In the event of a missing or broken piece, simply
call the Outdoor Living Today Customer Support
Line @ 1-888-658-1658 within 30 days of the
delivery of your purchase. It is our commitment
to you to courier replacement parts, free of
charge, within 10 business days of this
notification. Replacement parts will not be
provided free of charge after the 30 day grace
period.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any Outdoor Living Today
products.
Outdoor Living Today
5' X 11' Breeze Walkway
Assembly Manual
Outdoor Living Today
Important - Western Red Cedar Lumber and
Timbers will have surface splitting that occurs
as lumber seasons and drys to the moisture
content in your area. Splitting or "checking", as
it is referred to, can be 1/8" to 1/4" wide and can
run several feet. This does not diminish the
structural integrity of the material in any way.
www.outdoorlivingtoday.com
Page 1
Version #2
July 17/2009
sales@outdoorlivingtoday.com
Advertisement
Related Manuals for Outdoor living today 5' X 11' Breeze Walkway
Summary of Contents for Outdoor living today 5' X 11' Breeze Walkway
- Page 1 Replacement parts will not be provided free of charge after the 30 day grace period. Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper installation, maintenance and repair of any Outdoor Living Today products.
- Page 2 59 1/2” Inside Width Post to Post: 90” Q -2x2 Cross Member Template (not Shown)1 1/2” 1 1/2” 5 1/4” Outside Depth Post to Post: 41 1/2” Outside Depth Post to Post: 30 1/2” Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 2...
- Page 3 Post. B- Girders are 59 1/2” long and have top deep notches (2 3/4”). Complete 2 sets of Girder /Post Sections. May want to consider drilling 1/4” pilot holes to assist in inserting lag bolts. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 3...
- Page 4 Post / Girder section to Post Hardware. position between both B-Girder / Post Assemblies. The E-Girder has a deep notch facing down on each end and is 138” long. Deep Notch facing down. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 4...
- Page 5 E-Girder to Posts. Pre-marked for Stub Joist placement On level ground, position 1 Main Joist (D) and 6 Stub Joists (I).Main Joists are pre-marked for Stub Joist Notches facing down and Blocking position. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 5...
- Page 6 Attach all Stub Joists and Main Joist to girders with 1 - 4” screw per 4” long piece. Complete screws both assemblies. Consider drilling 1/8” pilot holes to assist in screw insertion. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 6...
- Page 7 Lower and position Ladder on H-Side Girders evenly between Posts so notch of joist sits on H - Girder. Attach Ladder to H-Side Girders with 4 - 4” screws per Ladder. Screw from top down into girder. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 7...
- Page 8 With Bracket and Post Mount correctly aligned, screw Post Mount to Bracket with 2 - 2 1/2” screws. Important- Drill pilot holes in Post Mounts and Bracket to prevent wood from splitting! Complete all remaining Brackets/Post Mount connections. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 9 Post with 6 - 2” Stainless mount to girder and joist/blocking Steel Screws. Attach with 2 - 3” screws per side. remaining Corner Brackets to Posts. There will be two brackets per post. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 9...
- Page 10 Skirting Slide in 2nd Post Skirting piece and position and nail Post Skirting Cap as per Step 28. Place remaining Post Skirting Caps on Skirting and nail as per Step 28. Complete remaining Post Skirtings. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 11 2nd Interior Stub Joist Using the 2x2 Cross Member Templates, align and attach interior 2x2’s starting at the 2nd interior Stub Joist. Use 4 Members spaced 5 1/4” apart. Attach as per Step 25. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 11...
- Page 12 Please call, write or email us at: be downloaded or copied provided that ALL copies retain the copyright and any other proprietary notices Outdoor Living Today Partnership contained on the materials. No material may be P.O. Box 96 modified, edited or taken out of context such that its...
