Quantum Networks QN-I-270 Quick Setup Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Setup Guide
Model:
QN-I-270

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QN-I-270 and is the answer not in the manual?

Questions and answers

Related Manuals for Quantum Networks QN-I-270

Summary of Contents for Quantum Networks QN-I-270

  • Page 1 Quick Setup Guide Model: QN-I-270...

  • Page 2: Table Of Contents

    Contents Glossary ............................ 3 Icon description........................3 Before you begin ........................4 Package contents ........................4 Prerequisites ..........................4 Network requisites ........................4 Connect Access Point ......................4 Step 1 – Create new account on Quantum® RUDDER ............ 5 Step 2- Basic setup ......................... 6 Step 3- Setting up device IP address ...................

  • Page 3: Glossary

    This Quick Setup Guide provides step-by-step instructions on how to set up Quantum® Networks Access Point. After completing the steps described in this Guide, you will be able to install the Access Point (AP) on-site and provide wireless network access to users. Glossary Feature Description...

  • Page 4: Before You Begin

    Before you begin Your Quantum® Networks Access Point can work in “Standalone Mode” or can be managed by “RUDDER”. Package contents  Access Point. Prerequisites  Internet access.  Desktop / Laptop / Handheld device.  802.3af / 802.3at PoE Switch / PoE Injector. ...

  • Page 5: Step 1 - Create New Account On Quantum® Rudder

    Verify Quantum® RUDDER account from registered email id.  Once the account gets validated, it turns the page to “Add License Key” (User will get the license key from respective (Partner / Resource))  Account on Quantum® RUDDER (Quantum Networks® Cloud Controller) is now ready to use.

  • Page 6: Step 2- Basic Setup

    Step 2- Basic setup  Connect the WAN port of the Access Point to the network with Internet access.  You should see a new wireless network with SSID QN_XX:XX (where XX:XX are the last four digits of Access Point MAC Address). ...

  • Page 7: Step 3- Setting Up Device Ip Address

    Step 3- Setting up device IP address “and set the device IP address by selecting the required options. Click “Configure  Connectivity Mode – Ethernet / USB  Protocol - DHCP, Static or PPPoE  Interface – Select interface  VLAN Assignment- Enable parameter.

  • Page 8: Step 5 - Access Point Quick Setup Inrudder Mode

    Figure 4 Step 5 - Access Point quick setup inRUDDER Mode  Select “Management Mode” as “RUDDER”, enter Quantum® RUDDER login credentials and click “Proceed”. In the case of on-premise RUDDER, mention the local server IP Address/URL assigned to RUDDER, here. Figure 5...
  • Page 9  It will verify the credentials, and turn to a next page. Figure 6  Upgrade QNOS version by either downloading from the cloud or by selecting manually from respective location and upgrade orclick “Skip Upgrade” to move further.  The user will turn to a page where the user has to select the site and AP group.
  • Page 10 o If the selected site is already having another Access Point, it will automatically configure AP in a bridge mode and will turn the user on the summary page after clicking “Proceed”. (Figure 8) o If this is the first Access Point for the selected site – the user will turn on the page, where the user can select Access Point Operation mode as Bridge or Router.
  • Page 11 Figure 11  Review the Configuration Summary. Click “Reconfigure “if any changes are required or click “Proceed “to complete the configuration. Router  Select option Router and click “Proceed”.  Configure WLAN (SSID) and Local subnet parameters and click “Proceed”. Parameter Value WLAN...
  • Page 12 Figure 12 Figure 13 Note: If you do not want to create WLAN (SSID)/LAN now, click the Skip option. It will turn to Configuration Summary.  Review the Configuration Summary. Click “Reconfigure “if any changes are required or click “Proceed “to complete the configuration.

  • Page 13: Step 6 - Access Point Quick Setup In Standalone Mode

    Step 6 - Access Point quick setup in standalone mode Figure 14  Select “Management Mode” as “Standalone” if each Access Point is to be configured and managed individually. Define username and password for the device and click “Proceed”.  User can select Access Point Operation mode as Bridge or Router.
  • Page 14 Bridge  Select option Bridge and click “Proceed”.  Configure WLAN (SSID) parameters and click “Proceed”. Parameter Value Country Select country for radio management. Timezone Select time zone for RUDDER management. WLAN Name Define a name for the network. SSID Define visible wireless network name.
  • Page 15 Router  Select option Router and click “Proceed”.  Configure WLAN (SSID) and Local subnet parameters and click “Proceed”. Parameter Value WLAN Country Select country for radio management. Timezone Select time zone for RUDDER management. WLAN Name Define a name for the network. SSID Define visible wireless network name.

  • Page 16: Reset Access Point To Factory Defaults

    Reset Access Point to factory defaults o Power on the Access Point o Push the reset button on the back panel and hold it for 10 seconds. o Access Point would restart with factory defaults Access Point default login detail With standalone mode: User Name: Created while doing "Quick Setup"...

  • Page 17: Fcc Statement

    FCC statement FCC Class B FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
