Summary of Contents for Quantum Networks QN-I-200
- Page 1 Access Point User Guide Models: QN-I-200, QN-I-220, QN-O-230...
- Page 2 Copyright & trademark specifications are subject to change without prior notice. Copyright © 2018 Quantum Networks (SG) Pte. Ltd. All Rights Reserved. Quantum NetworksTM& the logo are trademarks of Quantum Networks (SG) Pte. Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Introduction ..........................4 Access Point Overview ....................... 4 Package Contents ....................... 4 Unpacking the Access Point ....................4 Glossary ............................ 5 Pre-configuring Access Point in standalone Mode ............6 Navigation ..........................8 Navigating the web Interface ..................... 8 AP Configuration ........................9 Dashboard .......................... -
Page 4: Introduction
Access Point Overview This document explains how to configure and manage standalone Access Point. Quantum Networks Wireless APs are the industry's most facile to utilize. It’s a feature-opulent Wi-Fi APs designed to bring power and simplicity together for sizably voluminous-scale indoor deployments. -
Page 5: Glossary
Glossary Following terms are frequently used in this manual. Term Definition Access Point DHCP Dynamic Host Configuration Protocol (DHCP) is a network protocol that enables a server to automatically assign an IP address to concern devices. Static A static address is a fix IP address assigned to the device. PPPoE PPPoE stands for Point-to-Point Protocol over Ethernet, a network protocol for encapsulating Point-to-Point Protocol (PPP) frames inside Ethernet... -
Page 6: Pre-Configuring Access Point In Standalone Mode
Pre-configuring Access Point in standalone Mode AP default SSID is QN_XX: XX (where XX:XX= last four digits of AP MAC ID). Connect QN_XX:XX SSID and enter AP default IP 169.254.1.1 in browser. Click on start configuration. Figure 1 ... -
Page 8: Navigation
Navigation Navigating the web Interface Open Web Browser and enter configured IP address of the Access point. Below screen will appear. Figure 4: AP Web Login Page Enter Username and Password (use the same created while quick setup process), click on Login and get below screen. -
Page 9: Ap Configuration
AP Configuration Dashboard Select Configuration > Dashboard. Dashboard screen appears. Figure 6: Dashboard Statistics Statistics Description AP Name Name of Access Point Device Location Access point location GPS Coordinates Displays GPS coordinates Managed By Displays AP managed by QN cloud or as standalone Mode Displays AP selected mode Bridge / Gateway Device Model... - Page 10 Connected Clients Parameter Description Radio Displays radio detail through which clients has been connected. SSID Displays SSID name through which clients has been connected. Displays MAC address of connected client device. Displays IP address taken by host device Hostname Displays Host name RSSI Displays wireless signal strength.
-
Page 11: Configuration
Configuration Device Select Configuration > Device. The Configuration > Device page appears. Figure 7: Device General Setting Parameter Description Default Value Device Name Type Device name of your choice. The device name identifies the AP among other devices on the network Device Location &... - Page 12 Parameter Description Default Value Regulatory Select country Singapore Country Channel Bandwidth: Choose channel bandwidth Auto (20 from dropdown. It can be Auto / Auto (40/20 Mhz) or Mhz) Auto (20 Mhz). wider channel width means fewer channels available, and more interference with other Wireless 2.4 Wireless signals.
-
Page 13: Internet
Internet Select Configuration > Internet. The Configuration > Internet page appears. Figure 10: Internet setting WAN Configuration Parameter Description Select IP Schema Type DHCP / Static or PPPoE as per the requirement. DHCP - Displays currently- WAN Port: Select port which needs to be configuring assigned IP address and as WAN. - Page 14 WAN Security Parameter Description WAN Security Enable WAN Security when Access point is in Gateway mode and need to maintain network security. WAN Security option available only when AP is configured in Gateway mode. This feature protects AP and LAN devices from unauthorized access from WAN.
-
Page 15: Local Subnet
Local Subnet Local Subnet is available when AP is in Gateway mode. Select Configuration > Local subnet >Add. The Configuration > Local subnet page appears. Figure 13: Local Subnet Parameter Description Name Type Local Subnet name of your choice. IP Address Enter an IP address for the gateway. -
Page 16: Bridge Profile
Figure 14: Local Subnet –DHCP Reservation With this feature user can provide fix IP address to the clients. As a result whenever the respective client connects to this Local Subnet, he will get the dedicated fix IP address always. Bridge Profile Select Configuration >... -
Page 17: Wireless
Wireless Select Configuration > Wireless > Add. The Configuration > Wireless page appears. Figure 16: Wireless General Setting Parameter Description Default Value WLAN Name This Wireless LAN name is unique name for management purposes only and is not visible to wireless clients. Broadcasting The SSID name that is visible by the wireless clients SSID... - Page 18 Figure 17: Wireless WLAN Setting Parameter Description Default Value Option 1 Access Type : Standard Access Type Standard Auth. Method Open Auth. Method : Open Option 2 Access Type Hotspot (WISPr) Auth. Method Open Hotspot Profile Select pre-configured Hotspot profile from dropdown Option 3 Access Type Standard...
- Page 19 Important Note: Hotspot (WISPr): To select “Access Type” Hotspot (WISPr), first need to create Hotspot Profile. To create Hotspot Profile, go to Site > Configuration > Hotspot > Add Parameter Detail Description Authentication Open: Any encryption method can be used. It allows you to method configure a WPA2 or WPA-Mixed or "none"...
- Page 20 Parameter Detail Description Algorithm AES: This algorithm provides enhanced security over TKIP, and is the only encryption algorithm supported by the 802.11i standard. TKIP: TKIP is a stopgap encryption protocol introduced with WPA to replace the very –insecure WEP encryption at the time. Encryption WPA2: WPA encryptions that comply with the 802.11i security standard.
-
Page 21: Ethernet Ports
Ethernet Ports Select Configuration > Ethernet Port. The Configuration > Ethernet Port page appears. Figure 20: Ethernet Port Setting Parameter Description Default Value Type This option is used to configure the virtual- Port : Enabled LAN (VLAN) parameters for the Ethernet Type : Trunk Port ports on the AP. -
Page 22: Hotspot
Hotspot Select Configuration > Hotspot. The Configuration > Hotspot page appear Figure 21: Hotspot Profile Setting Parameter Value Description Hotspot Profile Name Name of hotspot PROFILE. Auth Profile Server IP Address RADIUS server primary IP address. Secondary Server Radius server secondary IP address. Authentication Port Radius server authentication port Accounting Port Radius server Accounting port... - Page 23 SNMP Select Configuration > SNMP. The Configuration > SNMP page appear. Figure 22: SNMP Setting Parameter Description Enable SNMP To enable SNMP client services. Server SNMP server IP address. Server SNMP backup server IP. Port SNMP communication port on server. Community Community string.
-
Page 24: Management
Management Use the Management option to perform below listed management task. To Upgrade Access Point Firmware. To Perform Reboot device. To Perform Restore Configuration to Factory Default. Figure 23: Management option setting Management Firmware Upgrade Current Version Displays Current running firmware version of the Access Point. -
Page 25: Diagnostics
Diagnostics Diagnostic option is a tool for diagnostics and connectivity test. Figure 24: Diagnostics Diagnostics Ping Ping utility to manually check the connectivity of a particular LAN/WAN connection. Trace route Trace route utility to analyze the connection path of a LAN/WAN connection. - Page 26 Logs Logs option is a tool to view Logs. Figure 24: Logs...
- Page 27 Education, SOHO, Hot- Spots, NGOs, Healthcare, Budget Hotels, Hostels and so on. Feel free to contact us directly on below addresses. Thanking you again! Team Quantum Networks (SG) Pte. Ltd. Contact us: Resources: Sales Team: sales@qntmnet.com...
