* The figure above shows this product combined with the separately sold ET-PKD520H Ceiling Mount Bracket (for High
Ceilings).
Thank you for purchasing this Panasonic product.
■ To customers
The "Installation Instructions" is intended for use by installation personnel. Be sure to employ certified
personnel to perform the installation.
After installation, have the installation personnel return these "Installation Instructions" to you, and save it for future use.
When moving or removing the projector, give this manual to the certified personnel and have them perform the
procedure.
■ To installation personnel
Read the "Installation Instructions" thoroughly and then perform the operation correctly and safely.
Be sure to read through the section entitled "Read this first!" (page 3) before proceeding with the installation.
After installation, return these "Installation Instructions" to the customer.
Installation Instructions
Model No.
Projector Mount Bracket
ET-PKD521B
ENGLISH
FRANÇAIS
DEUTSCH
日本語
ENGLISH
DPQX1648XA/X1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Panasonic ET-PKD521B
Summary of Contents for Panasonic ET-PKD521B
- Page 1 * The figure above shows this product combined with the separately sold ET-PKD520H Ceiling Mount Bracket (for High Ceilings). Thank you for purchasing this Panasonic product. ■ To customers The “Installation Instructions” is intended for use by installation personnel. Be sure to employ certified personnel to perform the installation.
-
Page 2: Table Of Contents
Contents Read this first! ....................3 Product components ..................4 Standard installation dimensions ..............5 <When using a lens other than the ET-D3LEW200 Zoom lens, the ET-D3LEU100 / ET-D75LE95 / ET-D75LE90 Fixed-focus lens, or ET-D3LEF70 Fisheye lens> ......5 <When using the ET-D3LEU100 Fixed-focus lens / ET-D3LEW200 Zoom lens> ....12 <When using the ET-D75LE95 / ET-D75LE90 Fixed-focus lens>... -
Page 3: Read This First
Electric shocks may result from contact with any metal objects inside the ceiling. ■ Panasonic Projector & Display Corporation disclaims all liability for any accidents or any damage caused by the installation of the ceiling mount bracket using methods that are not described in these Installation Instructions or methods that do not use the parts specified in these Instructions. -
Page 4: Product Components
Models other than the above may also be supported. Refer to the operating instructions for your projector or the following website. https://docs.connect.panasonic.com/projector ■ Structural components Check that the package contains the following parts. The number enclosed in < > is the quantity. -
Page 5: Standard Installation Dimensions
Standard installation dimensions <When using a lens other than the ET‑D3LEW200 Zoom lens, the ET‑D3LEU100 / ET‑D75LE95 / ET‑D75LE90 Fixed‑focus lens, or ET‑D3LEF70 Fisheye lens> The dimensional relationship between the screen and the projector is shown below. Establish the dimensions after assessing the area possible for installation. The zoom function of the lens allows you to adjust the projection distance. - Page 6 Standard installation dimensions (continued) Attention z Install the projector at a sufficient distance from the surrounding walls and objects so that the air intake and exhaust ports of the projector are not blocked. For details on the distance, refer to the operating instructions for your projector.
- Page 7 Standard installation dimensions (continued) PT‑RQ25K / RQ18K / RZ24K / RZ17K / RZ14K (Unit: m) Projection distance (L) formula Projection Throw ratio Aspect ratio Lens Min. (LW) Max. (LT) 1.11 - 1.32 : 1 16:10 = 0.9574 × SD - 0.0566 = 1.1471 ×...
- Page 8 Standard installation dimensions (continued) Projection distance (L) formula Projection Throw ratio Aspect ratio Lens Min. (LW) Max. (LT) 16:10 = 2.2081 × SD - 0.1261 = 4.2947 × SD - 0.1892 2.57 - 5.00 : 1 ET-D3LET30 16:9 = 2.2695 × SD - 0.1261 = 4.4141 ×...
- Page 9 Standard installation dimensions (continued) PT‑RZ21K / RZ16K (Unit: m) Projection distance (L) formula Projection Throw ratio Aspect ratio Lens Min. (LW) Max. (LT) 16:10 = 0.7979 × SD - 0.0566 = 0.9559 × SD - 0.0736 0.924 - 1.10 : 1 ET-D3LEW60/ 16:9 = 0.8201 ×...
- Page 10 Standard installation dimensions (continued) PT‑RZ12K (Unit: m) Projection distance (L) formula Projection Throw ratio Aspect ratio Lens Min. (LW) Max. (LT) 16 : 10 = 0.7979 × SD - 0.0566 = 0.9559 × SD - 0.0736 0.924 - 1.10 : 1 ET-D75LE6 16 : 9 = 0.8201 ×...
- Page 11 Standard installation dimensions (continued) PT‑RS11K (Unit: m) Projection distance (L) formula Projection Throw ratio Aspect ratio Lens Min. (LW) Max. (LT) 4 : 3 = 0.8150 × SD - 0.0566 = 0.9764 × SD - 0.0736 ET-D75LE6 1.01 - 1.19 : 1 16 : 9 = 0.8877 ×...
-
Page 12: When Using The Et-D3Leu100 Fixed-Focus Lens / Et-D3Lew200 Zoom Lens
Standard installation dimensions (continued) <When using the ET‑D3LEU100 Fixed‑focus lens / ET‑D3LEW200 Zoom lens> The dimensional relationship between the screen and the projector is shown below. Establish the dimensions after assessing the area possible for installation. ■ Dimensional reationship diagram z The illustration shows the ET-PKD520H ceiling mount bracket mounted on a projector. - Page 13 Standard installation dimensions (continued) Attention z Install the projector at a sufficient distance from the surrounding walls and objects so that the air intake and exhaust ports of the projector are not blocked. For details on the distance, refer to the operating instructions for your projector.
- Page 14 Standard installation dimensions (continued) ET‑D3LEU100 (Unit: m) Projector Throw ratio Aspect ratio Projection distance (L) formula PT-RQ25K / 16:10 = 0.3917 × SD - 0.0664 PT-RQ18K / 0.447 : 1 PT-RZ24K / 16:9 = 0.4025 × SD - 0.0664 PT-RZ17K / 0.538 : 1 = 0.4434 ×...
-
Page 15: When Using The Et-D75Le95 / Et-D75Le90 Fixed-Focus Lens
Standard installation dimensions (continued) <When using the ET‑D75LE95 / ET‑D75LE90 Fixed‑focus lens> The dimensional relationship between the screen and the projector is shown below. Establish the dimensions after assessing the area possible for installation. ■ Dimensional relationship diagram z The illustration shows the ET-PKD520H ceiling mount bracket mounted on a projector. (Units: mm (")) Ceiling For the ET-PKD520H:... - Page 16 Standard installation dimensions (continued) Attention z Install the projector at a sufficient distance from the surrounding walls and objects so that the air intake and exhaust ports of the projector are not blocked. For details on the distance, refer to the operating instructions for your projector.
- Page 17 Standard installation dimensions (continued) PT‑RZ21K / RZ16K / RZ12K (Unit: m) Aspect ratio 16 : 10 Aspect ratio 16 : 9 Aspect ratio 4 : 3 (Throw ratio [0.36 : 1]) (Throw ratio [0.36 : 1]) (Throw ratio [0.44 : 1]) = 0.303 ×...
-
Page 18: When Using The Et-D3Lef70 Fisheye Lens
Standard installation dimensions (continued) <When using the ET‑D3LEF70 Fisheye lens> The dimensional relationship between the screen and the projector is shown below. Establish the dimensions after assessing the area possible for installation. ■ Dimensional reationship diagram z The illustration shows the ET-PKD520H ceiling mount bracket mounted on a projector. Ceiling Lens optical axis θ... - Page 19 Standard installation dimensions (continued) ■ Dimensional relationship z H1 and L5 values (Unit: m) PT-RQ25K / RQ18K / RZ24K / RZ17K / PT-RQ22K / RZ21K / RS20K / RZ16K / RZ14K RQ13K / RZ12K / RS11K 0.540 - 0.660 0.562 - 0.682 ET-PKD520H 0.275 0.298...
- Page 20 Standard installation dimensions (continued) ■ Projected angle of view diagram θ θ Screen Screen θ θ θ Projector θ θ θ Projector θ When the lens is centered When the lens is shifted to the upward Vmax position θ Maximum horizontal center angle of view θ...
-
Page 21: Installation
Installation After checking the height, width, and structure of the installation location while referring to “Standard installation dimensions” on pages 5 to 20, determine the appropriate positions for setting up the screen and installing the projector. z The [GEOMETRY] function cannot be used when projecting images in the simultaneous format with a PT-RQ22K / RQ13K series DLP™... -
Page 22: Attaching The Wire Rope To The Projector
Installation (continued) <When PT‑RQ22K / RZ21K / RS20K / RZ16K / RQ13K / RZ12K / RS11K> 1) Place the projector upside-down onto a piece of “FRONT” inscription FRONT soft material. Projector mount bracket 2) Firmly secure the projector mount bracket to the bottom of the projector using the six supplied captive washer hex head bolts (M6 ×... -
Page 23: Specifications
Installation (continued) 2) As shown in the figure on the left, pass the supplied hex head bolts with washers (M10 × 40) through the rings in the supplied wire rope, and secure the bolts to the threaded holes in which the adjustable feet were previously attached. - Page 24 Panasonic Projector & Display Corporation Web Site : https://docs.connect.panasonic.com/projector © Panasonic Projector & Display Corporation 2025 SS0922AM2045 -PS Printed in Japan...
