMENT WEDGE Demagnetize CRT with the demagnetizer. DEFLECTION YOKE Loosen the retainer screw of the deflection yoke. Remove the wedges. Input a green raster signal from the signal generator, and turn the screen to green raster. Move the deflection yoke backward. P/C MAGNETS Bring the long lug of the purity magnets on the short P: PURITY MAGNET...
  • Page 13 STATIC CONVERGENCE ADJUSTMENT 1. Input a crosshatch signal. 2. Using 4-pole convergence magnets overlap the red and blue lines in the center of the screen (Fig. 1) and turn them to magenta (red/blue). (FRONT VIEW) 3. Using 6-pole convergence magnets overlap the magenta (red/blue) and green lines in the center of the screen and turn them to white.
  • Page 14 MENU TV/AV STANDBY AV1-VIN AV1-AL AV1-AR CNS01 RS01 CS01 RS02 RS03 STANDBY(power) CNS02 RB05 RB04 RB03 RB02 RB01 1.8K 1.2K A6-5V R208 A6-5V N202 R278 R219 R220 R215 R222 R212 R211 1/6W-100 24C08 A6-5V 3.3K 3.3K 3.3K 3.3K 3.3K CN703 TU101 3.3K C207...
  • Page 15 Sincere Forever...
