  • Page 1 Quick Setup Guide Model: QN-H-240...
  • Page 2: Copyright Information

    Copyright Information 2 | www.qntmnet.com...
  • Page 3: Table Of Contents

    Contents Glossary ............................ 4 Icon description ........................4 Before you begin ........................5 Package contents ........................5 Prerequisites ..........................5 Network requisites ........................5 Connect Access Point ......................5 Step 1 – Create new account on Quantum Rudder ............6 Step 2 - Basic setup ........................
  • Page 4: Glossary

    This Quick Setup Guide provides step-by-step instructions on how to set up Quantum Networks Access Point. After completing the steps described in this Guide, you will be able to install the Access Point (AP) on-site and provide wireless network access to users. Glossary Feature Description...
  • Page 5: Before You Begin

    Before you begin Your Quantum Networks Access Point can work in “Standalone Mode” or can be managed by “R udder ”. Package contents Access Point. Mounting kit Prerequisites Internet access. Desktop / Laptop / Handheld device. 802.3af / 802.3at PoE Switch / PoE Injector.
  • Page 6: Step 1 - Create New Account On Quantum Rudder

    Once the account gets validated, it turns the page to “Add License Key” (User will get the license key from respective (Partner / Resource) ) Account on Quantum Rudder (Quantum Networks Cloud Controller) is now ready to use. 6 | www.qntmnet.com...
  • Page 7: Step 2 - Basic Setup

    Step 2 - Basic setup Connect the WAN port of the Access Point to the network with Internet access. You should see a new wireless network with SSID QN_XX:XX (where XX:XX are the last four digits of Access Point MAC Address). Connect to QN_XX:XX SSID and browse Access Point’s default IP “169.254.1.1”.
  • Page 8: Step 3 - Setting Up Device Ip Address

    Step 3 - Setting up device IP address Click “Configure” and set the device IP address by selecting the required options. Connectivity Mode – Select the connectivity mode. Protocol - DHCP, Static or PPPoE Interface – Select interface VLAN Assignment- Enable parameter. Enter VLAN ID and click “Fetch IP Address” to get the respective IP in case of VLAN setup is required.
  • Page 9: Step 4 - Set The Management Mode

    Step 4 – Set the management mode Management Mode Quantum Networks Access Point can be configured in two modes: Rudder (on cloud / on -premise) Centralized management of Access Points using Quantum Rudder Standalone Independent management of each Access Point Figure 4 9 | www.qntmnet.com...
  • Page 10: Step 5 - Access Point Quick Setup In Rudder Mode

    Step 5 - Access Point quick setup in R udder Mode Select “Management Mode” as “Rudde r”, enter Quantum Rudder login credentials and click “Proceed” . In the case of on-premise RUDDER, mention the local server IP Address/URL assigned to RUDDER, here.
  • Page 11 Upgrade QNOS version by either downloading from the cloud or by selecting manually from respective location and upgrade or click “Skip Upgrade ” to move further. The user will turn to a page where the user has to select the site and AP group. Figure 7 Select Rudder site and AP Group where Access Point’s needs to be added and click “Proceed ”.
  • Page 12 Figure 8 Figure 9 Bridge Select option Bridge and click “Proceed” . Configure WLAN (SSID) parameters and click “Proceed” . Parameter Value WLAN Name Define a name for the network SSID Define visible wireless network name Passphrase Configure a passphrase for SSID Note: If you do not want to create WLAN (SSID)/LAN now, click the Skip option.
  • Page 13 Review the Configuration Summary. Click “Reconfigure” if any changes are required or click “Proceed” to complete the configuration. Figure 11 Router Select option Router and click “Proceed” . Configure WLAN (SSID) and Local subnet parameters and click “Proceed” . Parameter Value WLAN WLAN Name...
  • Page 14 Figure 12 Figure 13 Note: If you do not want to create WLAN (SSID)/LAN now, click the Skip option. It will turn to Configuration Summary . Review the Configuration Summary. Click “Reconfigure” if any changes are required or click “Proceed” to complete the configuration. 14 | www.qntmnet.com...
  • Page 15: Step 6 - Access Point Quick Setup In Standalone Mode

    Step 6 - Access Point quick setup in standalone mode Figure 14 Select “Management Mode” as “Standalone” if each Access Point is to be configured and managed individually. Define username and password for the device and click “Proceed ”. User can select Access Point Operation mode as Bridge or Router . Figure 15 15 | www.qntmnet.com...
  • Page 16 Bridge Select option Bridge and click “Proceed” . Configure WLAN (SSID) parameters and click “Proceed” . Parameter Value Country Select country for radio management. Timezone Select timezone for Rudder management. WLAN Name Define a name for the network. SSID Define visible wireless network name. Passphrase Configure a passphrase for SSID.
  • Page 17 Router Select option Router and click “Proceed” . Configure WLAN (SSID) and Local subnet parameters and click “Proceed” . Parameter Value WLAN Country Select country for radio management. Timezone Rudder Select timezone for management. WLAN Name Define a name for the network. SSID Define visible wireless network name.
  • Page 18: Reset Access Point To Factory Defaults

    Reset Access Point to factory defaults Power on the Access Point Push the reset button on the back panel and hold it for 10 seconds. Access Point would restart with factory defaults Access Point default login detail With standalone mode: User Name: Created while doing "Quick Setup"...
  • Page 19: Fcc Statement

    FCC statement FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 20: Ce Statement

    Warning: The installation position must be carefully selected so that the final output power does not exceed the limit set forth in relevant regulations. Violation of output power regulations could lead to serious federal penalties. CE Statement This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment.
