Note: Post Mounting Hardware is NOT included in this kit. Please confirm with your
local building permit office to determine the correct hardware in your area.
If you plan to paint or stain your Spa Breeze before assembly, be sure to scribe or mark
the top edge of Joist where Stub Joists and Ladder Blockings are pre-marked. Painting
or staining may cover up markings making it more difficult to align components later.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any Outdoor Living Today
products.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
9'X11' Spa Breeze
Assembly Manual
Outdoor Living Today
www.outdoorlivingtoday.com
Page 1
Revision 2
March 24, 2009
sales@outdoorlivingtoday.com
Advertisement
Related Manuals for Outdoor living today 9'X11' Spa Breeze
Summary of Contents for Outdoor living today 9'X11' Spa Breeze
- Page 1 Outdoor Living Today products. In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase.
- Page 2 9X11 SPA BREEZE PERGOLA 3 LADDER SECTIONS 90” Thank you for purchasing one of our Breeze Pergola's. Please take the time to identify all the parts prior to assembly. Hardware Kit Includes; Parts Lists: Finished Size 4” , 2 1/2” Screws Qty.
-
Page 3: Hardware Kit
9x11 BREEZE PERGOLA HARDWARE PACKAGE Hardware Kit (Provided) Note: screws and nails shown actual size. 1 1/4” 4” Finishing Square 2 1/2” Drive Bit Wooden 2” Dowel (8) Stainless Lag Screw and Washer (16 each) Tools Required (Not Provided) Hammer Wood Clamp 9/16”... - Page 4 Important - Western Red Cedar Lumber and Laying out your Footprint Timbers will have surface splitting that occurs as lumber seasons and drys to the moisture To determine the proper placement of your content in your area. Splitting or “checking”, as 5 3/8”...
- Page 5 Important- You will require the assistance of 2 helpers to support the posts up to Step 7. Lift up a completed Post/Girder Assembly slowly Girder facing and carefully. Make sure out. Girder is facing outward. If Post Mount Hardware is installed, position bottom of Posts in Hardware.
- Page 6 Carefully lower (C) Girder down into notch of (B) Girders. Be careful not to twist the Girder when dropping down into place. Lag Screw Girder to Post. Pilot hole first. Note; Pilot hole Post with 1/4” drill bit. 2 Lag Screws to Post Lift, position and Lag Bolt the second (C) Girder to Posts.
- Page 7 With Stub Joists positioned correctly on Joist, attach each Stub Joist with 2 - 2 1/2” screws. Stub Joists should be flush with top and bottom of Joist with all notches facing down. There are two Joist / Stub Joist Assembly’s, complete both now.
- Page 8 On a flat surface, position Ladder Blocking (F) where marked on top edge of Joist (D) and screw with 2 - 2 1/2” screws per end. Ladder Blocking should be flush with top and bottom of Joist with all notches facing down. 2 - 2 1/2”...
- Page 9 Notched slides onto Girder Carefully slide Joist notches of Ladder Section onto Girder. Try to align notches so they fall into place all at once. With notches of Ladder Section all sitting correctly on Girder, slide Section approximately 7” from Post.
- Page 10 (H) Right Side There are 4 Left (G) and 4 Right Sided Corner Bracket Corner Brackets (H). Corner Bracket Post Mounts (I) must be attached to the bottom end of each Corner Bracket before attaching to Posts. Wooden Dowel (I) Corner Bracket Post Mounts...
- Page 11 4” screws countersunk 1/2” below surface. Bracket Left Sided Spacer flush Corner Bracket with bottom of Girder. Important- Posts may need to be aligned so they are true and square to mount Corner Brackets correctly. Use a Level to determine correct Post position. Lift completed Left Sided Corner Bracket up and align bottom of Bracket Spacer flush with bottom of Girder.
- Page 12 With several helpers, position Spa between Posts. Skirting (K) Post Skirting - Slotted (J) To complete your Breeze, attach Post Skirting around each post. Position 2 Slotted Post Skirting Pieces (J) on opposite sides of Post. Slide a Post Skirting (K) between grooved slots until flush at top. Align Post Skirting Cap (L) tight against Post and equally from side to side of skirting framing.
- Page 13 Slide in 2nd Post Skirting piece and position and nail Post Skirting Cap as per Step 26. Place remaining Post Skirting Caps on Skirting and nail as per Step 26. Complete remaining Post Skirtings. Alignment String Lift and position 2 - 2x2 Cross Members (M) up against outside Posts on both sides. Align with outside of B-Girders.
- Page 14 2nd Interior Stub Joist. Using the 2x2 Cross Member Templates, align and attach interior 2x2’s starting at the 2nd interior Stub Joist. Use 4 Members spaced 5 1/4” apart. Attach as per Step 29. Continue attaching 2x2’s using Template for spacing and positioning ends with alignment strings. Attach as per Step 29.
- Page 15 Leg Support Brackets have 1/8” Pilot Holes drilled. Support Bracket Place Leg Support Bracket (R) in corner and attach to Bar and Leg framing with 2 - 2 1/2”screws through pre-drilled holes in brackets. Complete 2 brackets per leg. End Panel Center Leg Panel Complete remaining Leg Panels (center and end) following alignment and attachment...
- Page 16 Please call, write or email us at: contained on the materials. No material may be Outdoor Living Today Partnership modified, edited or taken out of context such that its P.O. Box 96...
