- Page 1 T H E W O R L D P O W E R A N C H O R I N G S Y S T E M S HR 2500 CHEETAH HORIZONTAL WINDLASS www.muir.com.au...
-
Page 2: Table Of Contents
All HR2500 Cheetah Models - 12/24V DC Three Wire 1200W motor Exploded View Drawings HR 2500 Single Gypsy / Capstan HR 2500 twin Gypsies Only HR 2500 Twin Gypsies and Capstans HR 2500 Single Gypsy / Capstan (left hand) www.muir.com.au... -
Page 3: T H E W O R L D
S Y S T E M S INTRODUCTION Thank you for purchasing a Muir Windlass. Muir go to great lengths to develop anchoring systems that not only meet all your performance and safety requirements, but at the same time are designed with a style and finish that enhances the aesthetics of your vessel. -
Page 4: Installation
1. Mount the windlass from above as shown. Figure (6) 2. From below, place washers and nut on each stud and tighten. For fitting of the chain pipe or RCMS see next page NOTE: On assembly, grease all moving parts with a Lithium/teflon based grease. www.muir.com.au... -
Page 5: Chain Pipe Fitting
Procedure: 1. Loosen the grub screw on the chain pipe with an Allen key for finger adjustment. 2. Turn the screwdriver clockwise to tension the spring, while holding the tension re-tighten the grub screw www.muir.com.au... -
Page 6: Depth Of Chain Locker
Vertical windlasses minimise deck intrusion and the modern curved lines of the Muir windlass enhance the look of any vessel. A vertical windlass provides the advantages of a I 80-degree wrap of the anchor rode around the gypsy. -
Page 7: Handy Hints
For wiring information, please refer to the appropriate wiring diagram. WINCH MODEL MOTOR SIZE MOTOR TYPE HR 2500 1200 W 3 POLE www.muir.com.au... -
Page 8: Wiring Layout
TOGGEL SWITCH TOGGLE / DECK SWITCH LAYOUT BATTERY CIRCUIT BREAKER SOLENOID/CONTROL BOX DECK SWITCHES TOGGLE SWITCH AUTO ANCHOR LAYOUT BATTERY CIRCUIT BREAKER SOLENOID/CONTROL BOX DECK SWITCHES AUTO ANCHOR AUTO ANCHOR SENSOR OGGLE NOT TO BE USED AS WIRING DIAGRAMS www.muir.com.au... -
Page 9: Operating Instructions
Work and Charter Vesels we suggest it is carried out more frequently. Do not use soap based grease. Manually Releasing chain Tighten to brake the outgoing line Fully tighten to retrieve the anchor under power Gradually loosen to release the line manually www.muir.com.au... -
Page 10: Maintenance Instructions
Note: • We recommend the use of Lithium/Teflon based grease. • We also recommend that the windlass be serviced at least yearly. In the case of Work/Charter Vessels the windlass may require a more regular servicing www.muir.com.au... -
Page 11: Rope/Chain Splice
Cut any remaining tails. Line Care Using the wrong type of line may cause the line to jam causing excessive line wear. Muir Windlasses are designed to run on 3-strand nylon line (supplied by Muir) which has been specially treated with fabric softener to prevent it from hardening. - Page 12 • Normal worn parts or to damage caused by neglect, lack of maintenance, accident or improper service/installation or service by persons other than an authorised Muir representative. • Muir shall not be responsible for failures due to products being used in applications that they are not intended for, or exceed the products performance specifications.
- Page 14 ITEM PART NUMBER DESCRIPTION P22-HSGHR2500A HOUSING ALLOY HR2500 CHEETAH SG/SC K06-SFTHR2500A SHAFT ASSEMBLY HR2500 CHEETAH SG/SC P07-CLNBRZHR01200C CLUTCH NUT BRONZE HR1200 COUGAR 3 PRONG P08-CNEBRZHR01200CD 'D' CONE BRONZE HR1200C COUGAR P11-HANAB2LEV01200C HANDLE LEVER AB2 HR1200C COUGAR P02-NOVHR01200CLH BEARING LEVER HANDLE NOV HR1200C COUGAR P22-BPLALLHR02500 BASE PLATE ALLOY HR2500 CHEETAH P02-NOVHR01200CCS...
- Page 15 ITEM PART NUMBER DESCRIPTION P22-HSGHR2500ATG HOUSING ALLOY HR2500 CHEETAH TW IN GYPSY K06-SFTHR2500B SHAFT ASSEMBLY HR2500 CHEETAH TG P07-CLNBRZHR01200C CLUTCH NUT BRONZE HR1200 COUGAR 3 PRONG P08-CNEBRZHR01200CD 'D' CONE BRONZE HR1200C COUGAR P11-HANAB2LEV01200C HANDLE LEVER AB2 HR1200C COUGAR P02-NOVHR01200CLH BEARING LEVER HANDLE NOV HR1200C COUGAR P22-BPLALLHR02500 BASE PLATE ALLOY HR2500 CHEETAH S45-30407.94013...
- Page 16 ITEM PART NUMBER DESCRIPTION P22-HSGHR2500A HOUSING ALLOY HR2500 CHEETAH SG/SC K06-SFTHR2500C SHAFT ASSEMBLY HR2500 CHEETAH TG/SC P07-CLNBRZHR01200C CLUTCH NUT BRONZE HR1200 COUGAR 3 PRONG P08-CNEBRZHR01200CD 'D' CONE BRONZE HR1200C COUGAR P11-HANAB2LEV01200C HANDLE LEVER AB2 HR1200C COUGAR P02-NOVHR01200CLH BEARING LEVER HANDLE NOV HR1200C COUGAR P22-BPLALLHR02500 BASE PLATE ALLOY HR2500 CHEETAH S45-30407.94013...
- Page 17 ITEM PART NUMBER DESCRIPTION P22-HSGHR2500ATG HOUSING ALLOY HR2500 CHEETAH TW IN GYPSY K06-SFTHR2500A SHAFT ASSEMBLY HR2500 CHEETAH SG/SC P07-CLNBRZHR01200C CLUTCH NUT BRONZE HR1200 COUGAR 3 PRONG P08-CNEBRZHR01200CD 'D' CONE BRONZE HR1200C COUGAR P11-HANAB2LEV01200C HANDLE LEVER AB2 HR1200C COUGAR P02-NOVHR01200CLH BEARING LEVER HANDLE NOV HR1200C COUGAR P22-BPLALLHR02500 BASE PLATE ALLOY HR2500 CHEETAH P02-NOVHR01200CCSL...
- Page 18 WINDLASS SERIAL NUMBER © 2005 Muir Engineering Pty. Ltd. Muir reserves the right to alter specifications without notice. All rights reserved. While all due care and attention has been taken in the preparation of this manual no responsibility shall be taken for errors or omissions.
