- Page 1 YS-Z600 Manual www.rami-yokota.com...
- Page 4 Recommended Technical specifications Brand Yokota Square Drive 3/8" Bolt capacity (mm) 1200 ~ 4800 Torque (Nm) 7 ~ 20 Weight w/o battery (kg) 1,34 mm A mm B Battery voltage (Volt) Battery type Li-ion….(Ah) Safety standard EN ISO 11148-6 Formal Capacity...
- Page 5 Safety Do not modify this tool in any way, this can cause danger for the operator. Make sure that this manual is accessible at all times for any relevant person, in case of loss of this manual ask your dealer for a new copy or refer to our website. Risk of explosion or fire: Make sure that generated sparks and/or increased temperature of the work piece can not cause any explosion or ignite a fire.
- Page 6 Do not use quick change couplings direct on the air inlet of the tool as these may release during operation. Assemble at least 50 cm air hose with a hose joint of shock resistant material. In case universal twist couplings ( claw couplings) are used, the lock pins must be mounted. Do not exceed the maximum air pressure as indicated on the tool.
- Page 7 Always obey the safety regulations for the work area you are working in. During operating the tool, the operator may be exposed to hazards as crushing, impacts, heat, vibration, cuts, abrasions, etc: Wear suitable gloves. Any person handling the tool must be able to handle the size, weight and power of the tool. Always be prepared for normal/abnormal movements/forces generated by the tool.
- Page 8 Oil replacement should only be carried out by trained qualified specialists. For Yokota Impulse wrenches the advice is to replace the oil after 250.000 cycles on hard joint, one cycle is 0,5 – 1 second impulsing. On soft joints, longer impulsing time per cycle, the oil must be changed earlier.
- Page 9 Warranty covers material or construction mistakes of the manufacturer, which are clearly definable. Replacement of parts or repair by an official Yokota/Red Rooster service workshop is free of charge, when the tool is covered by warranty. Freight or postage is for the account of the buyer. Damage attributable to a normal wear, overloading or incorrect use is excluded from warranty.
- Page 10 www.rami-yokota.com...
