DESCRIPTION
Demonstration circuit 1033B features the
cropower, multipurpose, pushbutton On/Off PowerPath™
controller that provides voltage monitoring and supervisory
features, as well as ideal diode power paths. Selectable
PowerPath management modes allow a variety of power
on and off configurations, including pushbutton on/off
control and voltage detection on/off control.
The LTC2952's pushbutton input has independently pro-
grammable ON and OFF de-bounce times. A simple micro-
processor interface allows for proper system housekeeping
prior to power down. The status of digital pins G1STAT,
PFO, RST and INT are displayed with LEDs. Under system
fault conditions, the part's internal KILL timer ensures that
the system can be shut down. High reliability systems may
PERFORMANCE SUMMARY
PARAMETER
Input Voltage Range
Output Voltage V
S
DC/DC Out 2P6V
V2 Trip Threshold
Power Fail Input Voltage PFI
Voltage Monitor VM
Pushbutton On Time ONT
Pushbutton Off Time OFFT
* V
will be the ideal diode OR of V1 and V2. There is only a slight voltage drop across the ideal diode.
S
Arrow.com.
Downloaded from
LTC
2952, a mi-
utilize the LTC2952's power fail, voltage monitoring, diode
©
status, watchdog and μP reset features to monitor power
status and ensure system integrity.
The DC1033B operates over the full LTC2952 range of 2.7V
to 28V to accommodate a wide variety of input power sup-
plies. Low forward drop ideal diodes and very low standby
current (25μA typ) make the LTC2952 ideally suited for
battery powered or power conscious applications.
Design files for this circuit board are available at
http://www.linear.com/demo/DC1033B
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and
PowerPath is a trademark of Linear Technology Corporation. All other trademarks are the
property of their respective owners.
Specifications are at T
CONDITIONS
V1 and/or V2
Configuration A
Configuration B
Configuration C, Pushbutton Enable On
Configuration D, Pushbutton Enable On, V2 > V2 Threshold
Configuration A-D, Pushbutton Enable On
Default Resistors (R9 and R10), JP2 Set to Monitor V2
Default Resistors (R3 and R4) Monitor V
Resistor Options (R17 and R4) Set to Monitor V2
Default Resistors (R1 and R2) Monitor 2P6V
Resistor Options (R16 and R2) Set to Monitor V
JP3 Set to OPEN, LTC2952 Default ONT
JP3 Set to CAP to Connect 22nF to ONT Pin
JP4 Set to OPEN, LTC2952 Default OFFT
JP4 Set to CAP to Connect 68nF to OFFT Pin
DEMO MANUAL DC1033B
Pushbutton On/Off
Power Path Controller
= 25°C
A
VALUE
2.7V to 28V
V1 or V2*
V1 or V2*
V1 or V2*
V1 or V2*
2.6V
4.725V
3.055V
S
3.055V
2.325V
3.055V
S
26ms
26ms + 205ms
26ms
26ms + 632ms
LTC2952
dc1033bf
1
