Configure AP in Cloud
Quick Setup Guide
Models: QN-I-200, QN-I-220, QN-O-230

Advertisement

loading
Need help?

Need help?

Do you have a question about the QN-I-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Quantum Networks QN-I-200

  • Page 1 Configure AP in Cloud Quick Setup Guide Models: QN-I-200, QN-I-220, QN-O-230...
  • Page 2 Copyright & trademark specifications are subject to change without prior notice. Copyright © 2018 Quantum Networks (SG) Pte. Ltd. All Rights Reserved. Quantum NetworksTM& the logo are trademarks of Quantum Networks (SG) Pte. Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners. Mentioned contents of this document can’t be used, translated or transmitted in any form or by any means without taking prior...
  • Page 3: Table Of Contents

    Contents Document Abstract ........................4 Glossary ............................. 5 Configuration ..........................6 Device Info ..........................7 Start Configuration ........................ 8 Operation mode ........................10 Bridge ........................... 11 Router ..........................12...
  • Page 4: Document Abstract

    An Access Point is a device that creates a wireless local area network. Access Points are extensively used for associating users with the central network. In this document, we showcase the quick setup procedure of QN-I-200, QN-I-220 and AN-O-230 Access Points. This procedure helps to correctly configure Access Point to the Quantum Networks Cloud.
  • Page 5: Glossary

    Glossary Following terms are frequently used in this manual. Issues Description DHCP Dynamic Host Configuration Protocol (DHCP) is a network protocol that enables a server to automatically assign an IP address to concern devices. Static A static address is a fix IP address assigned to the device. PPPoE PPPoE stands for Point-to-Point Protocol over Ethernet, a network protocol for encapsulating Point-to-Point Protocol (PPP) frames inside Ethernet...
  • Page 6: Configuration

    Configuration 1. Provide internet access to WAN port of the Access Point. 2. Access point default SSID QN_XX: XX will broadcast. (Where XX: XX are last four digits of Access Point MAC Address). 3. Connect QN_XX: XX SSID and browse access point default IP 169.254.1.1. Below screen appears.
  • Page 7: Device Info

    Device Info Click on Device Info- to get information about device MAC, Serial Number and Firmware Version Figure 2 o Click on Change Firmware to update firmware if required. Figure 3 o Click on Change Firmware, select the firmware file from respective location and update.
  • Page 8: Start Configuration

    Start Configuration Click on “Start Configuration” for quick setup (Figure1). 5. Do IPv4 setup (WAN) by selecting required option DHCP, Static or PPPoE and proceed for Next. Figure 4...
  • Page 9 (If yet you have not created account on QN cloud, please refer Step 8). Click on Next. Note: Quantum Networks Access Point can be configured in two modes.  Standalone Mode (Independent management of each Access point) ...
  • Page 10: Operation Mode

    Operation mode 6. User can select AP operation mode as Bridge or Router. Figure 6 Description: Difference between Bridge Access Point and Gateway Access Point. Bridge Access Point: In this mode, device connects to a wired or wireless router via an Ethernet cable and extends the wireless coverage of your existing network.
  • Page 11: Bridge

    Bridge 7.1 Operation Mode - Bridge By selecting option Bridge, Configuration Summary screen will appear.. Click on Reconfigure if any changes required or click on Finish to complete the quick configuration. Figure 9...
  • Page 12: Router

    Router 7.2 Operation mode – Router Select option Router and click on Next. Configure WLAN (SSID) and Local subnet parameters and click on Next. Figure 10 Parameter Value WLAN WLAN Name Type SSID name of your choice. This is the name of your wireless network.
  • Page 13 iii. Configuration Summary screen will appear. Click on Reconfigure if any changes required or click on Finish to complete the quick configuration. Figure 11...
  • Page 14 8. Account setup on Quantum Networks Cloud Controller .  Browse https://cc.qntmnet.com.  Click on “Create New Account” to sign up a new account. Figure 12  Follow the steps as guided on screen for Registration.  Successful registration will show below message.
  • Page 15 Education, SOHO, Hot-Spots, NGOs, Healthcare, Budget Hotels, Hostels and so on. Feel free to contact us directly on below addresses. Thanking you again! Team Quantum Networks (SG) Pte. Ltd. Contact us: Resources: Sales Team: sales@qntmnet.com...
