Delta Talbott 16997-SD-DST Specification Sheet

16997-SD-DST
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
2 1/4"
(57 mm)
3 1/4"
2 1/2"
(83 mm)
(64 mm)
Max. Deck
Thickness
2 1/4"
(57 mm)
10 11/32"
1 1/16"
(263 mm)
(27 mm)
3 1/4"
(83 mm)
2 7/16"
(62 mm)
2 1/4"
(57 mm)
1 1/16"
(27 mm)
10 11/32"
(263 mm)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-K-16997-SD-DST Rev. A
5 1/2"
(140 mm)
8"
(203 mm)
5 3/4"
(146 mm)
8"
(203 mm)
Centers
36"
(914 mm)
10 1/2"
(267 mm)
3/8" Compression Fitting
5 1/2"
(140 mm)
8"
(203 mm)
5 3/4"
(136 mm)
2 1/2"
(64 mm)
Dia.
2 1/2"
(64 mm)
Max. Deck
36"
Thickness
(914 mm)
3/8" Compression Fitting
KITCHEN
FAUCETS
■ Talbott™ Series
■ Single Handle Deck Mount
■ 1, 2, 3 or 4 Hole Sink Applications
■ Optional Soap Dispenser
■ DIAMOND™ Seal Technology
■ Integrated Supply Tubes
■ 2-Function Pull-Out

STANDARD SPECIFICATIONS:

•
Single handle kitchen faucets for exposed
mounting on 1, 2, 3 and 4 hole sinks.
10 3/16"
•
Centermount or 8" (203 mm) centers with optional
(259 mm)
10 1/2 (267 mm) long escutcheon included.
•
8" (203 mm) high, 5 1/2" (140 mm) long
spout nestled in metal hub assembly, swings 120.
•
Spout is connected to valve body with a 53''
(1346 mm) long hose.
• Pull-out spout operates in an aerated or spray
mode via an easy push button.
•
Lever handle shall return to neutral position
when valve is turned off
•
Control mechanism shall be the diamond coated
ceramic cartridge.
•
Red/blue graphics on handle button to indicate
hot/cold temperature
•
Touch-Clean® sprayhead.
•
3/8" O.D. straight, staggered pex supply
tubes - 35" (889 mm) and 36" (914 mm) long.
•
Standard 3/8" (10 mm) compression gasket fittings.
35"
(889 mm) •
Integral double check valves in spout.
•
Recommended hole size 1 3/8".
•
Soap dispenser bottle holds up to 8 oz.

WARRANTY

•
Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from
defects in material and workmanship.
•
5 Year Limited Warranty for usage in all industrial,
commercial and business applications.

COMPLIES WITH:

10 3/16"
(259 mm)
•
ASME A1 12.18.1 / CSA B125.1
Indicates ADA compliance to
ICC/ANSI A117.1
•
IAPMO Listed
•
CSA Certified
®
0 69 138 207
6
5
4
35"
(889 mm)
3
2
1
0
0 10 20 30
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
.
.
U P
C
®
Pressure (kPa)
276 345 414 483 552 621
22.7
18.9
15.1
11.4
7.6
3.8
0
40 50 60 70 80 90
Pressure (PSI)
