- Page 1 Monoprice™ Radio Frequency Remote Kit for Stealth Motorized Recessed Projector Lift (15495) GF123-5 (Remote Control) & 1GD-868MnIII (Receiver) Model User Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this manual carefully before use to prevent potential damage to the product caused by improper operation. Please keep this manual in a safe place for future reference. Receiver This device is intended for indoor use only. •... -
Page 3: Remote Control
Remote Control Remove and immediately recycle or dispose of used batteries according to local regulations and • keep away from children. DO NOT dispose of batteries in household trash or incinerate. Even used batteries may cause severe injury or death. Call a local poison control center for •... -
Page 4: Table Of Contents
Table of Contents SAFETY WARNINGS AND GUIDELINES ..................................... 2 Receiver .................................................. 2 Remote Control ............................................... 3 RECEIVER (1GD-868MNIII) ..........................................4 Technical Features ............................................5 Specifications ..............................................5 Installation ................................................5 Wiring Instructions ............................................6 REMOTE CONTROL (GF123-5) ........................................8 Functions ................................................8 Specifications .............................................. -
Page 5: Technical Features
Technical Features Equipped with STM microcontroller with damp-proof processing for • enhanced durability Automatically powers down if inactive for one minute to conserve • energy Includes certified connectors to ensure user safety and compliance • Each receiver can store and recognize up to 20 unique codes, •... -
Page 6: Wiring Instructions
metal Dimension Maintain a minimum distance of 20 cm between multiple receivers to ensure optimal • performance. Wiring Instructions Please refer to the diagram below for correct wire connections, and follow these guidelines during installation: Ensure that the power is fully disconnected before starting any wiring. •... - Page 7 Wiring Model Na e 115V Color Color ive Wire rown lack Power arth Wire Yellow Green reen Line ull Wire hite ull Wire arth Wire Yellow Green Y llow Green Motor p/Down Wire rown rown p/Down Wire lack lack Wire Stop Stop Wire xternal...
-
Page 8: Remote Control (Gf123-5)
REMOTE CONTROL (GF123-5) The remote control is compatible with the receiver and communicates via radio waves at a frequency of 868 MHz. Functions Press ▲ to raise the lift. Press - to stop the lift. DOWN 3. Press ▼ to lower the lift. Micro-up Micro-down 4. -
Page 9: Manual Switch Instructions For Receiver
2. Do not initiate programming while the lift is moving. 3. During programming, the remote control will temporarily be inactive. Manual Switch Instructions for Receiver If the remote control is not functioning, you can use the Manual Switch on the receiver to control the lift (refer to the diagram on Page 6). -
Page 10: Regulatory Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Modifying the equipment without Monoprice's authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense. -
Page 11: Radio Notice For Fcc
This FCC Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any changes or modification to said product not expressly approved by Monoprice, including the use of non-approved antennas, could void the user’s authority to operate this device. - Page 12 Product pictures are for reference only. Brea, CA 92821 – USA Specifications described herein are subject to change without prior notification. www.monoprice.com Monoprice™ and all Monoprice logos are trademarks of Monoprice Inc. Copyright © 2024 Monoprice, Inc. All rights reserved.
