KAKA Industrial AP-1/2 Operation Manual

Operation Manual
KAKA
Specifications
Model.............................................AP-1/2
Stock No. ......................................176501
Capacity........................................ 0.5 ton
Max. opening....... ........................115 mm
Deep Throat...................................80 mm
Worktable diameter.................. ⌀
Ram Square.............................19×19 mm
Packing Size................ 270x130x300 mm
N.W./G.W. ...................................... 8/9
kg
Unpacking
The ARBOR PRESS is shipped from the
manufacture in a carefully packed Carton
box. Thoroughly inspect the product upon
opening the package. After unpacking the
unit, carefully inspect for any damage that
may have occurred during transit.
If damage has
®
Industrial
95
occurred, shipping
damage claims must be filed with the
carrier and are the responsibility of the
user.
Check for completeness. Immediately
report missing parts to dealer.
Carefully open crate and unbolt brake
from shipping pallet and remove from
crate using heavy duty lifting equipment
such as an overhead crane.
Warning
The warnings, cautions and instructions
discussed in this instructions or situations
that could occur. It must be understood by
the operator that common sense and
caution are factors which cannot be built
into this product, but must be supplied by
the operator.
SAVE THIS MANUAL
You will need this manual for the safety
instruction,assembly
operating procedures, parts list, and
diagram. Write your invoice number on
the inside front cover. Put both your
manual and invoice in a safe, dry place for
future reference.
- 1 -
AP-1/2
instruction,
