LEGRAND WattStopper HDLS1SS Series Installation Instructions Manual

HDLS1SS-x /2SS-x/4SS-x/8SS-x
There are four basic Dataline Switch configurations:
the single-gang, 1-, 2- and 4-button HDLS1SS-x,
HDLS2SS-x and HDLS4SS-x, respectively, and the
two-gang, 8-button HDLS8SS-x.
Each switch includes bi-color LED status lights as well
as a locator light. In addition, the 2-, 4- and 8-button
units accept standard 3 / " wide (9 mm) identification
8
labels.
The -x suffix in the catalog number refers to button and
switchplate color:
2 = ivory, 4 = almond, 7 = white and 9 = grey.
Any button on a Dataline Switch may be smartwired to:
• Any relay or group of relays within a single panel.
• A channel within a single panel or the same channel
throughout multiple panels.
• A Complete Control group code. See WinControl
documentation for additional information.
These instructions cover wiring and testing of the Local
Dataline and Dataline Switches, manual smartwiring
of the switches, and documenting the switch and relay
configuration.
If your installation is using the HCLK8SS Network
Clock, HBMS8SS Building Management System
Interface Module, AA-Base Automation Appliance, or
Lighting Integrator Complete Control panels please
refer to the documentation provided with those
products for additional programming information.
Before proceeding, read the instructions on the
following pages. For an overview of the entire
system and the documentation forms, refer to the
other sections of the Lighting Integrator Installation
and Operation Manual.
If you have any questions, call Technical Support at:
800.879.8585.
Santa Clara, CA 95050
Lighting Integrator Dataline Switch
Installation and Operation
