North American Tool 7654 Important Operating Instructions

5HP 80 GALLON TWO
STAGE COMPRESSOR
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often
contains chemicals known to
cause cancer, birth defects, or
other reproductive harm. Wear
protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead, known
to the State of California to cause
cancer and birth defects or other
reproductive harm. Wash hands
after handling.
CAUTION:
FOR YOUR OWN SAFETY READ
INSTRUCTION MANUAL
COMPLETELY AND CAREFULLY
BEFORE OPERATING THIS
COMPRESSOR.
Failure to follow all instructions
as listed below may result in
electrical shock, fire, and/or
serious personal injury.
BREATHABLE AIR WARNING:
This compressor/pump is not
equipped and should not be used
"as is" to supply breathing
quality air. For any application of
air for human consumption, the
air compressor/pump will need
to be fitted with suitable in-line
safety and alarm equipment.
This additional equipment is
necessary to properly filter and
purify the air to meet minimal
specifications for Grade D
breathing as described in
Compressed Gas Association
Commodity Specification G 7.1 -
1966, OSHA 29 CFR 1910. 134,
and/or Canadian Standards
Associations (CSA).
DISCLAIMER:
In the event the compressor is
used for the purpose of
breathing air application and
proper in-line safety and alarm
equipment is not simultaneously
use, existing warranties are
void, and all warranties and
liabilities whatsoever for any
loss, personal injury, or
damage.
SPECIFICATIONS:
Tank Size: 80 Gallons
PUMP RPMs: 650 RPM
CFM: 17.0 @ 40 PSI
Max Pressure: 175 PSI
Thermal overload protection
Two Stage cast iron oil
lubricated
feedback@natitools.com
Models: 7654
SAFETY WARNINGS
Disconnect power and release
all pressure from the system
before attempting to install,
relocate, service or perform
any maintenance on this
compressor.
Never store flammable liquids
or gases near the
compressor. Electric arcs can
be produced by the electric
motor and pressure switch.
Do not operate the
compressor without the belt
guard in place. Moving parts
can cause serious injuries.
1) Follow all electrical and safety
codes along with National
Electrical Codes (NEC) and
Occupational Safety and Health
Act (OSHA).
2) Electric motors and starters
must be securely and properly
grounded.
3) Do not allow the cable to
come into contact with oil,
grease, chemicals or sharp
objects. Do not allow kinks to
form in the cable.
4) Do not exceed the pressure
limits for any component in or
connected to the system.
88007654 09/13
