Teradek User Manual
Serv 4K (2024) Quick Start Guide
Serv 4K lets you securely stream live camera feeds and instant recordings to anyone, anywhere, on
or off set. See what the camera, editor, and colorist see—from production through final color. Serv
4K can encode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity, can stream to up to 20
local viewers when connected to a WiFi network in Client mode (10 viewers when using Serv 4K in
AP mode) when using VUER, and can be connected to Teradek's Core Cloud Platform for even more
flexibility.
Serv 4K (2024) Quick Start Guide
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Serv 4K and is the answer not in the manual?

Questions and answers

Related Manuals for Teradek Serv 4K

Summary of Contents for Teradek Serv 4K

  • Page 1 4K can encode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity, can stream to up to 20 local viewers when connected to a WiFi network in Client mode (10 viewers when using Serv 4K in AP mode) when using VUER, and can be connected to Teradek’s Core Cloud Platform for even more flexibility.
  • Page 2 Teradek User Manual TABLE OF CONTENTS...

  • Page 3: Physical Properties

    • 1x 2 pin Connector to Power Tap (D-Tap) - 18in cable • 1x SDI - BNC to BNC Cable - 10in cable • 1x PSU 2pin Connector to 30W AC Adapter (Int) - 6ft cable • 2x Antenna 2dBi WIFI 2.4/5.8GHz Serv 4K (2024) Quick Start Guide Page 3...

  • Page 4: Power And Connect

    Teradek User Manual POWER AND CONNECT 1. Connect power to Serv 4K using the included A/C adapter or D-Tap cable to a battery. 2. Attach the two Wi-Fi antennas to the RP-SMA connectors (D). 3. Connect your video source's HDMI or SDI output to Serv 4K’s input connector or L).
  • Page 5 • Link/Unlink iOS Device (2)- Tap the Link/Unlink iOS button to use of your cellphone’s data as an Internet connection for streaming to Core. STATS Tap the Stats button (3) at the top of the screen to display Serv 4K’s serial number, current audio and video bitrates, runtime, recording status, IP address, and network. SETTINGS...

  • Page 6: Get Online

    • System - View the model and serial number of your device, or rename the Serv 4K. GET ONLINE You can use the front panel interface, web UI, or Serv App to control and configure Serv 4K to connect to a network.

  • Page 7: Configure Node

    Connect via Node II or USB Modem 1. Attach a Node II or USB modem to one or both to Serv 4K’s USB-C ports (I), then press the MENU button on the front panel to navigate to the Modem screen and verify that the modem has been detected and connected.
  • Page 8 Node II. Only one SIM card can be used at a time. 3. If applicable, configure the modem by entering an APN or select the Teradek Data configuration you have purchased. Serv 4K (2024) Quick Start Guide Page 8...
  • Page 9 Serv 4K encoders have a 1/4”-20 threaded hole on the bottom for mounting. Additionally, you can install dual mount pro battery plates on your Serv 4K, allowing you to attach your unit to either the back of a camera or monitor.

  • Page 10: Record To Sd Card

    Teradek User Manual RECORDING Serv 4K encoders support recording to an SD card or NFS drive. Each recording is saved with the same resolution and bitrate set in Serv 4K. Record to SD card 1. Insert a compatible SD card into the corresponding slot (J).

  • Page 11: Cloud Services

    1. From the web UI, select Cloud Services then click the Link this Device tab. 2. Log in to Core: Enter your credentials to link Serv 4K to your Core account, then click Next. Link with Code: Copy the authorization code generated for your Serv 4K, then follow the instructions provided.
  • Page 12 Teradek User Manual 3. Once a connection is established, you can configure Serv 4K from either the web UI or Core dashboard. Frame.io Frame.io is a collaboration platform that allows video producers and editors to privately upload, review and share media with their entire crew from anywhere in the world. NOTE: You must first have a subscription before you can use Frame.io.
  • Page 13 4. Enter a project name, then toggle the C2C Connections switch to enable your Serv unit to upload video. Click the Create Project tab. 5. Click the C2C Connections tab above, then click the Add new device tab (see image). Serv 4K (2024) Quick Start Guide Page 13...
  • Page 14 6. Click the Device ready to connect tab, then enter the authorization code. Click Authorize, then click Finish. 7. If successful, Serv 4K will be listed under the C2C Connections tab (see image). All future recordings will be listed under the Media tab.
  • Page 15 Make your selection, then tap APPLY. PRO BATTERY PLATE INSTALLATION Teradek’s Pro Battery Plates allow users to mount a Serv 4K unit to the back of a camera or monitor (Male), and/or attach a compatible battery for pass-through power (Female).
  • Page 16 4. Position the female/battery-side plate (5) on the opposite side of the unit so that the screw holes on the plate align with the holes on the unit. 5. Insert the Phillips head screws through the plate and into the unit, then tighten. Serv 4K (2024) Quick Start Guide Page 16...

  • Page 17: Other Resources

    Teradek User Manual OTHER RESOURCES • SERV 4K QUICK START GUIDE PDF: https://teradek.com/pages/downloads#serv-4k • SERV 4K SUPPORT ARTICLES: https://support.teradek.com/hc/en-us/categories/ 115000127753-Serv-Pro Serv 4K (2024) Quick Start Guide Page 17...
